Dell OptiPlex 5070 Micro all-in-one with 22 inch monitor in black and silver

DELL

DELL OptiPlex 5070 Micro i5-9500T 8GB 512GB+1TB 22" AIO desktop PC

SKU CH-T2AQ-CBTKX

All-in-one desktop with a 22-inch 1920 x 1080 IPS display, Intel Core i5-9500T processor, 8 GB DDR4 memory, 512 GB M.2 SSD plus 1 TB SSD, and Windows 10 Pro

  • TypeAll-in-One PC
  • Form FactorSoDIMM 204-pin
  • UsageBusiness
  • ColorBlack/Silver
  • ProcessorIntel Core i5 8th Gen
  • Memory8 GB DDR4

CPU Type Intel Core i5 9th Gen

CPU Name Intel Core i5-9500T

Memory 8GB DDR4

Option System + 22" Monitor

Class 1TB SSD + 512GB SSD

  • Space-saving 22" all-in-one design includes monitor and stand
  • 9th Gen Intel i5-9500T six-core processor reaches 3.70 GHz for responsive business performance
  • Dual-drive storage with 512 GB M.2 SSD plus 1 TB 2.5" SSD gives fast boot and ample capacity
  • 8 GB DDR4 memory supports multitasking across multiple applications
  • Windows 10 Pro installed and ready for Windows 11 upgrade

All-in-One desktop for business use

The Dell OptiPlex 5070 Micro integrates a 22 inch 1920 x 1080 IPS display with a 9th Gen Intel Core i5-9500T processor running at 2.20 GHz up to 3.70 GHz. It ships with 8 GB DDR4 memory, a 512 GB M.2 SSD plus a 1 TB 2.5 inch SSD, Windows 10 Pro and a USB keyboard and mouse. The compact Micro form factor suits offices where desk space is limited.

Replaces tower PCs with separate monitors

This all-in-one removes the need for a separate chassis and display cables, reducing clutter and IT setup time. The jump is worth it when a business wants a single managed asset with Gigabit Ethernet, WiFi, Bluetooth and multiple video outputs including HDMI and DisplayPort. It is not for buyers who require discrete graphics performance or more than 32 GB of DDR4 memory.

Limited by integrated graphics

The Intel UHD Graphics 630 drives the built-in panel and external displays but cannot handle modern 3D workloads or heavy video encoding. The Intel H370 chipset and Micro board restrict storage to one M.2 slot and one 2.5 inch bay, and memory tops out at 32 GB DDR4 across two SoDIMM slots. No PCIe expansion cards can be added.

Highlights

  • Space-saving 22" all-in-one design includes monitor and stand
  • 9th Gen Intel i5-9500T six-core processor reaches 3.70 GHz for responsive business performance
  • Dual-drive storage with 512 GB M.2 SSD plus 1 TB 2.5" SSD gives fast boot and ample capacity
  • 8 GB DDR4 memory supports multitasking across multiple applications
  • Windows 10 Pro installed and ready for Windows 11 upgrade

Specifications

BrandDELL
SeriesOptiPlex
Model5070
Part Number5070
TypeAll-in-One PC
Form FactorSoDIMM 204-pin
UsageBusiness
ColorBlack/Silver
ProcessorIntel Core i5 8th Gen
Memory8 GB DDR4
Storage512 GB M.2 SSD + 1TB SSD
GraphicsIntel UHD Graphics 630
EthernetGigabit Ethernet
MonitorMonitor included
CaseMicro (MFF)
KeyboardUSB Keyboard
MouseUSB Mouse
Operating SystemWindows 10 Pro
Windows 11Ready
ChipsetIntel H370
CPU TypeIntel Core i5 9th Gen
Installed Qty1
Max Supported Qty1
CPU NameIntel Core i5-9500T
GPU/VGA TypeIntel UHD Graphics 630
Graphics CardIntel UHD Graphics 630
Graphics InterfaceIntegrated video
Memory Capacity8GB DDR4
Memory SpeedDDR4
Memory Spec4 GB x 2
Memory Slot (Total)2
Memory Slot (Available)0
Memory Slots (Available/Total)0/2
Maximum Memory Supported32 GB
SSD512GB
HDDNo
HDD InterfaceSATA III
Storage Spec512 GB M.2 SSD + 1TB SSD
Screen Size22"
TouchscreenNo
LAN Speed10/100/1000Mbps
WiFi GenerationWi-Fi 5
BluetoothYes
Front USB2
Front Audio Ports2
Video Ports1 Display Port, 1 HDMI
Rear USB4
RJ451 port
Antenna PortsYes
Keyboard TypeUSB Keyboard
Mouse TypeUSB Mouse
Speaker ConfigurationNot Included
Weight7
Package TypeRetail

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What are the physical dimensions of the 22" 1920 x 1080 IPS monitor and the Micro form factor PC for desk mounting?

The system includes a 22-inch Full HD IPS display at 1920 x 1080 resolution paired with a Micro form factor chassis on an All-in-One stand. The compact MFF design saves desk space while the stand integrates the PC behind the screen.

How do I install the Dell OptiPlex 5070 or 7070 Micro onto the AIO stand, and which thumbscrew secures it?

Align the Micro chassis with the mounting brackets on the rear of the AIO stand, slide it into place, then tighten the thumbscrew labelled 6 on the port diagram to lock the unit securely.

When upgrading memory later, what DDR4 SoDIMM specification does the 204-pin slot support up to 32 GB?

The board uses DDR4 204-pin SoDIMM slots supporting up to 32 GB total capacity. Insert modules at an angle until the clips click; the system runs at the speed of the slowest stick installed.
