Green ATX motherboard with silver LGA 775 socket and four black DDR2 slots

DELL

DELL 915G Intel Motherboard LGA 775 DDR2

SKU CH-31NG-9CFWF MPN 915G

Socket 775 desktop motherboard with Intel 915G chipset, four DDR2 slots up to 4 GB, PCIe x16 graphics, dual Gigabit LAN, two SATA ports and onboard video

  • CPU Socket TypeLGA 775
  • CPU TypePentium 4
  • Number of Memory Slots4
  • Memory StandardDDR2-533/PC2-4200 DDR2-400/PC2-3200
  • Maximum Memory Supported4GB
  • PCI Express x161
  • LGA 775 socket fits Pentium 4 processors for desktop upgrades
  • Four DDR2 slots accept 400 and 533 MHz modules up to 4 GB total
  • Intel 915G Express chipset provides integrated graphics and Gigabit Ethernet
  • Two SATA ports and Ultra ATA 133 support legacy storage drives
  • ATX form factor with PCI Express x16 and x1 slots for expansion cards

LGA 775 Pentium 4 board

The DELL 915G motherboard uses the Intel 915G Express chipset and a Socket T LGA 775 interface for Pentium 4 processors. Four DDR2 slots accept 533 or 400 MHz modules up to 4 GB total. An ATX form factor provides one PCI Express x16 slot, one PCI Express x1 slot and two additional expansion slots for add-in cards.

Onboard video and dual Gigabit LAN

Integrated graphics output through a VGA port while two Intel Gigabit Ethernet controllers handle wired networking. Six USB ports and two SATA connectors support storage and peripherals alongside an Ultra ATA 133 channel and a floppy controller. The chipset runs at stock speeds with standard desktop cooling and no extra power phases.

Legacy I/O and expansion layout

A parallel-style floppy header, serial ATA headers and the Ultra ATA 133 connector cover older drive types. The single PCI Express x16 slot is wired for graphics cards, while the x1 slot and two general slots accept sound, network or I/O cards. No bundled software or accessories are mentioned in the specifications.

Highlights

  • LGA 775 socket fits Pentium 4 processors for desktop upgrades
  • Four DDR2 slots accept 400 and 533 MHz modules up to 4 GB total
  • Intel 915G Express chipset provides integrated graphics and Gigabit Ethernet
  • Two SATA ports and Ultra ATA 133 support legacy storage drives
  • ATX form factor with PCI Express x16 and x1 slots for expansion cards

Specifications

BrandDELL
CPU Socket TypeLGA 775
CPU TypePentium 4
Number of Memory Slots4
Memory StandardDDR2-533/PC2-4200 DDR2-400/PC2-3200
Maximum Memory Supported4GB
PCI Express x161
LAN ChipsetIntel
Second LAN ChipsetIntel
Form FactorATX

Questions about this item

How do I install the Pentium 4 CPU into the LGA 775 socket without bending pins?

Lift the socket lever, align the processor notches with the socket keys, lower the CPU straight down without forcing it, then close and latch the lever; the lever tension secures the chip — no screws or thermal paste are included.

What maintenance or replacement will the onboard video and DDR2 memory need later?

The integrated graphics cannot be upgraded; if it fails the board must be replaced. DDR2-400/PC2-3200 or DDR2-533/PC2-4200 modules can be swapped in the four slots up to 4 GB total.

What limit appears first when the board runs sustained loads with the Ultra ATA/133 controller?

The Ultra ATA/133 interface caps drive throughput at 133 MB/s, so storage bandwidth becomes the bottleneck before the PCI Express x16 slot or dual Intel Gigabit LAN saturate.
