Silver 2U server power supply with dual 60mm fans and front grille

Athena Power

Athena Power AP-2U70P868 700W 2U server power supply

SKU CH-P4GC-HS73H

A 700 W 2U server power supply with dual 60 mm fans, active PFC and connectors for dual Xeon CPUs plus two graphics cards

  • Type2U EPS
  • Single/RedundantSingle
  • Maximum Power700W
  • Main Connector20+4Pin
  • Output Current+3.3V@18A, +5V@20A,12V1/V2@28/28A, [email protected] , [emai
  • Output+3.3V, +5V,12V1/V2, -12V, +5Vsb
  • 700W output powers demanding dual-processor servers
  • 80Plus Platinum efficiency reduces energy waste
  • Dual 60mm fans with thermal control exhaust system heat
  • 90–264V auto-ranging input suits global deployments
  • 250,000-hour MTBF at 25°C ensures 24/7 reliability

700W 2U server power supply

The Athena Power AP-2U70P868 is a single 700W unit built for 2U rackmount servers and industrial PCs that run continuous workloads. It fits IPC chassis where a compact EPS form factor is required and delivers the connectors needed for dual-processor boards. This supply is not for builders who need redundant hot-swap modules or a higher wattage ceiling for dense GPU clusters.

80Plus Platinum efficiency and 90-264V input

Efficiency exceeds 80% across loads, meeting the 80Plus Platinum benchmark, while the wide-range input accepts 90 to 264V at 47 to 63Hz without a voltage selector. Hold-up time is rated at 11ms minimum at nominal voltage, and protections include OCP and OVP on all rails. The unit is not suited for environments that demand 240V-only input or specialized DC-input server racks.

Front-to-rear airflow with dual 60mm fans

Two 60mm ball-bearing fans create a front-to-rear flow that exhausts system heat through the PSU, and a smart controller adjusts fan speed automatically. Standard ATX 20+4 pin, dual EPS 8-pin (one 8-pin and one 4+4-pin), two PCIe 6+2-pin, three SATA and two Molex connectors cover typical server builds. Installers must verify that the 200mm depth clears their chassis rails and that cable routing reaches the motherboard without strain.

Highlights

  • 700W output powers demanding dual-processor servers
  • 80Plus Platinum efficiency reduces energy waste
  • Dual 60mm fans with thermal control exhaust system heat
  • 90–264V auto-ranging input suits global deployments
  • 250,000-hour MTBF at 25°C ensures 24/7 reliability

Specifications

BrandAthena Power
ModelAP-2U70P868
Type2U EPS
Single/RedundantSingle
Maximum Power700W
Main Connector20+4Pin
Output Current+3.3V@18A, +5V@20A,12V1/V2@28/28A, [email protected] , [email protected]
Output+3.3V, +5V,12V1/V2, -12V, +5Vsb
Input Voltage90 - 264 V
Input Frequency Range47 - 63 Hz
Input Current9.0A@110V, 4.5A@ 240V
MTBF250,000 Hours on Maximum Load at +25 degree C
Efficiency> 80%
Hold-up Time11 ms Minimum at Nominal Input Voltage
ProtectionOCP, OVP,
FeaturesRise time: Less than 70 ms
Dimensions(L x W x H) 200 x 100 x 69.7 mm/ 7.87 x 3.93 x 2.74 in
Weight5 lbs
Humidity20%-90%
TemperatureOperating: 0°C ~ +55°C on Full Load; Storage & Shipping: -40°C ~ +70°C

Questions about this item

Which 2U 700W version fits a dual-CPU server?

The AP-2U70P868 is a single 2U 700W unit with one 20+4Pin ATX, one EPS 8Pin and one EPS 8(4+4)Pin connector, so it supports dual processors without needing a redundant module.

What does the 700W rating deliver to the 12V rails in my build?

The two 12V rails each supply up to 28A, giving combined 12V capacity for Xeon CPUs and two graphics cards on the 6+2Pin PCIe connectors.

What does the 80Plus Platinum efficiency mean for my rack's power draw?

Efficiency exceeds 80% at typical loads, so less input current is drawn from the 90-264V supply and waste heat inside the 2U chassis is reduced.
