A bare M.2 2280 circuit board, green with black chips, no heatsink attached

Corsair

Corsair CSSD-F1000GBMP700R2 MP700 1TB internal SSD

SKU CH-656M-GXVG5 MPN CSSD-F1000GBMP700R2

A 1TB M.2 2280 internal SSD using PCI-Express 5.0 x4 with NVME protocol, delivering up to 9500 MBps read and 8500 MBps write speeds

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity1TB
  • Memory Components3D TLC
  • InterfacePCI-Express 5.0 x4
  • Sequential reads reach 9500 MBps via PCIe 5.0 x4
  • Sequential writes hit 8500 MBps on the Phison PS5026-E26 controller
  • Random 4 KB reads deliver 1.3M IOPS for snappy responsiveness
  • AES 256-bit encryption protects data at rest without performance loss
  • 1400 TBW endurance rating supports heavy workloads over time

Capacity and interface

This Corsair MP700 drive provides 1TB of storage on an M.2 2280 form factor. It connects through a PCI-Express 5.0 x4 link using the NVME protocol. The Phison PS5026-E26 controller manages 3D TLC memory with AES 256-bit encryption for consumer workloads.

Thermals and power

Active read power averages 10.5W while active write power averages 11W. The operating temperature range spans 0°C to 70°C without a heatsink installed. Storage temperature tolerances extend from -40°C to 85°C with humidity rated at 90% RH at 40°C. Shock resistance is specified at 93% RH at 40°C.

Endurance and accessories

The drive carries a 1400TB terabytes written endurance rating. Sequential speeds reach up to 9500 MBps read and 8500 MBps write. Random 4KB performance is rated at 1.3M read and 1.6M write IOPS. No heatsink or additional accessories are bundled in the package.

Highlights

  • Sequential reads reach 9500 MBps via PCIe 5.0 x4
  • Sequential writes hit 8500 MBps on the Phison PS5026-E26 controller
  • Random 4 KB reads deliver 1.3M IOPS for snappy responsiveness
  • AES 256-bit encryption protects data at rest without performance loss
  • 1400 TBW endurance rating supports heavy workloads over time

Specifications

BrandCorsair
SeriesMP700
ModelCSSD-F1000GBMP700R2
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity1TB
Memory Components3D TLC
InterfacePCI-Express 5.0 x4
ProtocolNVMe 2.0
ControllerPhison PS5026-E26
EncryptionAES 256-bit encryption
Max Sequential ReadUp to 9500 MBps
Max Sequential WriteUp to 8500 MBps
4KB Random Read1.3M
4KB Random Write1.6M
Terabytes Written (TBW)1400TB
HeatSinkwithout HeatSink
Power Consumption (Active)Power Average Active Read: 10.5W
Power Average Active Write: 11W
Operating Temperature0°C ~ +70°C
Storage Temperature-40°C ~ +85°C
Operating Humidity40°C 90% RH
Max Shock Resistance40°C 93% RH
Shipping weight0.05 kg
Package size133 × 108 × 25 mm

Questions about this item

How do I install the M.2 2280 drive without a heatsink and what step is often missed?

Insert the drive at an angle into the PCI-Express 5.0 x4 slot, secure it with the motherboard screw, then add a motherboard heatsink or third-party cooler because the drive ships without one.

What maintenance or replacement will the 3D TLC NAND need after heavy use?

The 1400TB terabytes-written rating marks the endurance limit; once reached the controller may switch to read-only mode, so plan a replacement when SMART health approaches that threshold.

What limit appears first during sustained writes on the Phison PS5026-E26 controller?

Active write power reaches 11W and the controller throttles once the 70°C operating temperature is hit, capping sequential write speeds below the 8500 MBps peak.
