Silver 2U rack server with front bezel, eight 3.5-inch drive trays, dual redundant power supplies and slide rails

DELL

Dell PowerEdge R540 2U Rack Server 2x Xeon Silver 4114 10 Core 64GB DDR4 H730P 8x 3.5" Trays iDRAC9 2x 750W

SKU CH-6VZV-EZ3RR

A 2U rack server with dual 10-core Xeon Silver 4114 processors at 2.2 GHz, 64 GB DDR4, H730P RAID controller, eight 3.5-inch drive trays, iDRAC9 Enterprise and redundant 750 W power supplies

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.20 GHz
  • CPU SocketLGA 3647
  • Dual 10-core Xeon Silver 4114 CPUs at 2.2 GHz base and 3.0 GHz turbo for strong multi-threaded throughput
  • 64 GB DDR4 2666 MHz registered ECC memory across 16 slots expandable to 384 GB
  • PERC H730P 2 GB controller with battery-backed RAID 0/1/5/6/10/50/60 and pass-through
  • Eight 3.5" SAS/SATA hot-swap drive trays ready for high-capacity storage arrays
  • iDRAC9 Enterprise remote management plus redundant 750 W platinum power supplies for resilient uptime

Dual Xeon Silver 4114 2U Rack Server

The Dell PowerEdge R540 is a 2U rack server equipped with two Intel Xeon Silver 4114 processors, each delivering ten cores at 2.2 GHz with a 3.0 GHz turbo frequency. Sixty-four gigabytes of DDR4 registered ECC memory are installed across four modules. The system targets virtualization, database hosting, and file-serving workloads that require dual-socket compute density in a standard rack footprint.

PERC H730P RAID Controller With Battery

A Dell PERC H730P controller with two gigabytes of cache and a backup battery enables RAID levels 0, 1, 5, 6, 10, 50 and 60 plus pass-through mode. Eight 3.5-inch drive trays accept both SATA and SAS drives, though no drives are included. The controller and tray combination lets administrators configure redundancy or capacity to match application demands without adding extra hardware.

Redundant 750W Platinum Power Supplies

Dual hot-swap 750 watt platinum-efficiency power supplies provide redundancy for continuous operation. Integrated iDRAC9 Enterprise delivers out-of-band remote management, monitoring and automation over a dedicated network interface. Ready rails and a front bezel are included for straightforward rack mounting and a finished appearance in standard cabinets.

Highlights

  • Dual 10-core Xeon Silver 4114 CPUs at 2.2 GHz base and 3.0 GHz turbo for strong multi-threaded throughput
  • 64 GB DDR4 2666 MHz registered ECC memory across 16 slots expandable to 384 GB
  • PERC H730P 2 GB controller with battery-backed RAID 0/1/5/6/10/50/60 and pass-through
  • Eight 3.5" SAS/SATA hot-swap drive trays ready for high-capacity storage arrays
  • iDRAC9 Enterprise remote management plus redundant 750 W platinum power supplies for resilient uptime

Specifications

BrandDELL
SeriesPowerEdge R740
ModelR540
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.20 GHz
CPU SocketLGA 3647
Number of CPU Cores10-Core Processor
# of Processors Installed2
MAX Processors2
Chipset0
Installed Memory Size64GB
Memory Type0
Max Memory Capacity384GB
Number of Memory Slots16
Hard Drive (Installed)None
Storage ControllerDell Perc H730P 2GB Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Media Drives0
GPU Type0
Video Memory0
Ethernet ControllerIntegrated Dell 2x1GbE Dual Port Ethernet Adapter
LAN Ports2 x Ports
Expansion Slots0
Management Port0
Operating SystemNo
Features8 x 3.5" SATA/SAS Hot-Plug Drive Bays

Questions about this item

When will the PERC H730P RAID controller battery need replacement?

The PERC H730P includes a battery-backed cache module; typical service life is several years, after which the battery can be swapped without removing the controller.

What limits sustained compute throughput on the dual Xeon Silver 4114 CPUs?

The two 10-core Xeon Silver 4114 processors run at 2.2 GHz base with 3.0 GHz turbo; under continuous all-core load the base frequency is the limiting factor.

How much power do the redundant 750W platinum PSUs draw at full load?

Each supply is rated at 750 W platinum efficiency; the pair provides redundant power so the server continues running if one unit fails.
