Green circuit board with two RJ45 ports and metal bracket

C&N

C&N SAE-TXA094 Dual-Port PCIe Gigabit Network Card

SKU CH-3YNT-YY9KV

Adds two Gigabit Ethernet ports via PCI Express 3.0 using an Intel 82576 controller with 9.5K jumbo frame and VLAN support

  • Speed1000 megabytes_per_second
  • Interfacepci_express_3.0
  • BUSpci_express_3.0
  • FeaturesDesktop
  • Weight0.091 kilograms
  • Adds two Gigabit Ethernet ports via PCI Express 3.0
  • Intel 82576 dual-port controller handles 1000 Mbps traffic
  • Works in x1, x4, x8 or x16 slots with low-profile bracket
  • Supports 9.5 KB jumbo frames, VLAN tagging and IEEE 802.3x flow control
  • Compatible with Windows, Linux and FreeBSD operating systems

Dual-Port Gigabit Adapter

The C&N SAE-TXA094 adds two 10/100/1000 Mbps RJ45 Ethernet ports to a desktop, server or workstation through a PCI Express slot. It uses the Intel 82576 controller and complies with IEEE 802.3, 802.3u and 802.3ab standards. A half-height bracket is included for small-form-factor installations. The card supports PXE network boot and IPv6 wake-up filters.

Suits Multi-Network Segments

Builders who need separate LAN segments, link aggregation or a dedicated management interface on a single slot will benefit from the dual-port design. The adapter fits PCIe x1, x4, x8 and x16 slots and runs on Windows XP through 10, Linux and FreeBSD. Buyers who only require a single Gigabit connection or who lack an available PCI Express slot should consider other options.

Steady Throughput Under Load

Hardware checksum offload for IPv4, IPv6, TCP and UDP reduces CPU utilisation during sustained transfers. Jumbo frames up to 9.5 KB lower per-packet overhead on compatible switches. Flow control per IEEE 802.3x and RMON statistics help maintain consistent throughput during prolonged heavy traffic rather than brief bursts.

Highlights

  • Adds two Gigabit Ethernet ports via PCI Express 3.0
  • Intel 82576 dual-port controller handles 1000 Mbps traffic
  • Works in x1, x4, x8 or x16 slots with low-profile bracket
  • Supports 9.5 KB jumbo frames, VLAN tagging and IEEE 802.3x flow control
  • Compatible with Windows, Linux and FreeBSD operating systems

Specifications

BrandC&N
ModelSAE-TXA094
Part NumberSAE-TXA094
Speed1000 megabytes_per_second
Interfacepci_express_3.0
BUSpci_express_3.0
FeaturesDesktop
Weight0.091 kilograms

Questions about this item

What type of PCI Express slot does the SAE-TXA094 require to operate?

It works in any PCI Express x1, x4, x8 or x16 slot that follows the PCIe 2.0 specification at 2.5 or 5 GT/s.

Will the Intel 82576 controller run on a Windows 7 machine that I still use?

Yes, the card supports Windows XP, 7, 8, 8.1 and 10, plus Linux and FreeBSD.

How can I confirm the dual-port card is passing traffic at gigabit speed after installation?

Check that the link and activity LEDs on both RJ45 ports light up and show negotiated 1000 Mbps full-duplex operation.
