Green 288-pin DDR4 RDIMM module with black memory chips and gold contacts

Brute Networks

Brute Networks 16GB DDR4-2133 ECC Registered RDIMM 2Rx4 CL15 1.20V

SKU CH-CAZ1-GHPTB

16 GB DDR4-2133 ECC registered RDIMM with CL15 latency and 1.20 V operation

  • Capacity16GB
  • Type288-Pin DDR4 SDRAM
  • SpeedDDR4 2133 (PC4 17000)
  • CAS LatencyCL15
  • Voltage1.20V
  • ECCYes
  • ECC protection prevents data corruption with registered design
  • 16GB capacity expands server memory for more virtual machines
  • DDR4-2133 speed delivers PC4-17000 bandwidth for responsive applications
  • 20V operation reduces power draw versus older DDR generations
  • 2Rx4 dual-rank layout increases memory density per slot

16GB DDR4-2133 ECC Registered RDIMM

This 16GB DDR4-2133 module uses a 288-pin RDIMM form factor with ECC and registered buffering. It operates at CL15 latency and 1.20V voltage. The 2Rx4 rank configuration suits server platforms that require registered memory.

Suits admins expanding IBM-compatible servers

This module fits administrators upgrading IBM systems using part 00FM012 or equivalent DDR4-2133 registered DIMMs. It is not for desktop PCs or workstations that accept only unbuffered non-ECC UDIMMs. Buyers needing higher speeds or different densities should verify their platform specifications first.

Check motherboard supports DDR4-2133 registered ECC

Confirm the server motherboard accepts 288-pin DDR4 RDIMMs at 2133 MT/s with CL15 timing and 1.20V operation. Verify the maximum supported capacity per slot and total system limit. Ensure the BIOS recognises registered ECC modules and that the 2Rx4 organisation matches the memory controller requirements.

Highlights

  • ECC protection prevents data corruption with registered design
  • 16GB capacity expands server memory for more virtual machines
  • DDR4-2133 speed delivers PC4-17000 bandwidth for responsive applications
  • 20V operation reduces power draw versus older DDR generations
  • 2Rx4 dual-rank layout increases memory density per slot

Specifications

BrandIBM
Capacity16GB
Type288-Pin DDR4 SDRAM
SpeedDDR4 2133 (PC4 17000)
CAS LatencyCL15
Voltage1.20V
ECCYes
Buffered/RegisteredRegistered
Rank2Rx4
ChipsetMajor Brand Chipset

Questions about this item

Does my server need a 288-pin DDR4 slot and support for registered ECC memory to use this 16GB RDIMM?

Yes, this module requires a 288-pin DDR4 slot that accepts registered ECC RDIMMs running at 1.20V with CL15 timing.

Can I mix this 2Rx4 PC4-17000 module with existing single-rank DDR4-2133 RDIMMs in the same channel?

Mixing ranks is often supported but the system will typically run all modules at the speed and voltage of the slowest DIMM; check your server's memory population rules.

How do I confirm the module is detected as 16GB of ECC registered memory at DDR4-2133 after installation?

Enter the BIOS or use a tool like dmidecode; you should see 16GB, type DDR4, speed 2133 MT/s, ECC enabled and registered mode reported for the slot.
