Black rectangular ATX power supply with 120mm fan and modular cable sockets

BGears

BGears b-GoldX 1200W power supply

SKU CH-4QD2-H1PST MPN b-GoldX 1200W

A 1200W semi-modular power supply with 80+Gold efficiency, ATX 3.1 and PCIe 5.1 support, plus a 16-pin 12VHPWR connector for modern GPUs

  • ColorBlack
  • Fans120mm (2000 RPM)
  • Main Connector20+4Pin
  • +12V RailsP16 (12+4)pin 12VHPWR
  • PCI-Express Connector4 x 6+2-Pin
  • SATA Power Connector5
  • 80+ Gold equivalent efficiency at 20, 50 and 100 per cent load
  • ATX 3.1 and PCIe 5.1 compliance for modern platforms
  • 16-pin 12VHPWR connector delivers up to 600 W to a GPU
  • Semi-modular design with black flat ribbon cables eases cable management
  • Comprehensive protection suite includes over power, short circuit, over voltage, under voltage, surge and over current protection

1200W ATX 3.1 power supply

The BGears b-GoldX 1200W is an ATX 3.1 compliant unit rated for 1200W continuous output. It targets builders assembling high-end workstations or enthusiast gaming rigs that demand substantial 12V headroom. The semi-modular design uses black flat ribbon cables to simplify routing and improve internal airflow.

120mm fan and protection suite

A 120mm fan spinning at 2000 RPM handles cooling across the 115V to 230V input range. The unit carries 80+Gold equivalent efficiency at 20, 50 and 100 percent load. Protections include active power factor correction, over power, short circuit, over voltage, under voltage, surge and over current safeguards.

12VHPWR connector for modern GPUs

The native 16-pin 12VHPWR cable delivers up to 600W to a single graphics card, while four 6+2-pin PCIe connectors and five SATA plugs cover additional components. Builders upgrading from older ATX 2.x units gain PCIe 5.1 readiness without adapters. Systems that do not require a 12VHPWR connection or 1200W capacity will not benefit from the added cost.

Highlights

  • 80+ Gold equivalent efficiency at 20, 50 and 100 per cent load
  • ATX 3.1 and PCIe 5.1 compliance for modern platforms
  • 16-pin 12VHPWR connector delivers up to 600 W to a GPU
  • Semi-modular design with black flat ribbon cables eases cable management
  • Comprehensive protection suite includes over power, short circuit, over voltage, under voltage, surge and over current protection

Specifications

BrandBluegears
Modelb-GoldX 1200W
Part Numberb-GoldX 1200W
ColorBlack
Fans120mm (2000 RPM)
Main Connector20+4Pin
+12V RailsP16 (12+4)pin 12VHPWR
PCI-Express Connector4 x 6+2-Pin
SATA Power Connector5
Max PSU Length600mm
Overload ProtectionYes
ProtectionActive Power Factor Correction
Over Power Protection
Short Circuit Protection
Over Voltage Protection
Under Voltage Protection
Surge Protection Device
Over Current Protection
Shipping weight1.81 kg
Package size152 × 152 × 102 mm

Questions about this item

How do I install the 12VHPWR connector so the sense pins seat fully?

Push the 16-pin 12VHPWR plug straight into the GPU until the latch clicks; the four sense pins are shorter and will not engage if the connector is angled or stopped early.

Which component will likely need replacement first during long-term use?

The 120 mm fan rated at 2000 RPM is the only moving part; bearing wear over years of continuous operation is the typical replacement point.

What limit appears first when the unit runs at high load for extended periods?

The 1200 W maximum output is the hard ceiling; sustained draws above that trigger over-power protection and shut the supply down.
