Green micro-ATX motherboard with black heatsinks and silver PCIe slots

ASUS

ASUS TUF B360M-E GAMING Intel motherboard

SKU CH-KE9G-P0RHH

Micro-ATX board for 8th-generation Intel Core processors with dual-channel DDR4 2666 memory, one PCIe 3.0 x16 slot, six SATA 6Gb/s ports, one M.2 slot, Intel I219-V Gigabit LAN.

  • CPU Socket TypeLGA 1151 (300 Series)
  • CPU TypeCore i7 / i5 / i3 (8th Gen, LGA1151)
  • Supported CPU TechnologiesTurbo Boost Technology 2.0
  • ChipsetIntel B360
  • Onboard Video ChipsetSupported only by CPU with integrated graphic
  • Number of Memory Slots2x288pin (DDR4)
  • Supports 8th Gen Intel Core i7/i5/i3 processors via LGA 1151 (300 Series) socket
  • Dual-channel DDR4 2666 memory up to 32 GB across two 288-pin slots
  • Six SATA 6Gb/s ports plus one M.2 slot for fast storage expansion
  • Intel I219-V Gigabit LAN and Realtek ALC887 7.1-channel audio for wired networking and sound
  • Military-grade TUF components with Fan Xpert cooling control and Aura Sync RGB lighting

Built for 8th Gen Intel Core

The ASUS TUF B360M-E GAMING is a Micro ATX board on the Intel B360 chipset with an LGA 1151 socket for 8th generation Core i7, i5 and i3 processors. It supports up to 32GB of DDR4 2666 memory in two slots running dual channel. A single PCI Express 3.0 x16 slot, two PCI Express x1 slots and six SATA 6Gb/s ports handle expansion and storage.

Who it suits and who should look elsewhere

Builders who need a compact, durable platform for an 8th Gen Intel CPU with integrated graphics will appreciate the military-grade TUF components, Fan Xpert cooling control and Aura Sync RGB lighting. The board includes Intel I219-V Gigabit LAN, Realtek ALC887 7.1 audio, HDMI, DVI and USB 3.1 connectivity. Users needing more than two memory slots, multiple M.2 drives or support for newer CPU generations should choose a different motherboard.

The deciding specification

The LGA 1151 (300 Series) socket locks this board to 8th generation Intel Core, Pentium and Celeron processors only; it will not accept 6th, 7th or 9th generation CPUs. If your processor is not on that list, this motherboard cannot be used.

Highlights

  • Supports 8th Gen Intel Core i7/i5/i3 processors via LGA 1151 (300 Series) socket
  • Dual-channel DDR4 2666 memory up to 32 GB across two 288-pin slots
  • Six SATA 6Gb/s ports plus one M.2 slot for fast storage expansion
  • Intel I219-V Gigabit LAN and Realtek ALC887 7.1-channel audio for wired networking and sound
  • Military-grade TUF components with Fan Xpert cooling control and Aura Sync RGB lighting

Specifications

BrandASUS
SeriesTUF
ModelB360M-E GAMING
CPU Socket TypeLGA 1151 (300 Series)
CPU TypeCore i7 / i5 / i3 (8th Gen, LGA1151)
Supported CPU TechnologiesTurbo Boost Technology 2.0
ChipsetIntel B360
Onboard Video ChipsetSupported only by CPU with integrated graphic
Number of Memory Slots2x288pin (DDR4)
Memory StandardDDR4 2666
Maximum Memory Supported32GB
Channel SupportedDual Channel
PCI Express 3.0 x161 x PCI Express 3.0 x16
PCI Express x12 x PCI Express x1
Serial ATA (SATA)6 x SATA 6Gb/s
M.21 x M.2
Intel Optane ReadyYes
Audio ChipsetRealtek ALC887
Audio Channels8 Channels
LAN ChipsetIntel I219-V
Max LAN Speed1Gbps
Back I/O Ports1 x HDMI / 2 x PS/2 / 2 x USB 2.0/1.1 / 4 x USB 3.1 Gen 2 Type-A
PS/22
Video PortsDVI
HDMI1 x HDMI
RJ451 x RJ45
USB 3.14 x USB 3.1
USB 1.1/2.02 x USB 2.0
Audio Ports3 Ports
Onboard USB2 x USB 3.1 + 4 x USB 2.0
Other Connectors1 x 4-pin CPU Fan connector 1 x 4-pin Chassis Fan connector1 x Front panel audio connector1 x S/PDIF Out connector1 x COM header1 x RGB header1 x Clear CMOS jumper (2-pin)1 x Speaker connector1 x System Panel connector
Form FactoruATX
LED LightingRGB
Dimensions (W x L)12.0" x 8.2"
Power Pin24 Pin
FeaturesASUS Special Features:ASUS TUF PROTECTION- ASUS SafeSlot: Protects your graphics card Investment- ASUS ESD Guards - Enhanced ESD protection- ASUS DIGI+ VRM - 5 Phase digital power design- ASUS Overvoltage Protection: World-class circuit-protecting power design- ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!Superb PerformanceASUS OptiMem- Improved DDR4 stabilityM.2 onboard- The latest transfer technologies with up to 32Gb/s data transfer speedsASUS EPU- EPUUEFI BIOS- The most advanced options with a fast response timeGaming ScenarioAudio Features - Audi
Package ContentsAccessories:2 x Serial ATA 6.0Gb/s cables1 x I/O shield1 x M.2 screw package1 x TUF GAMING sticker1 x TUF Certification Card1 x Support DVD1 x User's manual

Questions about this item

How loud or hot does the TUF B360M-E GAMING run when the system is under load all day?

Fan Xpert gives advanced fan and liquid cooling controls so you can tune airflow for quiet, stable operation during extended sessions.

What components must I already own for this board to boot and post?

You need an 8th generation Intel Core i7, i5 or i3 processor for the LGA 1151 socket and at least one DDR4 2666 DIMM for the two 288-pin slots.

Will my existing SATA SSDs and hard drives work alongside the single M.2 slot on this motherboard?

Yes, six SATA 6Gb/s ports are available plus one M.2 interface, so legacy drives and a new M.2 device can coexist.
