Dark green micro-ATX board with reinforced PCIe slot and black heatsinks

ASUS

ASUS TUF Z390M-Pro Gaming (Wi-Fi) Intel motherboard

SKU CH-3EWN-PXJAC

Micro-ATX Intel Z390 board with dual M.2 slots, 802.11 ac Wi-Fi, USB 3.1 Gen2 and military-grade TUF components for 8th and 9th Gen Core CPUs

  • CPU Socket TypeLGA 1151 (300 Series)
  • CPU TypeCore i7 / i5 / i3 (8th Gen, LGA1151)
  • Supported CPU TechnologiesTurbo Boost Technology 3.0
  • ChipsetIntel Z390
  • Onboard Video ChipsetSupported only by CPU with integrated graphic
  • Number of Memory Slots4x288pin (DDR4)
  • Supports 8th and 9th Gen Intel Core CPUs via LGA 1151 socket
  • Dual M.2 slots and six SATA 6Gb/s ports expand high-speed storage
  • Military-grade TUF components and SafeSlot reinforce long-term board durability
  • Realtek S1200A 8-channel audio with Japanese capacitors delivers immersive gaming sound
  • ASUS OptiMem II trace isolation preserves DDR4 signal integrity at 2666 speeds

Designed for 8th and 9th Gen Intel Core

This Micro ATX motherboard uses the LGA 1151 socket with Intel Z390 chipset to support 8th and 9th generation Core i7, i5 and i3 processors. Four 288-pin DDR4 slots accept up to 64 GB in dual-channel configuration at 2666 MHz. Onboard 802.11 ac Wi-Fi and USB 3.1 Gen2 add modern connectivity in a compact form factor.

Upgrade path from older 300 Series boards

The Z390 chipset brings native USB 3.1 Gen2 support and improved power delivery over earlier 300 Series designs, making the jump worthwhile when moving to 9th generation CPUs or when more M.2 slots are needed. Two M.2 sockets and six SATA 6Gb/s ports with RAID 0/1/5/10 give flexible storage expansion without sacrificing PCI Express 3.0 x16 graphics lanes.

Sustained load behaviour

TUF Chokes, Capacitors and MOSFETs are rated for extended durability under continuous thermal stress, while FanXpert 4 adjusts cooling curves dynamically across headers. Realtek S1200A 8-channel audio driven by Japanese capacitors maintains signal integrity during long sessions, and ASUS OptiMem II trace isolation preserves memory stability at higher frequencies over time.

Highlights

  • Supports 8th and 9th Gen Intel Core CPUs via LGA 1151 socket
  • Dual M.2 slots and six SATA 6Gb/s ports expand high-speed storage
  • Military-grade TUF components and SafeSlot reinforce long-term board durability
  • Realtek S1200A 8-channel audio with Japanese capacitors delivers immersive gaming sound
  • ASUS OptiMem II trace isolation preserves DDR4 signal integrity at 2666 speeds

Specifications

BrandASUS
SeriesTUF
ModelZ390M-Pro Gaming (Wi-Fi)
CPU Socket TypeLGA 1151 (300 Series)
CPU TypeCore i7 / i5 / i3 (8th Gen, LGA1151)
Supported CPU TechnologiesTurbo Boost Technology 3.0
ChipsetIntel Z390
Onboard Video ChipsetSupported only by CPU with integrated graphic
Number of Memory Slots4x288pin (DDR4)
Memory StandardDDR4 2666
Maximum Memory Supported64GB
Channel SupportedDual Channel
PCI Express 3.0 x162 x PCI Express 3.0 x16
PCI Express x11 x PCI Express x1
Serial ATA (SATA)6 x SATA 6Gb/s
M.22 x M.2
Intel Optane ReadyYes
SATA RAID0/1/5/10
Audio ChipsetRealtek ALC S1200A High Definition Audio CODEC
Audio Channels8 Channels
LAN ChipsetIntel I219-V
Max LAN Speed1Gbps
Wireless LANWi-Fi 802.11 ac
BluetoothYes
PS/22
HDMI1 x HDMI
RJ451 x RJ45
DisplayPort1 x DisplayPort
USB 3.15 x USB 3.1
USB Type-C1 x USB 3.1
Audio Ports3 Ports
Antenna Connectors2 x Wi-Fi antenna port(s)
Onboard USB3 x USB 3.1 + 4 x USB 2.0
Other Connectors2 x Lighting Control RGB Strip Header(s)1 x CPU Fan connector(s) (4-pin)1 x CPU OPT Fan connector(s) (4-pin)2 x Chassis Fan connector(s) (4-pin)1 x AIO_PUMP connector (4-pin)1 x S/PDIF out header(s)1 x Front panel audio connector(s) (AAFP)1 x MemOK! II switch(es)1 x Clear CMOS jumper(s)1 x Serial Port header1 x System panel connector
Form FactorMicro ATX
LED LightingRGB
Dimensions (W x L)9.6" x 9.6"
Power Pin24 Pin
FeaturesMulti-GPU Support:Supports NVIDIA SLI TechnologySupports AMD CrossFireX Technology Special Features:ASUS TUF PROTECTION- ASUS SafeSlot: Protect your graphics card Investment- ASUS ESD Guard: Enhanced ESD protection- ASUS Overvoltage Protection: World-class circuit-protecting power design- ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!- ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges!ASUS Optimem II:- Optimem (Improved DDR4 stability)ASUS EPU:- EPUAURA:- Aura Lighting Control- Aura RGB Strip HeadersASUS Ex
Package ContentsAccessories:User's manualI/O Shield2 x SATA 6Gb/s cable(s)1 x M.2 Screw Package1 x ASUS 2T2R dual band Wi-Fi moving antennas (Wi-Fi 802.11 a/b/g/n/ac compliant)1 x TUF Gaming Sticker1 x SLI HB BRIDGE (2-WAY-S)1 x Q-Connector1 x TUF Certification card(s)1 x SCD (by region)

Questions about this item

What case clearance does the Micro ATX board need?

The board uses the Micro ATX form factor, so it fits any case that accepts Micro ATX or larger ATX motherboards.

How is the CPU installed on the LGA 1151 socket?

Lift the socket lever, align the processor triangle with the socket corner, place the CPU gently without force, then lower and lock the lever — the step often missed is checking that the notches sit fully before locking.

When will the DDR4 memory slots need attention?

The four 288-pin DDR4 slots only need attention if you upgrade capacity later; they support up to 64 GB in dual-channel mode.
