Black metal 2U rack DVR unit with front panel controls and drive bays

Bluecctv

Bluecctv BL-TD2524HDC-1TB 24CH 960H DVR surveillance security system

SKU CH-NXM9-43XM3

A 24-channel 960H DVR records real-time at 720 fps using H.264 compression and provides HDMI 1920x1080 output with eight SATA bays supporting up to 16 TB

  • TypeStandalone DVR
  • Camera inputs24CH
  • Video Input24CH
  • Audio Input1 x RCA
  • Resolution Recording960H 720FPS
  • Recording Frame RateReal Time
  • Real-time 960H recording across 24 channels at 720 FPS
  • H.264 compression keeps footage clear while saving storage space
  • HDMI output delivers 1920x1080 display for sharp monitoring
  • Eight SATA bays support up to 16 TB total capacity
  • Gigabit Ethernet enables fast remote access and backup

24-Channel 960H DVR for Multi-Camera Sites

The Bluecctv BL-TD2524HDC-1TB is a standalone digital video recorder that accepts 24 camera inputs and records every channel at 960H resolution in real time. It uses H.264 compression and ships with a 1 TB hard drive installed. The unit is designed for installations that need continuous recording across many entry points without dropping frames.

Rack-Mount Chassis with Eight SATA Bays

The recorder fits a standard 2U rack space and provides eight internal SATA ports that support up to 16 TB of total storage. Video outputs include HDMI, VGA and a single BNC connector, while audio uses one RCA input and one RCA output. Network connectivity is handled by a gigabit RJ45 port; configuration is performed through a mouse-driven GUI or the supplied remote.

Sustained Recording with Dual-Stream Encoding

Dual-stream technology separates the high-quality recording stream from the lower-bitrate network stream, so remote viewing does not degrade the stored footage. The system can play back 16 channels simultaneously while continuing to record all 24 inputs. Motion, sensor, timer and manual triggers all write to the disks without interrupting the live preview.

Highlights

  • Real-time 960H recording across 24 channels at 720 FPS
  • H.264 compression keeps footage clear while saving storage space
  • HDMI output delivers 1920x1080 display for sharp monitoring
  • Eight SATA bays support up to 16 TB total capacity
  • Gigabit Ethernet enables fast remote access and backup

Specifications

BrandBluecctv
SeriesEnterprise
ModelBL-TD2524HDC-1TB
TypeStandalone DVR
Camera inputs24CH
Video Input24CH
Audio Input1 x RCA
Resolution Recording960H 720FPS
Recording Frame RateReal Time
Recording Modemanual/timer/motion/sensor
Recording CompressionH.264 Level
Video Output1 x BNC, 1 x VGA, 1 x HDMI
Audio Output1 x RCA
Resolution DisplayMI 1920x1080 output
Display Frame Rate720FPS
Storage Capacity8 x SATA,up to 16TB
Backup DeviceDVDRW ( Optional ), USB
Network ConnectionRJ45 Giga ethernet (1,000Mbps)
Network ProtocolTCP/IP, UDP, DHCP, DNS, PPPOE, DDNS,Email
Features960H Real Time Recording
Operating SystemEmbedded Linux
Power SupplyAC 100V - 240V
System RequirementCamera , Wires , Monitor or TV
Remote ControlYes
Bundled Camera NumberNone
Weight8 KG

Questions about this item

How do I confirm the DVR is recording all 24 channels at 960H resolution in real time?

Check the live view and playback menus; each channel should show 960H at 720FPS, and the recording status icons will display continuous capture for manual, timer, motion or sensor modes.

What comes in the box and what must I purchase separately to run the system?

The unit includes the 24CH DVR with a pre-installed 1TB HDD and DVD-RW drive; you must supply the 24 cameras, BNC cables, power adapters, a monitor for HDMI or VGA, and a network cable for the RJ45 Giga ethernet port.

Which storage configuration should I choose for longer retention across all channels?

The chassis accepts up to 8 SATA drives with a maximum of 16TB total; adding more drives or higher-capacity SATA disks extends recording time before overwrite.
