Dell PowerEdge R730xd 2U rack server front view with twelve 3.5 inch drive bays and bezel

DELL

DELL PowerEdge R730xd 2U 12 Bay 3.5" 2x Xeon E5-2620 v3 2.4GHz 64GB DDR4 12x 8TB H730 X520/I350 iDRAC8 2x 750W

SKU CH-4FP0-699FF

2U rack server with dual 2.4 GHz 6-core Xeon processors, 64 GB DDR4 ECC memory, twelve 8 TB 3.5-inch SATA drives on a PERC H730 controller, quad-port 1/10 GbE networking.

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.40 GHz
  • CPU SocketLGA 2011-3
  • Dual Xeon E5-2620 v3 CPUs deliver 12 cores at 2.4 GHz base with 3.2 GHz turbo
  • 64 GB DDR4 2133 MHz registered ECC memory installed across 4 slots with 24 total slots supporting 1.5 TB max
  • PERC H730 1 GB controller enables RAID 0, 1, 5, 6, 10, 50, 60 plus pass-through mode
  • 12 enterprise 8 TB 7.2K SATA 3.5-inch drives provide high-capacity storage
  • X520/I350 quad-port card adds two 1 GbE and two 10 Gb SFP+ connections with iDRAC8 Enterprise remote management

Purpose-built storage server

The Dell PowerEdge R730xd is a 2U rack server populated with twelve 3.5-inch bays, dual Intel Xeon E5-2620 v3 processors at 2.4 GHz and 64 GB of DDR4 ECC memory. A PERC H730 controller with 1 GB cache manages the twelve installed 8 TB 7.2 K SATA drives, while an Intel X520/I350 daughter card adds two 1 GbE and two 10 Gb SFP+ ports. iDRAC 8 Enterprise and dual 750 W platinum supplies complete the configuration.

Who this suits and who should look elsewhere

This system fits teams that need dense, hot-swap SATA capacity behind a hardware RAID engine with dual-socket compute and out-of-band management. Buyers who require more than 24 DIMM slots, more than two processor sockets, or SSD-optimised all-flash performance should evaluate other platforms. The fixed 12-bay 3.5-inch chassis also limits deployments needing 2.5-inch density or additional PCIe expansion beyond the integrated networking.

Deciding specification: 12 x 8 TB SATA drives

The twelve 8 TB 7.2 K SATA drives delivered on the PERC H730 controller define the raw capacity and RAID flexibility of the platform. With support for RAID 0, 1, 5, 6, 10, 50 and 60 plus pass-through, this single specification determines whether the storage density and redundancy model match the workload.

Highlights

  • Dual Xeon E5-2620 v3 CPUs deliver 12 cores at 2.4 GHz base with 3.2 GHz turbo
  • 64 GB DDR4 2133 MHz registered ECC memory installed across 4 slots with 24 total slots supporting 1.5 TB max
  • PERC H730 1 GB controller enables RAID 0, 1, 5, 6, 10, 50, 60 plus pass-through mode
  • 12 enterprise 8 TB 7.2K SATA 3.5-inch drives provide high-capacity storage
  • X520/I350 quad-port card adds two 1 GbE and two 10 Gb SFP+ connections with iDRAC8 Enterprise remote management

Specifications

BrandDELL
SeriesPowerEdge R730XD
ModelR730xd
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.40 GHz
CPU SocketLGA 2011-3
Number of CPU Cores6-Core Processor
# of Processors Installed2
MAX Processors2
ChipsetIntel C610
Installed Memory Size64GB
Memory TypeDDR4
Max Memory Capacity1.5TB
Number of Memory Slots24
Storage ControllerDell Perc H730 1GB Controller
HDD InterfaceSATA
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerDell Intel X520/I350 Quad Port 2x 1GbE 2x 10Gb SFP+ Network Daughter Card
LAN Ports4 x Ports
Expansion Slots1 x PCIe 3.0 x16 Slot, Single Riser Included (Riser 3)
Management PortRJ 45
Operating SystemNo
Features12 x 3.5" SATA/SAS Hot-Plug Drive Bays

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Will the LGA 2011-3 socket and C610 chipset accept the DDR4 modules I already have?

The server uses DDR4 registered ECC memory in 24 slots; only DDR4 RDIMMs or LRDIMMs are supported, not unbuffered desktop modules.

How can I confirm the H730 controller and all twelve 8 TB drives are healthy after first boot?

Open the iDRAC8 Enterprise interface or the PERC H730 BIOS utility to view controller battery status, drive SMART data and virtual-disk state.

Which items ship in the box and what must be sourced separately?

Included are the 2U chassis with bezel, ready rails, two 750 W PSUs, two Xeon E5-2620 v3 CPUs, 64 GB DDR4, H730 controller, twelve 8 TB SATA drives and the X520/I350 quad-port card. SFP+ transceivers are not included.
