Compact silver desktop NAS with six M.2 slots and front status LEDs

ASUSTOR

ASUSTOR FS6806X Flashstor Gen2 6-Bay NAS 8GB DDR5

SKU CH-JE2K-KK5MT MPN FS6806X

A six-bay M.2 NVMe NAS with a quad-core 2.3 GHz Ryzen CPU, 8 GB DDR5-4800 ECC RAM, 10 GbE, two USB 4.0 Type-C and three USB 3.2 Gen 2 Type-A ports

  • TypeDesktop NAS
  • Ports1 x 10GbE
  • Port USB2 x USB 4.0 (Type-C)+3 x USB 3.2 Gen 2 (Type-A)
  • Form Factor(1392324)6-Slot (M.2)
  • Operating SystemADM 5.0
  • ProcessorAMD Ryzen
  • Quad-core 2.3 GHz Ryzen CPU handles demanding workloads
  • Six M.2 slots accept PCIe 4.0 x4 NVMe SSDs
  • 10 GbE port delivers high-speed network transfers
  • 8 GB DDR5-4800 ECC RAM ensures data integrity
  • Five USB ports including two USB 4.0 Type-C and three USB 3.2 Gen 2 Type-A

Six-bay M.2 NVMe NAS

The FS6806X is a six-bay desktop NAS built around M.2 NVMe slots instead of traditional drive bays. It runs on an AMD Ryzen V3C14 quad-core processor at 2.3 GHz with 8 GB of DDR5-4800 ECC memory installed. The system supports ADM 5.0 and provides a single 10 GbE port alongside two USB 4.0 Type-C and three USB 3.2 Gen 2 Type-A ports.

Suits flash-only workflows, not spinning-disk arrays

This unit targets users who want all-flash storage for tasks such as 4K editing, virtualization or high-speed caching where low latency matters. It is not suited for buyers who need 3.5-inch hard-drive bays, higher raw capacity per bay, or a lower-cost archive tier based on mechanical drives.

Six M.2 slots with PCIe 4.0 x4 support

The decisive specification is the six M.2 slots, each capable of PCIe 4.0 x4 speeds, which dictates the maximum number of NVMe drives you can install and the peak throughput per drive.

Highlights

  • Quad-core 2.3 GHz Ryzen CPU handles demanding workloads
  • Six M.2 slots accept PCIe 4.0 x4 NVMe SSDs
  • 10 GbE port delivers high-speed network transfers
  • 8 GB DDR5-4800 ECC RAM ensures data integrity
  • Five USB ports including two USB 4.0 Type-C and three USB 3.2 Gen 2 Type-A

Specifications

BrandAsustor
SeriesFlashstor Gen2
ModelFS6806X
TypeDesktop NAS
Ports1 x 10GbE
Port USB2 x USB 4.0 (Type-C)+3 x USB 3.2 Gen 2 (Type-A)
Form Factor(1392324)6-Slot (M.2)
Operating SystemADM 5.0
ProcessorAMD Ryzen
Installed Memory8GB
Max Memory Capacity64GB
Memory Slot2
Included HDD CapacityN/A
Max Capacity48TB
RAIDRAID 0, 1, 5, 6, 10, and JBOD
Environment Remote ControlHDD, cooling fan, CPU temperature, network status
LEDsPower, HDD (Hard Disk Drive), LAN (10/100)
Power100-240 VAC 50/60Hz
Power Consumption68.68W
Temperature0°C - 40 °C
Humidity5-95% R.H
UsageBackup & stream media through personal cloud
Dimensions12.7 x 11.8 x 3.4
Weight5.19
Sports Team4 Piece
Shipping weight2.18 kg
Package size330 × 305 × 89 mm

Questions about this item

Will the 10GbE port on the FS6806X work with my existing 1GbE switch and cabling?

Yes, the 10GbE port auto-negotiates down to 1GbE so it will operate with your current switch and Cat5e or Cat6 cables, simply at the lower speed.

How can I verify the AMD Ryzen V3C14 processor and 8GB DDR5-4800 ECC memory are recognised and healthy after first boot?

Log into ADM 5.0, open System Information and confirm the CPU shows as AMD Ryzen Embedded V3C14 with four cores at 2.3GHz and the memory reads 8GB DDR5-4800 ECC.

The FS6806X arrives diskless — what must I buy separately to populate the six M.2 slots?

You need to purchase up to six M.2 NVMe SSDs that support PCIe 4.0 x4; no drive caddies or screws are required as the slots are tool-less.
