Dell PowerEdge R330 1U rack server, matte black front with four 3.5-inch drive bays

DELL

DELL PowerEdge R330 1U rack server Xeon E3-1220 v5 3GHz 8GB DDR4 H330 2x 350W

SKU CH-HAPF-4J7VA

1U rack server with Xeon E3-1220 v5, 8GB DDR4, H330 RAID controller, four 3.5" hot-plug bays and dual 350W power supplies

  • TypeRack
  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • MAX Processors1
  • ChipsetIntel C236
  • Quad-core Xeon E3-1220 v5 at 3 GHz delivers responsive compute
  • 8 GB DDR4 memory supports everyday workloads
  • H330 12 Gbps RAID controller enables RAID 0/1/5/10/50/60
  • Dual 350 W hot-swap power supplies provide redundancy
  • Four 3.5" hot-plug bays allow up to 40 TB storage

1U rack server for single-socket workloads

The Dell PowerEdge R330 fits a single Intel Xeon E3-1220 v5 quad-core processor at 3GHz in a 1U form factor. It ships with 8GB of DDR4 memory across four DIMM slots and includes a PERC H330 RAID controller. Two hot-swap 350W power supplies provide redundancy for continuous operation.

8GB DDR4 with four slots and 40TB drive ceiling

The installed 8GB uses one of four DDR4 slots that accept 4GB, 8GB or 16GB modules at up to 2400MT/s. Maximum supported memory is 64GB, though the spec sheet also lists a 8GB ceiling. Four 3.5-inch hot-plug bays accept SAS or SATA drives with a combined raw capacity of 40TB. RAID 0, 1, 5, 10, 50 and 60 are available through the H330 controller.

Redundant power and iDRAC8 remote management

Dual 350W hot-swap supplies keep the server running if one unit fails. The iDRAC8 Express controller is included for out-of-band management, with Enterprise and vFlash upgrades available. A DVD-ROM drive is fitted. The package includes a power cable; rail kit, bezel, keyboard, mouse and video cable are not supplied.

Highlights

  • Quad-core Xeon E3-1220 v5 at 3 GHz delivers responsive compute
  • 8 GB DDR4 memory supports everyday workloads
  • H330 12 Gbps RAID controller enables RAID 0/1/5/10/50/60
  • Dual 350 W hot-swap power supplies provide redundancy
  • Four 3.5" hot-plug bays allow up to 40 TB storage

Specifications

BrandDELL
SeriesPowerEdge
ModelPowerEdge R330
TypeRack
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
MAX Processors1
ChipsetIntel C236
Installed Memory Size8GB
Memory TypeDDR4
Max Memory Capacity8GB
Memory Features4 DIMM slots compatible with 4GB/8GB/16GB DDR4 up to 2400MT/s, actual memory speed dependent on the processor capability.
Number of Memory Slots4
Storage ControllerDell Perc H330 Controller
SSD (Installed)No
Raid LevelRAID 0/1/5/10/50/60
Max HDD Capacity40TB
Media DrivesDVD ROM
GPU TypeMatrox G200
Video Memory8MB
Remote ManagementiDRAC8 with Lifecycle Controller, iDRAC8 Express (default), iDRAC8 Enterprise (upgrade) 8GB vFlash media (upgrade), 16GB vFlash media (upgrade)
LAN Ports2 x Ports
Expansion Slots2 x PCIe 3.0 slots + 1 slot for internal storage.
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight40.0000LBS

Questions about this item

Will my existing DDR4 ECC modules rated at 2400MT/s work in the four DIMM slots of this PowerEdge R330?

Yes, the four slots accept 4GB, 8GB or 16GB DDR4 modules up to 2400MT/s; actual speed depends on the installed Xeon E3-1220 v5 processor capability.

How can I confirm the PERC H330 RAID controller is operating correctly after installation?

During POST the H330 BIOS will display its firmware version and detected drives; you can also enter the controller configuration utility (Ctrl+R) to verify RAID 0/1/5/10/50/60 arrays are healthy.

Which items ship with the server and which must be purchased separately?

The unit includes the chassis, Xeon E3-1220 v5 CPU, 8GB DDR4, H330 controller, DVD-ROM, Matrox G200 graphics, two 350W redundant power supplies, a power cable and iDRAC8 Express; rails, bezel, keyboard, mouse, video cable and any hard drives are not included.
