Rectangular M.2 2280 SSD with silver aluminum heatsink and black circuit board visible at edges

Corsair

Corsair MP700 ELITE 4TB internal SSD CSSD-F4000GBMP700EHS

SKU CH-EHQX-RSWQ0 MPN CSSD-F4000GBMP700EHS

A 4TB M.2 2280 internal SSD with PCI-Express 5.0 x4 interface, up to 10000 MBps sequential read and 8500 MBps sequential write, plus a pre-installed heatsink

  • Device TypeInternal Solid State Drive (SSD)
  • Used ForConsumer
  • Form FactorM.2 2280
  • Capacity4TB
  • Memory Components3D TLC
  • InterfacePCI-Express 5.0 x4
  • Sequential read up to 10000 MBps for rapid game loads
  • Sequential write up to 8500 MBps for fast file transfers
  • Random read up to 1200K IOPS for responsive multitasking
  • Endurance rated at 2400 TBW for long-term reliability
  • AES 256-bit encryption secures stored data

4TB PCIe 5.0 SSD for consumers

The Corsair MP700 ELITE is a 4TB internal drive built on the PCI-Express 5.0 x4 interface with NVMe 2.0 protocol. It uses a Phison PS5031-E31T controller and 3D TLC NAND to deliver up to 10000 MBps sequential read and 8500 MBps sequential write speeds. The M.2 2280 form factor fits standard desktop and laptop slots.

Sustained performance with pre-installed heatsink

An aluminium heatsink ships already mounted on the drive to manage the thermal output of the Gen5 controller during extended workloads. The controller supports AES 256-bit encryption without a measurable impact on throughput. Rated endurance of 2400 TBW provides a measurable ceiling for heavy write cycles over the drive’s service life.

DirectStorage ready and backward compatible

The drive works with Microsoft DirectStorage for reduced game load times when the operating system and title support the API. Backward compatibility with PCIe Gen4 slots allows installation in older platforms while retaining full NVMe functionality. CORSAIR SSD Toolbox software is available for firmware updates and health monitoring.

Highlights

  • Sequential read up to 10000 MBps for rapid game loads
  • Sequential write up to 8500 MBps for fast file transfers
  • Random read up to 1200K IOPS for responsive multitasking
  • Endurance rated at 2400 TBW for long-term reliability
  • AES 256-bit encryption secures stored data

Specifications

BrandCorsair
SeriesMP700 ELITE
ModelCSSD-F4000GBMP700EHS
Part NumberCSSD-F4000GBMP700EHS
Device TypeInternal Solid State Drive (SSD)
Used ForConsumer
Form FactorM.2 2280
Capacity4TB
Memory Components3D TLC
InterfacePCI-Express 5.0 x4
ProtocolNVMe 2.0
ControllerPhison PS5031-E31T
EncryptionAES 256-bit encryption
Max Sequential ReadUp to 10000 MBps
Max Sequential WriteUp to 8500 MBps
4KB Random Readup to 1200K IOPS
4KB Random Writeup to 1400K IOPS
Terabytes Written (TBW)2400TB
HeatSinkwith HeatSink
FeaturesHigh-speed Gen5 PCIe x4 NVMe 2.0 M.2 interface
Up to 10,000MB/sec sequential read and 8,500MB/sec sequential write speeds
Load games, boot windows, open and transfer files, all faster than ever
High-density 3D TLC NAND
Microsoft DirectStorage compatible
Outstanding endurance up to 2,400TB Written
Compact M.2 2280 form-factor
Pre-installed aluminum heatsink
Backward compatible with PCIe Gen4
CORSAIR SSD Toolbox software
Comprehensive five-year warranty
Power Consumption (Idle)< 50mW
Power Consumption (Active)5.9W
Operating Temperature0°C ~ +70°C
Storage Temperature-40°C ~ +85°C
Operating Humidity40°C 90% RH
Max Shock Resistance1500G
Max Vibration Resistance20Hz~80Hz/1.52mm
Shipping weight0.09 kg
Package size133 × 109 × 25 mm

Questions about this item

Does the pre-installed aluminium heatsink keep the Phison PS5031-E31T controller cool during sustained 10000 MBps reads?

The drive ships with a pre-installed aluminium heatsink designed to dissipate heat from the Phison PS5031-E31T controller and 3D TLC NAND during prolonged high-speed operation, maintaining performance without throttling.

Must my motherboard have an M.2 2280 slot wired for PCI-Express 5.0 x4 to install this SSD?

The SSD uses the M.2 2280 form factor and requires a motherboard M.2 key-M slot; it will run at PCIe 5.0 x4 speeds on a Gen5 platform and falls back to PCIe 4.0 x4 on older boards.

Will this NVMe 2.0 drive work in a system that only supports PCIe 4.0 and NVMe 1.4?

Yes, the MP700 ELITE is backward compatible with PCIe 4.0 x4 and NVMe 1.4, so it functions normally on older platforms while delivering up to 8500 MBps writes on Gen5.
