Silver 1U rack server chassis with front drive bays and rear ventilation

DELL

DELL PowerEdge R570 1U rack server Intel Xeon 6 DDR5

SKU CH-B4MT-G5AZ2 MPN PowerEdge R570

A 1U rack server for general-purpose workloads with Intel Xeon 6, DDR5 memory up to 4TB, and up to 12 drive bays

  • WorkloadGeneral Purpose Server
  • TypeRack
  • Rack Height1U
  • SecurityCryptographically signed firmware Data at Rest Encryption (S
  • CPU TypeIntel Xeon 6
  • # of Processors Installed0
  • Intel Xeon 6 processor drives demanding workloads
  • DDR5 memory scales to 4 TB across 16 slots
  • Up to 12 front 3.5-inch bays store 288 TB
  • Six PCIe Gen5 x16 slots enable high-speed add-in cards
  • Silicon Root of Trust and TPM 2.0 FIPS harden platform security

1U rack server for general-purpose workloads

The Dell PowerEdge R570 is a 1U rack server designed for general-purpose workloads. It supports a single Intel Xeon 6 processor and DDR5 memory across 16 slots. The chassis ships without a CPU or memory installed, letting you choose the exact configuration for compute, virtualisation or database tasks.

Memory capacity and storage headroom

Up to 4TB of DDR5 memory can be installed across the 16 DIMM slots. Front bays accept up to 12 x 3.5-inch SAS or SATA drives for a maximum of 288TB, or up to 8 x 2.5-inch NVMe SSDs for 122.88TB. The chosen drive type and bay count define the storage ceiling for the deployment.

Build integration and expansion options

The 1U form factor fits standard racks measuring 3.42 x 18.98 x 31.55-31.59 inches. Up to six PCIe Gen5 x16 slots provide room for GPU, networking or storage controllers, while an OCP 3.0 slot and optional BOSS module handle dedicated I/O. Cryptographically signed firmware, Secure Boot, Silicon Root of Trust and TPM 2.0 secure the platform from boot-up.

Highlights

  • Intel Xeon 6 processor drives demanding workloads
  • DDR5 memory scales to 4 TB across 16 slots
  • Up to 12 front 3.5-inch bays store 288 TB
  • Six PCIe Gen5 x16 slots enable high-speed add-in cards
  • Silicon Root of Trust and TPM 2.0 FIPS harden platform security

Specifications

BrandDELL
SeriesPowerEdge R570
WorkloadGeneral Purpose Server
TypeRack
Rack Height1U
SecurityCryptographically signed firmware
Data at Rest Encryption (SEDs with local or external key mgmt)
Secure Boot
Secured Component Verification (Hardware integrity check)
Secure Erase
Silicon Root of Trust
System Lockdown
TPM 2.0 FIPS, CC-TCG certified
Chassis Intrusion Detection
CPU TypeIntel Xeon 6
# of Processors Installed0
MAX Processors1
Installed Memory SizeNo
Memory TypeDDR5
Max Memory Capacity4TB
Number of Memory Slots16
Expansion SlotsUp to six PCIe slots (x16 connector)
- Slot 2: 1 x16 Gen5 Full Height, Half Length or 1 x16 Full Height, Full Length
- Slot 3: 1 x16 Gen5 Full Height, Half Length
- Slot 4: 1 x16 Gen5 Full Height, Half Length or 1 x16 Full Height, Full Length or 1 x16 OCP3.0
- Slot 6: 1 x4 Gen4 Boss (optional)
- Slot 7: 1 x16 Gen5 Full Height, Half Length or 1 x16 Full Height, Full Length
- Slot 9: 1 x16 Gen5 Full Height, Half Length
- Slot 10: 1 x16 OCP3.0
- Slot 31: 1 x16 Gen5 Full Height, Half Length
- Slot 34: 1 x16 OCP3.0 or 1 x4 Gen4 Boss (optional)
- Slot 36: 1 x16 Gen5 Full Height, Half Lengt
Expansion BaysFront bays:
- Up to 12 x 3.5-inch SAS (HDD) RAID max 288 TB
- Up to 12 x 3.5-inch SAS/SATA (HDD) RAID max 288 TB
- Up to 8 x 2.5-inch NVMe (SSD) RAID max 122.88 TB
- Up to 8 x 2.5-inch NVMe (SSD) max 122.88 TB
- Up to 8 x 2.5-inch SAS/SATA (HDD/SSD) max 30.72 TB
- Up to 8 x 2.5-inch SAS/SATA/Universal (HDD/SSD) max 122.88 TB
- Up to 16 x 2.5-inch SAS/SATA (HDD/SSD) RAID max 61.44 TB
- Up to 24 x 2.5-inch SAS4/SATA (HDD/SSD) max 92.16 TB
- Up to 8 x EDSFF E3.S (hot-aisle) Gen5 NVMe max 122.88 TB
- Up to 8 x EDSFF E3.S (cold-aisle) Gen5 NVMe 122.88 TB
- Up to 16 x EDSFF E3.S (cold-aisl
Dimensions3.42" x 18.98" x 31.55"-31.59"
Shipping weight18.14 kg
Package size914 × 610 × 203 mm

Questions about this item

Can I install my current PCIe Gen4 expansion cards into the Gen5 x16 slots on the PowerEdge R570?

Yes, PCIe Gen4 cards are compatible with the up to six Gen5 x16 slots on the R570 and will operate at Gen4 speeds.

How can I verify the PowerEdge R570 firmware integrity after initial setup?

The Silicon Root of Trust and Secured Component Verification perform hardware integrity checks at boot, confirming cryptographically signed firmware is running.

Does the PowerEdge R570 include any processors, memory modules or drive caddies in the box?

The system ships with zero processors installed, no memory modules, and no drives; CPU, DDR5 DIMMs and 2.5-inch or 3.5-inch drive carriers must be purchased separately.
