Buffalo LinkStation SoHo 220 2-bay desktop NAS in black finish

Buffalo Technology

Buffalo Technology LS220D0402B 2-Bay NAS 4TB (2x2TB)

SKU CH-MNT4-7RG7X MPN LS220D0402B

Two-bay desktop NAS with 4 TB pre-installed in RAID 1, 1 GbE LAN, USB 2.0, and 256 MB DDR3

  • TypeDesktop NAS
  • StandardsIEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-TX), IEEE 802.3a
  • Ports1 x 1GbE
  • Port RJ-451 x 10/100/1000M
  • Port USB1 x USB2.0
  • HDD InterfaceSATA 3 Gbps

Capacity 4TB (2 x 2TB)

  • Secure personal cloud with closed system limiting third-party vulnerabilities
  • RAID 1 ships pre-configured for redundancy and 2TB usable capacity
  • 1GbE and USB 2.0 ports for wired network and direct copy
  • Subscription-free file storage and backup with no monthly fees
  • 256MB DDR3 memory and dual-issue ARM 800MHz processor

Secure personal cloud NAS

The Buffalo LinkStation SoHo 220 is a two-bay desktop NAS that ships with two 2 TB drives for 4 TB raw capacity. It targets home offices and small businesses that want a subscription-free personal cloud with hardware RAID redundancy out of the box.

Build integration

The unit connects through a single gigabit Ethernet port and a USB 2.0 port for additional storage or printer sharing. A closed operating system limits third-party software exposure while supporting FTPS, FTP, AFP and CIFS/SMB for broad client compatibility. RAID 0, 1 and JBOD modes let the builder choose between performance, mirroring or simple spanning.

Sustained-load behaviour

The 800 MHz dual-issue ARM processor and 256 MB DDR3 memory deliver steady throughput for everyday file transfers and automated backups. Maximum power draw is 48 W within a 5 °C to 35 °C operating range. The manufacturer notes that the LS SoHo 720 offers higher performance and 2.5 GbE connectivity for heavier workloads.

Highlights

  • Secure personal cloud with closed system limiting third-party vulnerabilities
  • RAID 1 ships pre-configured for redundancy and 2TB usable capacity
  • 1GbE and USB 2.0 ports for wired network and direct copy
  • Subscription-free file storage and backup with no monthly fees
  • 256MB DDR3 memory and dual-issue ARM 800MHz processor

Specifications

BrandBUFFALO
SeriesLinkStation SoHo 220
ModelLS220D0402B
Part NumberLS220D0402B
TypeDesktop NAS
StandardsIEEE 802.3 (10BASE-T), IEEE 802.3u (100BASE-TX), IEEE 802.3ab (1000BASE-T), AUTO-MDIX
Ports1 x 1GbE
Port RJ-451 x 10/100/1000M
Port USB1 x USB2.0
HDD InterfaceSATA 3 Gbps
Form Factor2-Bay
Operating SystemWindows® 11 (32-bit/64-bit)
Windows® 10
Windows® 8.1 (32-bit/64-bit)
Windows® 8 (32-bit/64-bit)
Windows® 7 (32-bit/64-bit)
Windows Vista® (32-bit/64-bit)
Windows Server® 2012 R2
Windows Server® 2012
Windows Server® 2008 R2
Windows Server® 2008
Windows Server® 2003
Mac OS® X up to 10.12 or later
ProcessorDual Issue ARM 800MHz Processor
Installed Memory256MB DDR3
Included HDD Capacity4TB (2 x 2TB)
RAIDRAID 0, 1 and JBOD
Supported ProtocolsTCP/IP
Power100-240 VAC 50/60Hz
Power Consumption48W Max
Temperature5°C - 35 °C
Humidity20-80% Humidity (non-condensing)
Dimensions8.07 x 3.42 x 5.02 in
Weight5.5 lbs.
Package ContentsLinkStation™ SoHo 220, Quick setup guide, Ethernet cable, AC adapter, AC cable, Warranty Statement
Shipping weight2.22 kg
Package size259 × 229 × 130 mm

Other versions of this model

2 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Does the 1GbE port limit sustained transfer speeds?

The single 1GbE port caps network throughput at 1000 Mbps, so sustained reads and writes cannot exceed that link speed.

What is the maximum power draw and operating temperature range?

Maximum power consumption is 48W and the operating temperature range is 5°C to 35°C.

Are the two 2TB drives already installed and configured?

The unit ships with two 2TB SATA drives pre-installed in RAID 1, giving 2TB usable capacity.
