Silver 2U rack server with eight front 3.5-inch drive bays and redundant power supplies

DELL

DELL PowerEdge R730 2U E5-2609v3 1.9GHz 16GB DDR4 H330 8x3.5" rack server

SKU CH-X82Y-J77DE

A 2U rack server with an 8-bay 3.5" hot-plug chassis, single Xeon E5-2609v3 six-core 1.9GHz CPU, 16GB DDR4, and H330 RAID controller

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • MAX Processors2
  • ChipsetIntel C610

Installed Memory Size 16GB

HDD None

  • 2U rack form factor fits dense data-centre deployments
  • Single Xeon E5-2609v3 six-core 1.9GHz handles core workloads
  • 16GB DDR4 ECC memory supports virtualisation and database tasks
  • H330 12Gbps RAID controller enables RAID 0/1/5/10/50/60 protection
  • Dual 750W hot-swap power supplies keep the system running through a failure

2U rack server for dense compute

The Dell PowerEdge R730 is a 2U rackmount system built around a single Intel Xeon E5-2609v3 six-core processor running at 1.9GHz. It ships with 16GB of DDR4 memory and a Perc H330 RAID controller supporting RAID 0/1/5/10/50/60. Dual 750W redundant power supplies provide failover protection. The chassis accommodates up to eight 3.5-inch hot-plug SAS or SATA drives. Remote management is handled by iDRAC8 with Lifecycle Controller.

Eight 3.5-inch hot-plug drive bays

Storage capacity hinges on the eight front-accessible 3.5-inch bays that accept SAS or SATA drives in hot-plug carriers. The H330 controller delivers 12Gbps SAS connectivity and supports RAID levels 0, 1, 5, 10, 50 and 60 for redundancy or performance. No drives or trays are included, so buyers must supply their own media. Maximum raw capacity reaches 64TB when the bays are fully populated.

Redundant 750W supplies and iDRAC8

Two 750W hot-swap power supplies share the load and maintain operation if one unit fails, reducing downtime in rack environments. The Matrox G200 graphics subsystem draws minimal power for basic video output. iDRAC8 with Lifecycle Controller enables remote monitoring of temperatures, fan speeds and power consumption without needing an operating system. A DVD-ROM drive is fitted for legacy media access.

Highlights

  • 2U rack form factor fits dense data-centre deployments
  • Single Xeon E5-2609v3 six-core 1.9GHz handles core workloads
  • 16GB DDR4 ECC memory supports virtualisation and database tasks
  • H330 12Gbps RAID controller enables RAID 0/1/5/10/50/60 protection
  • Dual 750W hot-swap power supplies keep the system running through a failure

Specifications

BrandDELL
SeriesPowerEdge
ModelPowerEdge R730
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
MAX Processors2
ChipsetIntel C610
Installed Memory Size16GB
Memory TypeDDR4
Max Memory Capacity16GB
Memory Features24 DIMM slots, 12 per processor. (4GB/8GB/16GB/32GB/64GB/128GB DDR4 up to 2400MT/s, actual memory speed dependent on the processor capability)
Number of Memory Slots24
Storage ControllerDell Perc H330 Controller
SSD (Installed)No
Raid LevelRAID 0/1/5/10/50/60
Max HDD Capacity64TB
Media DrivesDVD ROM
GPU TypeMatrox G200
Video Memory8MB
Remote ManagementiDRAC8 with Lifecycle Controller, iDRAC8 Express (default), iDRAC8 Enterprise (upgrade) 8GB vFlash media (upgrade), 16GB vFlash media (upgrade)
LAN Ports4 x Ports
Expansion SlotsUp to 7 x PCIe 3.0 plus dedicated PERC slot
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight70.0000LBS

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What does the single E5-2609v3 at 1.9 GHz mean for actual workloads?

The server ships with one six-core Xeon running at 1.9 GHz, giving you 6 cores and 6 threads for entry-level virtualization, file serving or test environments. A second processor can be added later to double that capacity.

How does the H330 12Gbps RAID controller limit drive performance?

The H330 handles SAS and SATA drives at up to 12 Gbps per port and supports RAID 0, 1, 5, 10, 50 and 60, but it has no write-back cache, so sustained write throughput will be lower than on a cached controller.

What rack space and mounting hardware does the 2U chassis require?

The unit is 2U high (3.4") and 26.8" deep, fitting a standard four-post rack; rail kit and bezel are not included, so you will need to source compatible sliding rails separately.
