DELL
DELL PowerEdge R630 8SFF Xeon E5-2690 v3 2.6GHz 12C 384GB DDR4 No Drive
1U rack server holds eight 2.5-inch drives, runs one 12-core Xeon at 2.6GHz with 384GB DDR4 and a PERC H730 controller
- TypeRack
- CPU TypeIntel Xeon
- CPU Speed2.6GHz
- # of Processors Installed1
- MAX Processors2
- Installed Memory Size384GB
- 12-core Xeon E5-2690 v3 at 2.6GHz for high compute density
- 384GB DDR4 ECC memory supports large virtualisation workloads
- Eight 2.5" drive bays with PERC H730 SAS controller for flexible storage
- Dual 10GbE and 1GbE network ports for high-throughput connectivity
- iDRAC8 Enterprise remote management simplifies server administration
1U rack server for virtualization
The Dell PowerEdge R630 fits a single Intel Xeon E5-2690 v3 processor with 12 cores running at 2.6 GHz. It ships with 384 GB of DDR4 ECC registered memory and a PERC H730 SAS RAID controller. The 8-bay 2.5-inch chassis supports SATA drives and includes dual 10 GbE plus dual 1 GbE network ports. iDRAC8 Enterprise provides remote management.
Verify rack depth and power before ordering
The unit measures 36 by 24 by 10 inches and weighs 40 pounds, so confirm your rack can accommodate that depth and weight. Two 495 W power supplies are installed; ensure your PDU circuits can deliver the required current. No drives are included, so plan the quantity and capacity of 2.5-inch SATA drives you will add. A second processor can be added later up to the two-socket maximum.
Integrates into dense compute clusters
The 1U form factor leaves space for additional nodes in a standard rack. Eight front-accessible drive bays free internal cabling and simplify storage expansion. Dual 10 GbE ports handle east-west traffic between nodes without a separate switch uplink. iDRAC8 Enterprise enables lights-out firmware updates and hardware monitoring across the cluster. Memory can scale to 1.5 TB when workloads grow.
Highlights
- 12-core Xeon E5-2690 v3 at 2.6GHz for high compute density
- 384GB DDR4 ECC memory supports large virtualisation workloads
- Eight 2.5" drive bays with PERC H730 SAS controller for flexible storage
- Dual 10GbE and 1GbE network ports for high-throughput connectivity
- iDRAC8 Enterprise remote management simplifies server administration
Specifications
| Brand | DELL |
|---|---|
| Series | PowerEdge |
| Model | Rack Mount |
| Type | Rack |
| CPU Type | Intel Xeon |
| CPU Speed | 2.6GHz |
| # of Processors Installed | 1 |
| MAX Processors | 2 |
| Installed Memory Size | 384GB |
| Memory Type | DDR4 |
| Max Memory Capacity | 1.5TB |
| Hard Drive (Installed) | 3.840,00 |
| Storage Controller | Dell PERC H730 SAS Controller |
| HDD Interface | SATA |
| GPU Type | Integrated Graphics |
| Remote Management | iDRAC8 - Enterprise License |
| Dimensions | 36 x 24 x 10 in |
| Weight | 40 |
Questions about this item
Does the server ship with any drives or do I need to supply my own 2.5-inch SATA or SAS drives?
The 8SFF chassis has eight 2.5-inch bays but no drives are installed; you must add compatible SATA or SAS drives yourself.
Should I choose the single E5-2690 v3 configuration or add a second processor to reach the 24-core maximum?
One 12-core 2.6 GHz E5-2690 v3 is installed and the board supports a second identical CPU for 24 cores total.
How much of the 384 GB DDR4 ECC registered memory is usable after the operating system and iDRAC8 reserve their share?
The full 384 GB is addressable by the OS; only a small firmware-reserved region is taken by iDRAC8.
