Black 1U rack server with silver front bezel, ten 2.5-inch drive bays, dual redundant power supplies, and sliding rails

DELL

DELL PowerEdge R650xs 1U Rack Server 2x Xeon Gold 5317 3.0GHz 12 Core 512GB DDR4 10x 960GB SSD

SKU CH-8RGN-FER28

1U rack server with two 12-core Xeon Gold 5317 CPUs, 512 GB DDR4, ten 960 GB SATA SSDs and dual 1400 W power supplies

  • TypeRack
  • Rack Height1U
  • Redundant Hot-swap PowerYes
  • AI Features10 x 960GB SATA SSD
  • CPU TypeIntel Xeon
  • CPU Speed16
  • Dual Xeon Gold 5317 CPUs provide 12 cores each at 3.0 GHz
  • 512 GB DDR4 2933 MHz ECC memory enables high-capacity multitasking
  • PERC H745 RAID controller with 4 GB NV cache supports RAID 0, 1, 5, 6, 10, 50, 60
  • Ten 960 GB SATA SSDs deliver fast solid-state storage
  • iDRAC9 Enterprise plus quad-port 1 GbE OCP card simplify remote management

Compact 1U rack server

The Dell PowerEdge R650xs is a 1U rack server built for dense data-center deployments. It ships with two Intel Xeon Gold 5317 processors running at 3.0 GHz with a 3.6 GHz turbo frequency. The system includes 512 GB of DDR4 2933 MHz registered ECC memory across 16 DIMM slots. Dual 1400 W platinum power supplies and iDRAC9 Enterprise remote management come standard.

Suits virtualization and database clusters.

This configuration targets workloads that demand high core counts and large memory capacity in a single rack unit. Virtualization hosts, database clusters and dense compute farms benefit from the 12-core CPUs and 512 GB DDR4. Buyers who need GPU acceleration for AI training or workloads requiring NVMe flash should evaluate other platforms. The front bays accept SATA and SAS drives only.

Ten 960 GB SATA SSDs on a PERC H745 controller

Storage is provided by ten 960 GB enterprise SATA 6 Gb/s 2.5-inch SSDs managed by a Dell PERC H745 RAID controller with 4 GB non-volatile cache. The controller supports RAID 0, 1, 5, 6, 10, 50 and 60 for redundancy and performance tuning. Network connectivity uses a Broadcom 5720 quad-port 1 GbE OCP 3.0 adapter. Ready Rails and a front bezel are included for immediate rack installation.

Highlights

  • Dual Xeon Gold 5317 CPUs provide 12 cores each at 3.0 GHz
  • 512 GB DDR4 2933 MHz ECC memory enables high-capacity multitasking
  • PERC H745 RAID controller with 4 GB NV cache supports RAID 0, 1, 5, 6, 10, 50, 60
  • Ten 960 GB SATA SSDs deliver fast solid-state storage
  • iDRAC9 Enterprise plus quad-port 1 GbE OCP card simplify remote management

Specifications

BrandDELL
SeriesPowerEdge R650xs
ModelR650xs
Part Number3.00 GHz
TypeRack
Rack Height1U
Redundant Hot-swap PowerYes
AI Features10 x 960GB SATA SSD
CPU TypeIntel Xeon
CPU Speed16
CPU SocketLGA 4189
Number of CPU Cores12-Core Processor
# of Processors InstalledGold 5317
MAX Processors2
Chipset0
Installed Memory Size512GB
Memory TypeDDR4
Max Memory Capacity1TB
Storage ControllerDell Perc H745 Controller
HDD InterfaceSATA
Raid LevelRAID 0/1/5/6/10/50/60
Media Drives0
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerDell EMC 15G Broadcom 5720 Quad Port 1GbE OCP 3.0 Network Card
LAN Ports4 x Ports
Expansion Slots0
Management PortRJ 45
Operating SystemNo
Features10 x 2.5" SATA/SAS Hot-Plug Drive Bays

Questions about this item

Does the R650xs ship with all ten 960 GB SSDs installed and are rails included?

The server comes with ten 960 GB SATA SSDs pre-installed in the 2.5-inch bays and includes Ready Rails plus a front bezel.

Should I choose the 512 GB DDR4 configuration or add more modules later?

The unit already holds 512 GB across sixteen 32 GB DDR4 2933 MHz registered ECC DIMMs; the platform supports up to 1 TB so additional modules can be added if workloads grow.

What real-world throughput can I expect from the H745 controller with these ten SATA SSDs?

The PERC H745 with 4 GB NV cache manages the ten 6 Gb/s SATA SSDs in RAID 0, 1, 5, 6, 10, 50 or 60, delivering sustained read/write speeds limited by the SATA 6 Gb/s interface.
