Silver 2U rack server front with eight 2.5-inch drive trays and bezel

DELL

DELL PowerEdge R730 rack server 2x Xeon E5-2680 v4 2.4GHz 14-core 64GB DDR4 H730 8x 2.5" trays

SKU CH-W5DF-JQPAZ

2U rack server with dual 14-core Xeon CPUs at 2.4 GHz, 64 GB DDR4 ECC, H730 RAID controller, eight 2.5-inch drive trays, quad-port 1 GbE and 10 Gb SFP+ networking, iDRAC8 Enterprise.

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.40 GHz
  • CPU SocketLGA 2011-3
  • Dual Xeon E5-2680 v4 CPUs deliver 28 cores at 2.4 GHz base and 3.3 GHz turbo
  • 64 GB DDR4 2400 MHz registered ECC memory scales to 1.5 TB across 24 slots
  • PERC H730 1 GB controller supports RAID 0 1 5 6 10 50 60 with battery backup
  • Intel X520 I350 daughter card provides two 1 GbE and two 10 Gb SFP+ ports
  • iDRAC 8 Enterprise plus dual 750 W platinum PSUs enable remote management and redundant power

Dual 14-core Xeon server for virtualised workloads

The Dell PowerEdge R730 is a 2U rack server fitted with two Intel Xeon E5-2680 v4 processors running at 2.4 GHz with a 3.3 GHz turbo. Fourteen cores per socket and 64 GB of DDR4-2400 registered ECC memory give strong multi-threaded capacity for virtualisation, database and HPC data-node roles. The system ships with a PERC H730 1 GB RAID controller and eight 2.5-inch SAS/SATA drive trays.

Suited to mixed read-write arrays.

The eight-bay chassis and H730 controller target workloads that benefit from RAID 0/1/5/6/10/50/60 across spinning disks or SATA SSDs. Buyers who need more than eight internal drive bays or a different storage controller should evaluate other platforms. The included X520/I350 daughter card provides two 1 GbE and two 10 Gb SFP+ ports for typical rack networking.

DDR4-2400 registered ECC memory ceiling 1.5 TB

Twenty-four DIMM slots support up to 1.5 TB of DDR4-2400 registered ECC memory, so capacity can grow well beyond the factory 64 GB. Confirm that any additional modules match the registered ECC specification and 2400 MHz speed before ordering.

Highlights

  • Dual Xeon E5-2680 v4 CPUs deliver 28 cores at 2.4 GHz base and 3.3 GHz turbo
  • 64 GB DDR4 2400 MHz registered ECC memory scales to 1.5 TB across 24 slots
  • PERC H730 1 GB controller supports RAID 0 1 5 6 10 50 60 with battery backup
  • Intel X520 I350 daughter card provides two 1 GbE and two 10 Gb SFP+ ports
  • iDRAC 8 Enterprise plus dual 750 W platinum PSUs enable remote management and redundant power

Specifications

BrandDELL
SeriesPowerEdge R730
ModelR730
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.40 GHz
CPU SocketLGA 2011-3
Number of CPU Cores14-Core Processor
# of Processors Installed2
MAX Processors2
ChipsetIntel C610
Installed Memory Size64GB
Memory TypeDDR4
Max Memory Capacity1.5TB
Number of Memory Slots24
Storage ControllerDell Perc H730 1GB Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerDell Intel X520/I350 Quad Port 2x 1GbE 2x 10Gb SFP+ Network Daughter Card
LAN Ports4 x Ports
Expansion Slots1 x PCIe 3.0 x16 Slot, Single Riser Included (Riser 3)
Management PortRJ 45
Operating SystemNo
Features8 x 2.5" SATA/SAS Hot-Plug Drive Bays

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What SAS speed does the H730 controller support, and how does that limit drive throughput?

The PERC H730 is a 12Gb/s SAS controller, so each 2.5" bay is capped at 12Gb/s per drive.

What rack depth and mounting hardware does the 2U chassis require?

The server includes Dell Ready Rails for square-hole or round-hole racks and needs a standard 2U vertical space.

How is the PERC H730 battery installed, and what step is often missed?

The battery plugs into the controller's dedicated header; the step often missed is seating the connector fully until it clicks.
