Green ATX motherboard with silver CPU socket and four black memory slots

ASUS

ASUS Z87-K LGA 1150 Intel Z87 ATX Motherboard

SKU CH-F8H5-4CQSY

Supports fourth-generation Intel Core processors with up to 32 GB of DDR3 memory and six SATA 6Gb/s ports

  • CPU Socket TypeLGA 1150
  • CPU Type4th-Generation Core i7 / Core i5 /Core i3 / Pentium / Celero
  • Supported CPU TechnologiesTurbo Boost Technology 2.0
  • ChipsetIntel Z87
  • Number of Memory Slots4 × 240 pin
  • Memory StandardDDR3 2933(OC)/2800(OC)/2666(OC)/2600(OC)/2400(OC)/2200(OC)/2
  • Supports 4th-generation Intel Core processors via LGA 1150 socket
  • Dual-channel DDR3 memory up to 32 GB with overclocked speeds to 2933 MHz
  • Six SATA 6 Gb/s ports with RAID 0/1/5/10 for flexible storage arrays
  • Realtek ALC887 8-channel audio and Gigabit LAN for clear sound and wired networking
  • UEFI BIOS plus AI Suite 3 and Fan Xpert 2 simplify setup, monitoring and cooling control

Socket LGA 1150 Z87 ATX Motherboard

This ASUS Z87-K board fits the Intel LGA 1150 socket and supports 4th-Generation Core i7, Core i5, Core i3, Pentium and Celeron processors. The Intel Z87 chipset provides native SATA 6Gb/s and USB 3.0 connectivity on a standard ATX layout.

System builders using 4th-Generation Intel CPUs

The four DDR3 slots accept dual-channel kits up to 32 GB with overclocked speeds reaching 2933 MT/s. Builders needing newer CPU sockets, different memory types or integrated wireless should look at alternative platforms.

One PCI Express 3.0 x16 slot

A single full-length PCI Express 3.0 x16 slot handles the primary graphics card while a second x16 slot runs at x4 and two x1 slots plus three legacy PCI slots provide extra expansion.

Highlights

  • Supports 4th-generation Intel Core processors via LGA 1150 socket
  • Dual-channel DDR3 memory up to 32 GB with overclocked speeds to 2933 MHz
  • Six SATA 6 Gb/s ports with RAID 0/1/5/10 for flexible storage arrays
  • Realtek ALC887 8-channel audio and Gigabit LAN for clear sound and wired networking
  • UEFI BIOS plus AI Suite 3 and Fan Xpert 2 simplify setup, monitoring and cooling control

Specifications

BrandASUS
ModelZ87-K
CPU Socket TypeLGA 1150
CPU Type4th-Generation Core i7 / Core i5 /Core i3 / Pentium / Celeron (LGA1150)
Supported CPU TechnologiesTurbo Boost Technology 2.0
ChipsetIntel Z87
Number of Memory Slots4 × 240 pin
Memory StandardDDR3 2933(OC)/2800(OC)/2666(OC)/2600(OC)/2400(OC)/2200(OC)/2133(OC)/2000(OC)/1866(OC)/1600/1333
Maximum Memory Supported32GB
Channel SupportedDual Channel
PCI Express 3.0 x161 x PCI Express 3.0 x16
PCI Express 2.0 x161(running at x4)
PCI Express x12 x PCI Express x1
PCI Slots3 x PCI Slots
Serial ATA (SATA)6 x SATA 6Gb/s
SATA RAID0/1/5/10
Audio ChipsetRealtek ALC887
Audio Channels8 Channels
LAN ChipsetRealtek 8111-GR
Max LAN Speed1Gbps
Back I/O Ports1 x HDMI / 2 x PS/2 / 2 x USB 3.0 / 4 x USB 2.0/1.1
PS/22
Video PortsD-Sub + DVI
HDMI1 x HDMI
USB 3.02 x USB 3.0
USB 1.1/2.04 x USB 2.0
Audio Ports3 Ports
Onboard USB1 x 19-pin USB 3.0/2.0 connector supports additional 2 USB 3.0/2.0 port3 x USB 2.0/1.1 connectors support additional 6 USB 2.0/1.1 ports
Other Connectors1 x COM port(s) connector(s)6 x SATA 6Gb/s connector(s)1 x CPU Fan connector(s) (1 x 4 -pin)2 x Chassis Fan connector(s) (2 x 4 -pin)1 x S/PDIF out header(s)1 x 24-pin EATX Power connector(s)1 x 8-pin ATX 12V Power connector(s)1 x Front panel audio connector(s) (AAFP)1 x System panel(s)1 x Clear CMOS jumper(s)
Form FactorATX
Dimensions (W x L)12" x 8.2"
Power Pin24 Pin
FeaturesASUS 5X PROTECTION - All-round protection provides the best quality, reliability, and durabilityNew UEFI BIOS - Friendlier, easier, and more intuitive with helpful info addedFan Xpert 2 - Comprehensive controls for the perfect cool and quiet balanceUSB 3.0 Boost (UASP Support) - 170% faster transfer speeds than traditional USB 3.0Ai Suite 3 - One-stop access to innovative ASUS features
Package ContentsASUS Z87-K MB2 x Serial ATA 6.0Gb/s cables1 x User Manual1 x I/O Shield1 x Support DVD

Questions about this item

Will the four DDR3 slots hit the 32GB ceiling before the CPU throttles under sustained load?

The board supports up to 32GB of DDR3 across four slots; sustained CPU throttling depends on the processor and cooler you install, not the motherboard itself.

How loud and hot does the VRM area get when the system runs all day with Fan Xpert 2 active?

Fan Xpert 2 lets you tune chassis and CPU fan curves for a quiet, cool balance; actual VRM temperature and noise vary with your CPU, case airflow and chosen fan profile.

Which 4th-generation LGA 1150 processor do I need to have already for this board to POST?

Any 4th-generation Core i7, i5, i3, Pentium or Celeron in the LGA 1150 package will work; the board also requires DDR3 memory, a PSU with 24-pin and 8-pin CPU power, and a graphics source if the CPU lacks integrated graphics.
