1U silver rack server with eight 2.5 inch drive bays front panel

DELL

DELL PowerEdge R430 1U rack server 2× Xeon E5-2603 v3 1.6 GHz 96 GB DDR4 H730

SKU CH-V63A-T5W12

1U rack server with dual Xeon E5-2603 v3 CPUs, 96 GB DDR4, H730 RAID controller and eight 2.5" hot-plug bays

  • TypeRack
  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeDual Intel Xeon
  • MAX Processors2
  • ChipsetIntel C610

Installed Memory Size 96GB

HDD None

  • Dual Xeon E5-2603 v3 six-core CPUs deliver multi-threaded compute
  • 96 GB DDR4 memory across 12 DIMM slots supports virtualization workloads
  • H730 RAID controller enables RAID 0/1/5/6/10/50/60 for data protection
  • Dual 550 W redundant power supplies maintain uptime during a failure
  • 1U rack form factor fits 8 × 2.5" hot-plug drive bays

Purpose-built 1U rack server

The Dell PowerEdge R430 is a 1U rack-mount server system designed for dense compute environments. It arrives with dual Intel Xeon E5-2603 v3 six-core processors running at 1.6 GHz and 96 GB of DDR4 memory installed across 12 DIMM slots. The platform targets workloads that benefit from redundant power and integrated hardware RAID in a single rack unit.

Memory ceiling fixed at 96 GB

The installed 96 GB of DDR4 matches the maximum capacity supported by the specific processor configuration, leaving no headroom for future expansion. Twelve slots are populated to reach this limit, so any increase would require a processor change. Buyers who need more than 96 GB of RAM should consider a different server configuration.

Dual 550 W redundant supplies

Two hot-swap 550 W power supplies provide N+1 redundancy for continuous operation. The 1U chassis uses internal fans to cool the dual CPUs, memory, and the PERC H730 RAID controller under normal load. Acoustic output is typical for a 1U rack server in a data-centre aisle.

Highlights

  • Dual Xeon E5-2603 v3 six-core CPUs deliver multi-threaded compute
  • 96 GB DDR4 memory across 12 DIMM slots supports virtualization workloads
  • H730 RAID controller enables RAID 0/1/5/6/10/50/60 for data protection
  • Dual 550 W redundant power supplies maintain uptime during a failure
  • 1U rack form factor fits 8 × 2.5" hot-plug drive bays

Specifications

BrandDELL
SeriesPowerEdge
ModelPowerEdge R430
TypeRack
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeDual Intel Xeon
MAX Processors2
ChipsetIntel C610
Installed Memory Size96GB
Memory TypeDDR4
Max Memory Capacity96GB
Memory Features12 DIMM slots, 6 per processor. (4GB/8GB/16GB/32GB DDR4 up to 2400MT/s, actual memory speed dependent on the processor capability).
Number of Memory Slots12
Storage ControllerDell Perc H730 Controller
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Max HDD Capacity16TB
Media DrivesDVD ROM
GPU TypeMatrox G200
Video Memory8MB
Remote ManagementiDRAC8 with Lifecycle Controller, iDRAC8 Express (default), iDRAC8 Enterprise (upgrade) 8GB vFlash media (upgrade), 16GB vFlash media (upgrade)
LAN Ports4 x Ports
Expansion Slots2 PCIe 3.0
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight40.0000LBS

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What real-world throughput does the H730 controller's 12Gbps rating deliver with eight 2.5-inch drives?

The Perc H730 controller runs at 12Gbps SAS/SATA. With eight hot-plug bays the practical ceiling is the backplane and drive mix; the controller supports RAID 0/1/5/6/10/50/60 so aggregate throughput scales with the number and speed of the installed drives.

Which PCIe generation and slot count limit add-in cards in this R430?

The system provides two PCIe 3.0 slots. Any add-in card must fit the 1U height and the electrical budget of those two lanes; no additional expansion slots are present.

What physical space and power connections does the 1U chassis need for installation?

The chassis measures 26.7 by 18.99 by 1.68 inches and weighs 43 lbs. It requires two 550W redundant power supplies fed from separate circuits, and a rail kit (not included) for rack mounting.
