Black tower CPU cooler with six copper heat pipes, aluminium fins, top cover and dual 120 mm PWM fans

Cooler Master

Cooler Master Hyper 612 APEX MAP-T6PN-225PK-R1 CPU cooler

SKU CH-JPB6-0K37Q MPN MAP-T6PN-225PK-R1

Six copper heat pipes and dual 120 mm PWM fans cool high-end CPUs on AM5, AM4, LGA 1700 and LGA 1851 sockets at up to 75.2 CFM and 30 dB(A) in a 159 mm tower

  • TypeFan only
  • RPM0 – 2400 RPM ± 10%
  • LEDNon LED
  • Air Flow75.2 CFM (127.6 m³/h )
  • Noise Level30 dB(A)
  • Power Connector4-Pin(PWM)
  • Six heat pipes and copper base cool high-end CPUs effectively
  • Dual Mobius 120 fans deliver 75.2 CFM airflow at 30 dB(A) noise
  • PWM control adjusts fan speed from 0 to 2400 RPM for balance
  • Simplified brackets enable quick installation on AM5/AM4 and LGA 1700/1851
  • 159 mm height fits most mid-tower cases with clearance

High-Performance Tower Cooler for Enthusiast Builds

The Cooler Master Hyper 612 APEX is a dual-fan tower air cooler built around six superconducting composite heat pipes and a direct-contact copper base. It uses two Mobius 120 PWM fans with a ring-blade design and loop dynamic bearings to deliver 75.2 CFM of airflow at a maximum of 2400 RPM. The unit stands 159 mm tall and fits LGA 1831, 1700, 1200, AM5 and AM4 sockets.

Ideal for High-TDP Chips in Mid-Tower Cases

This cooler targets builders running high-heat CPUs who want strong thermal headroom without moving to liquid cooling. The simplified mounting brackets make installation straightforward on supported Intel and AMD platforms. It is not for small-form-factor builds where a 159 mm tower exceeds case clearance, nor for users who require addressable RGB lighting on the fans.

159 mm Height Dictates Case Compatibility

The single specification that decides fitment is the 159 mm overall height. Buyers must confirm their chassis lists a CPU cooler clearance of at least this figure; if the case allows less, this cooler cannot be installed regardless of socket support.

Highlights

  • Six heat pipes and copper base cool high-end CPUs effectively
  • Dual Mobius 120 fans deliver 75.2 CFM airflow at 30 dB(A) noise
  • PWM control adjusts fan speed from 0 to 2400 RPM for balance
  • Simplified brackets enable quick installation on AM5/AM4 and LGA 1700/1851
  • 159 mm height fits most mid-tower cases with clearance

Specifications

BrandCOOLER MASTER
ModelHYPER 612 APEX
Part NumberMAP-T6PN-225PK-R1
TypeFan only
RPM0 – 2400 RPM ± 10%
LEDNon LED
Air Flow75.2 CFM (127.6 m³/h )
Noise Level30 dB(A)
Power Connector4-Pin(PWM)
Heatsink Material6 SCHPs Heat Pipes / Direct Contact / Aluminum Fins
CPU Socket CompatibilityLGA 1831 / 1700 / 1200 sockets
AM5 / AM4 sockets
Pressure3.63 mmH2O
Max CPU Cooler Height159 mm
FeaturesCooler Master’s all-new CPU air cooler, the Hyper 612 APEX, has been designed with high-performance machine in mind and comes packed with all the benefits necessary to support such a beast. With premium features such as in-house designed Super conductive composite heat pipes, a black out stealth design, an enhanced visual design, easy installation, Dual Mobius 120P fans, and extra clearance
Shipping weight1.86 kg
Package size229 × 178 × 178 mm

Questions about this item

How do I verify the Hyper 612 APEX is cooling properly after installation?

Check that fan speed ramps up to 2400 RPM under load, CPU temperatures stay within the processor's thermal limits, and the 75.2 CFM airflow moves freely through the 6 heat-pipe heatsink without obstruction.

What comes in the box with the MAP-T6PN-225PK-R1 and what must I buy separately?

The package includes the dual 120 mm Mobius fans, 6 copper heat-pipe tower, mounting brackets for AM5/AM4 and LGA 1851/1700/1200/1831, and thermal paste; no separate purchase is required for standard installation.

Which version of the Hyper 612 APEX should I choose for my build?

Only one version exists — MAP-T6PN-225PK-R1 with dual 120 mm PWM fans, 6 heat pipes, 159 mm height, non-LED black finish, and compatibility across current AMD and Intel desktop sockets.
