Silver rectangular server PSU with dual fans and black cables

Athena Power

Athena Power AP-2UMK10P868 1000W 80 PLUS Platinum server power supply

SKU CH-45H5-SJR67

A 1000W ATX 3.1 server power supply with 80 PLUS Platinum efficiency and dual cooling fans

  • TypeATX
  • Single/RedundantSingle
  • Maximum Power1000W
  • Fans2
  • Main Connector24-pin ATX (20+4)
  • Output Current+3.3V 18A, +5V 18A, +12V1/12V2 82A, -12V 0.5A, +5VSB 3.0A
  • 1000W continuous power fuels demanding GPU workloads
  • 80 PLUS Platinum efficiency above 92% cuts energy waste
  • ATX 3.1 and PCIe 5.0 ready with 12V-2x6 connector
  • Dual 60mm smart thermal fans maintain reliable cooling
  • IEC/UL 62368-1 certified with 100000-hour MTBF at 25°C

Industrial U2 1000W server supply

The Athena Power AP-2UMK10P868 is a single 1000W ATX 3.1 power supply built for workstations, edge servers and GPU-intensive platforms. It delivers continuous output with a 12V-2x6 connector for modern graphics cards and includes dual EPS 8-pin plus 8(4+4)-pin CPU connectors for dual-processor boards. The unit carries 80 PLUS Platinum certification and active PFC across a universal 100-240V input range.

Dual 60mm thermal-controlled cooling

Two ball-bearing fans adjust speed based on internal temperature, keeping the supply within its 0 to 50°C operating window while MTBF is rated at 100,000 hours at 25°C and full load. Efficiency exceeds 92 percent at typical loads, reducing waste heat and acoustic output compared to lower-rated units. Protections include OVP and OCP, and hold-up time is 17 ms at nominal input.

Replaces older ATX 3.0 or 2.x units lacking 12V-2x6

The jump is worthwhile when a build needs the PCIe 5.0 GPU connector, dual CPU power for server boards, or Platinum-grade efficiency for 24/7 operation. Builds staying on a single mid-range GPU with standard 8-pin power and no redundant supply requirement will not use the extra connectors or efficiency headroom.

Highlights

  • 1000W continuous power fuels demanding GPU workloads
  • 80 PLUS Platinum efficiency above 92% cuts energy waste
  • ATX 3.1 and PCIe 5.0 ready with 12V-2x6 connector
  • Dual 60mm smart thermal fans maintain reliable cooling
  • IEC/UL 62368-1 certified with 100000-hour MTBF at 25°C

Specifications

BrandAthena Power
SeriesU2
ModelAP-2UMK10P868
TypeATX
Single/RedundantSingle
Maximum Power1000W
Fans2
Main Connector24-pin ATX (20+4)
Output Current+3.3V 18A, +5V 18A, +12V1/12V2 82A, -12V 0.5A, +5VSB 3.0A
Output1000W
Input Voltage100 - 240 V
Input Frequency Range50 - 60 Hz
Input Current13A@110V, 6A@ 240V
MTBF100,000 Hours on Maximum Load at +25 degree C
Efficiency> 92%
Hold-up Time17 ms Minimum at Nominal Input Voltage
ProtectionOVP, OCP
Features1000W output, 80 PLUS Platinum efficiency, ATX 3.1 / PCIe 5.0 compatible, dual cooling fans, EPS-12V CPU support, low ripple, active PFC, IEC/UL 62368-1 certified, RoHS, 5-Year warranty
Dimensions(D x W x H)200 × 100 × 69.7?mm (7.87 × 3.93 × 2.75?in)
Weight5 lbs
HumidityOperating Humidity: 5–85% RH, non-condensing, Storage Humidity: 5–95% RH, non-condensing
TemperatureOperating: 0°C ~ +50°C on Full Load; Storage & Shipping: -20°C ~ +80°C

Questions about this item

How do I install the 24-pin ATX and 12V-2x6 connectors without bending pins?

Align the 24-pin ATX (20+4) and 12V-2x6 GPU connectors squarely before pressing; the keyed shapes prevent reverse insertion. Route cables behind the motherboard tray first, then seat each connector firmly until the latch clicks. Do not force angled insertion — bent pins on the 12V-2x6 can cause 12V rail instability.

Which components need replacement first during long-term 24/7 operation?

The dual 60mm ball-bearing fans are the primary wear items; MTBF is rated 100,000 hours at 25 °C full load. Dust buildup reduces airflow, so clean fan blades and heatsink fins every 6-12 months. Electrolytic capacitors on the secondary side may drift after 5-7 years of continuous 1000W operation.

What thermal limit appears first when the unit runs at 1000W continuously?

At sustained 1000W the +12V rail delivers 82A and internal temperatures rise until the smart thermal control ramps both fans to maximum. The 50 °C operating-temperature ceiling is reached before any protection triggers; hold-up time remains 17 ms. Ensure chassis airflow keeps intake air below 40 °C to avoid throttling.
