Green circuit board with black memory chips and gold edge connectors

Brute Networks

Brute Networks 16GB DDR4-3200 2Rx8 1.2V UDIMM server RAM

SKU CH-D9SB-KQF88

16 GB DDR4-3200 ECC UDIMM running at 1.2 V with 2Rx8 organisation for Dell-compatible servers

  • Capacity16GB
  • Type288-Pin DDR4 SDRAM
  • SpeedDDR4 3200 (PC4 25600)
  • Voltage1.20V
  • ECCYes
  • Buffered/RegisteredUnbuffered
  • 16 GB DDR4-3200 boosts server throughput
  • 2Rx8 dual-rank layout increases memory density
  • 2 V operation reduces power draw
  • 288-pin UDIMM fits standard DDR4 slots
  • Major-brand chips ensure Dell-compatible reliability

16GB DDR4-3200 UDIMM for Dell servers

This 16GB DDR4-3200 UDIMM is built for Dell servers that accept unbuffered non-ECC memory. It runs at PC4-25600 speed with a 1.20V operating voltage. The module uses a 2Rx8 organisation and major-brand DRAM chips. It is designed as a direct replacement for Dell part SNPC5N22C/16G.

Check your platform before ordering

Verify that your server supports 288-pin DDR4 UDIMMs and does not require registered or load-reduced modules. Confirm the memory slots accept 1.20V operation and 3200 MT/s speed. Ensure the system can use non-ECC unbuffered DIMMs rather than ECC or registered types. Matching modules will be supplied for multi-DIMM configurations.

Fits standard DDR4 UDIMM slots

The module installs in any 288-pin DDR4 UDIMM slot wired for 1.20V unbuffered operation. It frees you from sourcing OEM-labelled sticks while keeping factory warranty coverage. Identical modules ship together so multi-channel populations stay matched. No extra cooling or power connections are required beyond the slot itself.

Highlights

  • 16 GB DDR4-3200 boosts server throughput
  • 2Rx8 dual-rank layout increases memory density
  • 2 V operation reduces power draw
  • 288-pin UDIMM fits standard DDR4 slots
  • Major-brand chips ensure Dell-compatible reliability

Specifications

BrandDell
Capacity16GB
Type288-Pin DDR4 SDRAM
SpeedDDR4 3200 (PC4 25600)
Voltage1.20V
ECCYes
Buffered/RegisteredUnbuffered
Rank2Rx8
ChipsetMajor Brand Chipset

Questions about this item

Does the box contain only the memory module or are extra items included?

The package includes a single 16 GB DDR4 288-pin UDIMM rated at 3200 MT/s with 1.20 V operation and 2Rx8 organisation. No cables, brackets or additional components are supplied.

Should I choose the 16 GB 2Rx8 version or a different capacity for my Dell server?

This part is the 16 GB 2Rx8 module matching Dell part SNPC5N22C/16G; select it when your configuration calls for that exact density and rank. Other capacities carry different part numbers and are not covered by this listing.

What does the PC4-25600 rating mean once the module is installed in a compatible system?

PC4-25600 indicates a peak transfer rate of 25 600 MB/s at the rated 3200 MT/s data rate; the module will operate at that speed when the platform supports DDR4-3200, otherwise it will downshift to the highest speed the platform allows.
