Silver 1U rack server with four front drive bays and dual power supplies

DELL

DELL PowerEdge R330 1U rack server Xeon E3-1220v5 3GHz 8GB 4×2TB SAS H730 2×350W

SKU CH-GVE7-7MWF7

1U rack server with Xeon E3-1220v5, 8 GB DDR4, four 2 TB SAS drives on an H730 controller and dual 350 W supplies

  • TypeRack
  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • MAX Processors1
  • ChipsetIntel C236
  • Quad-core Xeon at 3GHz drives responsive compute
  • 8GB DDR4 with four slots ready for expansion
  • Four 2TB SAS drives in hot-plug bays for capacity
  • H730 RAID controller supports RAID 0/1/5/6/10/50/60
  • Dual 350W redundant power supplies keep the server running

Compact 1U rack server for single-socket workloads

The Dell PowerEdge R330 fits a Xeon E3-1220 v5 quad-core processor at 3 GHz with 8 GB of DDR4 memory into a single rack unit. It targets small-business IT rooms or remote offices that need a dedicated physical host for virtualisation, file serving or line-of-business applications without the footprint of a larger chassis.

Dual 350 W redundant supplies

Two hot-swappable 350 W power supplies share the load so one can fail without downtime. Four 3.5-inch bays accept SAS or SATA drives and the front panel provides direct access for drive replacement while the system runs. The H730 controller with 1 GB cache offloads RAID parity calculations from the CPU, keeping thermals steady under mixed read-write traffic.

H730 RAID controller and iDRAC8 remote management

The PERC H730 supports RAID 0, 1, 5, 6, 10, 50 and 60, letting administrators tune capacity versus redundancy across the four installed 2 TB 7.2K SAS drives. iDRAC8 Express gives out-of-band console access, power control and hardware inventory over a dedicated 1 GbE port, while optional Enterprise licences add virtual media and vFlash caching for faster firmware updates.

Highlights

  • Quad-core Xeon at 3GHz drives responsive compute
  • 8GB DDR4 with four slots ready for expansion
  • Four 2TB SAS drives in hot-plug bays for capacity
  • H730 RAID controller supports RAID 0/1/5/6/10/50/60
  • Dual 350W redundant power supplies keep the server running

Specifications

BrandDELL
SeriesPowerEdge
ModelPowerEdge R330
TypeRack
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
MAX Processors1
ChipsetIntel C236
Installed Memory Size8GB
Memory TypeDDR4
Max Memory Capacity8GB
Memory Features4 DIMM slots compatible with 4GB/8GB/16GB DDR4 up to 2400MT/s, actual memory speed dependent on the processor capability.
Number of Memory Slots4
Storage ControllerDell Perc H730 Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Max HDD Capacity40TB
Media DrivesDVD ROM
GPU TypeMatrox G200
Video Memory8MB
Remote ManagementiDRAC8 with Lifecycle Controller, iDRAC8 Express (default), iDRAC8 Enterprise (upgrade) 8GB vFlash media (upgrade), 16GB vFlash media (upgrade)
LAN Ports2 x Ports
Expansion Slots2 x PCIe 3.0 slots + 1 slot for internal storage.
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight40.0000LBS

Questions about this item

How do I install the four 3.5-inch SAS drives and what step is often missed?

Slide each drive into a hot-plug bay until the latch clicks; the step often missed is creating the virtual disk in the H730 controller BIOS before the OS sees any volume.

Which components will need replacement first during long-term operation?

The 7.2K SAS drives and the two 350W redundant power supplies are the field-replaceable parts most likely to require service over time.

What limit appears first when the server runs sustained workloads?

The installed 8GB DDR4 memory reaches capacity before CPU or storage limits become a bottleneck under continuous use.
