Small silver square mini PC barebone with front ports

BRENUC

BRENUC BREB i7-1260P barebone mini PC

SKU CH-CDE2-SCE2Y

A barebone mini PC with a 12-core Intel Core i7-1260P, dual-channel DDR5-4800 support up to 64 GB, Thunderbolt 4, 2.5 GbE, Wi-Fi 6 and Intel Iris Xe graphics

  • CPU TypeIntel Core i7-1260P
  • Memory slot2 x 288Pin DIMM
  • Memory Type SupportedDDR5 4800
  • Max Memory Supported64GB
  • Dual Channel Memory SupportedYes
  • Serial ATA1 x SATA 3.0Gb/s
  • 12-core 16-thread i7-1260P handles heavy multitasking
  • Dual-channel DDR5-4800 up to 64 GB for fast memory
  • 5 GbE plus Wi-Fi 6 and Bluetooth 5.2 for quick networking
  • Dual HDMI and Thunderbolt 4 drive up to four 4K displays
  • Compact 136 x 123 x 55 mm chassis fits tight spaces

Ready-to-build mini PC with Core i7-1260P

This barebone system ships with a 12-core Intel Core i7-1260P processor already installed. It targets builders who want a compact desktop foundation for office work, media playback or light content creation. You add DDR5 memory and storage to match the workload.

Dual-channel DDR5 slots

The chassis provides two 288-pin DIMM sockets supporting DDR5-4800 in dual-channel mode up to 64 GB. A PCIe Gen4 x4 M.2 slot takes 2280 drives while a second M.2 slot accepts 2242 PCIe Gen3 x1 or SATA devices. Front I/O includes two USB 3.2 Gen2 Type-A ports, one USB 2.0 Type-C port and a 3.5 mm audio jack. Rear video uses dual HDMI 2.0 plus a Thunderbolt 4 Type-C connector, and a 2.5 GbE Intel i226V LAN port sits alongside Wi-Fi 6 and Bluetooth 5.2.

Replaces larger towers for multi-display setups

Integrated Iris Xe graphics drives up to four 4K 60 Hz displays, letting this unit serve digital-signage or multi-monitor productivity roles that previously needed a full-size PC. The 120 W adapter powers the complete platform without an internal PSU. Buyers who need discrete GPU performance or more than two M.2 slots should look elsewhere.

Highlights

  • 12-core 16-thread i7-1260P handles heavy multitasking
  • Dual-channel DDR5-4800 up to 64 GB for fast memory
  • 5 GbE plus Wi-Fi 6 and Bluetooth 5.2 for quick networking
  • Dual HDMI and Thunderbolt 4 drive up to four 4K displays
  • Compact 136 x 123 x 55 mm chassis fits tight spaces

Specifications

BrandBRENUC
SeriesBREB
ModelBREB i7-1260P
CPU TypeIntel Core i7-1260P
Memory slot2 x 288Pin DIMM
Memory Type SupportedDDR5 4800
Max Memory Supported64GB
Dual Channel Memory SupportedYes
Serial ATA1 x SATA 3.0Gb/s
M.2 Slot1 x M.2
Discrete Graphic CardIntel® Iris® Xe Graphics
Onboard AudioIntegrated
Channel7.1 Channel
LANIntel i226V
Max LAN Speed2.5Gbps
Wireless LAN802.11ax
WiFi GenerationWi-Fi 6
BluetoothBluetooth 5.2
Front USB2 * USB 3.2 Gen2(10Gbps) Type-A ports
1 * USB 2.0 Type-C port
Front Audio Ports3.5mm Audio Jack
HDMI2 * HDMI 2.0,
Thunderbolt2 * Type-C Full Function (Thunderbolt™ 4 ports ) ports
Rear USB1 * USB 3.2 Gen2(10Gbps) Type-A port
1 * USB 2.0 Type-A port
RJ451 x 2.5Gb RJ45
Other Rear Ports1 * Kensington Lock (right side of Chassis)
Input19VDC /6.32
Power Supply120W
Dimensions136mm*123mm*51mm
PackagingIndividual retail box packaging

Questions about this item

What display resolution does the dual HDMI 2.0 output support?

The dual HDMI 2.0 ports each support 4K resolution at 60Hz, allowing up to four displays when combined with the Thunderbolt 4 and USB Type-C video outputs.

What size DDR5 modules fit the two 288-pin DIMM slots?

The board accepts standard 288-pin DDR5 4800 DIMMs up to 64GB total in dual-channel configuration; laptop SO-DIMMs will not fit.

How is the M.2 B-key expansion slot used for extra Ethernet or USB?

Insert a compatible M.2 B-key card into the internal slot and secure it with the mounting screw; the slot provides PCIe Gen3 x1 and USB 2.0 signals for additional 2.5GbE or USB 2.0 ports.
