Silver 1U rack server front with eight drive bays and four network ports

DELL

DELL PowerEdge R640 1U rack server 2× Xeon Gold 6134 3.2GHz 64GB DDR4 8× 1.2TB SAS H740P 4× 1GbE

SKU CH-A1XT-EN9V2

1U rack server with two 3.20 GHz Xeon Gold 6134 CPUs, 64 GB DDR4 ECC memory, eight 1.2 TB SAS drives on an H740P controller and quad 1 GbE ports

  • TypeRack
  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon Scalable
  • CPU Speed3.20 GHz
  • CPU SocketLGA 3647
  • 16-core Xeon performance handles virtualization and database workloads
  • 64GB DDR4 ECC memory supports multiple virtual machines and services
  • 8× 1.2TB SAS drives deliver capacity for applications and backups
  • H740P RAID controller simplifies storage setup and management
  • Quad-port 1GbE provides network connectivity for business workloads

PowerEdge R640 virtualization server

The Dell EMC PowerEdge R640 is a 1U rack server built for business workloads such as virtualization, databases, backups and application hosting. Two Intel Xeon Gold 6134 processors run at 3.20 GHz with Turbo Boost up to 3.70 GHz, delivering 16 cores in total. 64 GB of DDR4 ECC registered memory is installed across 24 slots, supporting up to 3 TB maximum capacity. Redundant hot-swap power supplies are included.

Suits dense virtualization; not for GPU compute

This configuration suits teams that need high core density and fast SAS storage in a single rack unit for virtual machine clusters or database instances. The 1U form factor limits expansion cards, so buyers who need GPU acceleration or additional PCIe devices should look at a larger chassis. Memory headroom remains for growth up to the 3 TB limit.

8× 1.2 TB SAS drives on H740P

Eight 1.2 TB 10K SAS drives connect through the Dell PERC H740P controller with 8 GB cache, providing hardware RAID for operating systems, applications, virtual machines and backups. The SAS interface delivers 12 Gb/s throughput for write-heavy workloads. Four onboard 1 GbE RJ45 ports handle network connectivity.

Highlights

  • 16-core Xeon performance handles virtualization and database workloads
  • 64GB DDR4 ECC memory supports multiple virtual machines and services
  • 8× 1.2TB SAS drives deliver capacity for applications and backups
  • H740P RAID controller simplifies storage setup and management
  • Quad-port 1GbE provides network connectivity for business workloads

Specifications

BrandDELL
SeriesPowerEdge R640
TypeRack
Rack Height1U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon Scalable
CPU Speed3.20 GHz
CPU SocketLGA 3647
Number of CPU Cores8-Core Processor
CPU FeaturesTurbo Boost up to 3.70 GHz
# of Processors Installed2
MAX Processors2
Installed Memory Size64GB
Memory TypeDDR4
Max Memory Capacity3TB
Memory FeaturesECC Registered
Number of Memory Slots24
Storage ControllerDell Perc H740P 8GB Controller
HDD InterfaceSAS
Ethernet ControllerI350 - Quad Port 1GbE RJ45
LAN Ports4 x Ports
Package ContentsPower Cables Included

Questions about this item

How many 2.5-inch drive bays does the 1U R640 chassis provide for the 1.2TB SAS drives?

The 1U chassis holds eight 2.5-inch hot-swap bays, matching the eight 1.2TB SAS drives installed.

Which slot type does the H740P RAID controller occupy and what cable step is often missed?

The H740P uses a dedicated internal storage slot; the step often missed is connecting the two mini-SAS HD cables from the backplane to the controller before closing the chassis.

What memory type and maximum capacity should be planned for future upgrades?

The server uses DDR4 ECC registered DIMMs across 24 slots and supports up to 3TB total capacity.
