Compact silver rack gateway, 211 by 240 by 86 mm, three Ethernet ports, multiple USB and serial connections

DELL

DELL EGW-5200 Edge 5200 Gateway rack server

SKU CH-XDP0-HHHDS MPN EGW-5200

A compact rack gateway with three Intel gigabit Ethernet ports, eight digital I/O channels, six USB ports, a full-size PCIe slot, and dual nanoSIM slots

  • TypeRack
  • Compact 86 mm height fits tight edge spaces
  • 3× Intel GbE ports for wired network redundancy
  • 8-ch DI/DO plus 6 USB for sensor and peripheral hook-up
  • iAMT on i5/i7 CPUs enables remote out-of-band management
  • Full-size PCIe and M.2 2280/3042 slots allow add-on expansion

Compact edge gateway

The Dell EGW-5200 Edge 5200 Gateway is a compact rack-mounted server system designed for edge-computing deployments. It measures 211 mm wide, 240 mm deep and 86 mm high, allowing desktop or wall-mount installation. Three Intel gigabit Ethernet ports provide wired connectivity for industrial or IoT workloads.

Suitable for remote sites.

This unit suits organisations that need a small-footprint gateway with multiple serial and digital I/O interfaces for legacy equipment integration. Buyers requiring standard 19-inch rackmount brackets, redundant power supplies or high-core-count compute density should look at alternative platforms.

3x Intel GbE + 8-ch DI/DO

The gateway includes three Intel GbE ports (two i210 or i225 controllers plus an i219LM PHY) with iAMT support on i5 and i7 CPUs. It also provides eight-channel digital input, eight-channel digital output, two RS-232 ports, six external USB ports, audio line-out and mic-in, one full-size PCIe slot, one M.2 socket 2 (key B+M or B, 2280/3042) supporting SATA 6 Gb/s, and two nanoSIM slots.

Highlights

  • Compact 86 mm height fits tight edge spaces
  • 3× Intel GbE ports for wired network redundancy
  • 8-ch DI/DO plus 6 USB for sensor and peripheral hook-up
  • iAMT on i5/i7 CPUs enables remote out-of-band management
  • Full-size PCIe and M.2 2280/3042 slots allow add-on expansion

Specifications

BrandDELL
ModelEGW-5200
TypeRack

Questions about this item

Does the EGW-5200 need a separate power supply or does it ship with one?

The gateway is sold as hardware only; no power adapter or cable is included in the box.

Can I connect legacy serial equipment to the three Intel GbE ports on this unit?

The three Intel GbE ports are Ethernet only; legacy serial gear uses the two dedicated RS-232 ports instead.

Which front-panel LED confirms the EGW-5200 has booted and the i219LM PHY link is active?

The unit has no documented front-panel LED for PHY link status; verify operation through the OS network stack or management console.
