Silver 2U rack server with eight 2.5-inch drive bays and redundant power supplies

DELL

DELL PowerEdge R730 2U rack server E5-2609 v3 1.9GHz 128GB DDR4 2x 300GB SAS H330

SKU CH-KT09-98T3T

2U rack server with a six-core Xeon at 1.9 GHz, 128 GB DDR4, two 300 GB SAS drives and a PERC H330 RAID controller

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • MAX Processors2
  • ChipsetIntel C610

Installed Memory Size 128GB

HDD 2 x 300GB

  • Six-core Xeon processor at 1.9 GHz handles parallel workloads
  • 128 GB DDR4 memory fills all 24 DIMM slots for large datasets
  • Two 300 GB 15K SAS drives deliver fast sequential access
  • H330 RAID controller supports RAID 0, 1, 5, 10, 50, 60
  • Dual 750 W redundant power supplies keep the server running

2U rack server for dense compute

The Dell PowerEdge R730 fits two processors and 24 DDR4 DIMM slots into a 2U chassis. It ships with a single Xeon E5-2609 v3 six-core processor at 1.9 GHz and 128 GB of memory already installed. The platform targets workloads that need high core density and large memory capacity in a standard rack footprint.

SAS and SATA drive limits

Eight 2.5-inch hot-plug bays accept SAS or SATA drives behind the integrated H330 controller. The controller supports RAID 0, 1, 5, 10, 50 and 60 with a 12 Gbps interface. Maximum raw capacity reaches 64 TB when all bays are populated with supported drives.

Memory ceiling fixed at 128 GB

The specification lists maximum memory capacity as 128 GB, matching the installed amount. All 24 DIMM slots are therefore occupied, leaving no room for expansion. Buyers who need more than 128 GB must choose a different server model.

Highlights

  • Six-core Xeon processor at 1.9 GHz handles parallel workloads
  • 128 GB DDR4 memory fills all 24 DIMM slots for large datasets
  • Two 300 GB 15K SAS drives deliver fast sequential access
  • H330 RAID controller supports RAID 0, 1, 5, 10, 50, 60
  • Dual 750 W redundant power supplies keep the server running

Specifications

BrandDELL
SeriesPowerEdge
ModelPowerEdge R730
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
MAX Processors2
ChipsetIntel C610
Installed Memory Size128GB
Memory TypeDDR4
Max Memory Capacity128GB
Memory Features24 DIMM slots, 12 per processor. (4GB/8GB/16GB/32GB/64GB/128GB DDR4 up to 2400MT/s, actual memory speed dependent on the processor capability)
Number of Memory Slots24
Storage ControllerDell Perc H330 Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/10/50/60
Max HDD Capacity64TB
Media DrivesDVD ROM
GPU TypeMatrox G200
Video Memory8MB
Remote ManagementiDRAC8 with Lifecycle Controller, iDRAC8 Express (default), iDRAC8 Enterprise (upgrade) 8GB vFlash media (upgrade), 16GB vFlash media (upgrade)
LAN Ports4 x Ports
Expansion SlotsUp to 7 x PCIe 3.0 plus dedicated PERC slot
Operating SystemNo
Compatible/Certified OSMicrosoft Windows Small Business Server 2011/2008, Microsoft Windows Server 2008 R2 SP1/SP2, Microsoft Windows HPC Server 2008 R2, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Oracle Solaris
Weight70.0000LBS

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Should I choose the single E5-2609 v3 or add a second processor for my workload?

The system board accepts up to two Xeon E5-2609 v3 CPUs; adding the second doubles core count to twelve and unlocks the remaining twelve DIMM slots for memory expansion beyond the installed 128GB.

What does the 1.9 GHz clock speed mean for actual performance in this 2U rack server?

Each of the six cores runs at a fixed 1.9 GHz with no Turbo Boost, so sustained throughput is predictable for multi-threaded tasks such as virtualisation hosts or database nodes.

How does the H330 12Gbps RAID controller limit drive performance in practice?

The H330 caps each SAS lane at 12 Gbps and supports RAID 0/1/5/10/50/60, so the installed 300 GB 15K drives and any additional SAS or SATA drives are limited by that 12 Gbps link speed.
