Small green M.2 2242 circuit board with black chips and gold edge connector

BIWIN STORAGE TECHNOLOGY LIMITED

BIWIN STORAGE TECHNOLOGY LIMITED 120GB MLC SATA M.2 2242 internal SSD

SKU CH-CN6Q-XZGYM

A 120GB M.2 2242 SATA internal SSD with MLC flash delivering up to 500 MBps read and 450 MBps write speeds

  • Device TypeInternal Solid State Drive (SSD)
  • Form FactorM.2 2242
  • Capacity120GB
  • Memory ComponentsMLC
  • Max Sequential ReadUp to 500 MBps
  • Max Sequential WriteUp to 450 MBps

Options 120GB

  • MLC flash delivers sustained speed and endurance
  • Sequential read reaches 500 MBps for fast boot and load times
  • Sequential write hits 450 MBps to move large files quickly
  • Idle power of 0.27W extends laptop battery life
  • Shock rated at 50G and vibration at 3.1G protects data on the move

Compact M.2 2242 form factor

This BIWIN internal SSD fits the M.2 2242 slot and provides 120GB of MLC flash storage. It connects through a SATA III 6Gb/s interface for broad laptop and small-form-factor desktop compatibility.

Sustained workload behaviour

Sequential reads reach up to 500 MBps and writes up to 450 MBps while active power draw stays at 1.97W. The drive operates from 0°C to 70°C and is rated for 50G shock and 3.1G vibration resistance.

Installation notes

The 42mm by 22mm by 3.2mm card weighs 5.4g and uses a single keyed notch, so it inserts directly into the slot without cables. Ensure the motherboard BIOS recognises SATA M.2 devices; some platforms only support PCIe signalling on this connector.

Highlights

  • MLC flash delivers sustained speed and endurance
  • Sequential read reaches 500 MBps for fast boot and load times
  • Sequential write hits 450 MBps to move large files quickly
  • Idle power of 0.27W extends laptop battery life
  • Shock rated at 50G and vibration at 3.1G protects data on the move

Specifications

BrandBIWIN
Device TypeInternal Solid State Drive (SSD)
Form FactorM.2 2242
Capacity120GB
Memory ComponentsMLC
Max Sequential ReadUp to 500 MBps
Max Sequential WriteUp to 450 MBps
Power Consumption (Idle)0.27W (Idle)
Power Consumption (Active)1.97W
Operating Temperature0°C to 70°C
Storage Temperature-40°C to 85°C
Operating Humidity5% to 95%
Max Shock Resistance50G,11ms, half-sine wave
Max Vibration Resistance3.1G(2-500Hz)
Height42mm
Width22mm
Depth3.2mm
Weight=5.4g

Other versions of this model

1 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How hot and power-hungry is the 120GB MLC SATA M.2 2242 drive during all-day use?

It draws 0.27W at idle and 1.97W active, with an operating range of 0°C to 70°C and a 2 million hour MTBF rating.

What must my motherboard provide for this M.2 2242 SATA III 6Gb/s SSD to function?

A 2242-length M.2 slot wired for SATA III 6Gb/s and 3.3V ±5% power; the drive measures 42mm × 22mm × 3.2mm and weighs 5.4g.

Will this SATA III 6Gb/s M.2 2242 drive work alongside my older SATA 3Gb/s 2.5-inch SSD?

Yes, it runs on the same SATA III 6Gb/s interface and is backward compatible with SATA 3Gb/s ports, delivering up to 500 MB/s read and 450 MB/s write.
