Silver 2U rack server with 24 front drive bays and front bezel

DELL

DELL PowerEdge R730xd 2U 24-Bay 2x Xeon E5-2680 v4 14C 2.4GHz 128GB DDR4 H730 2x 800GB SSD

SKU CH-2G56-Q2PVC

2U rack server with twenty-four 2.5-inch drive bays, dual 14-core Xeon processors at 2.4 GHz, 128 GB DDR4 ECC memory, PERC H730 RAID controller, two 800 GB SATA SSDs.

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.40 GHz
  • CPU SocketLGA 2011-3
  • Dual 14-core Xeon processors at 2.4 GHz with 3.3 GHz turbo for demanding compute workloads
  • 128 GB DDR4 registered ECC memory across eight 16 GB modules for large virtualisation capacity
  • PERC H730 1 GB controller supports RAID 0, 1, 5, 6, 10, 50 and 60 for flexible data protection
  • Two 800 GB enterprise SATA SSDs deliver fast read performance for database and VDI workloads
  • Dual 750 W platinum power supplies with hot-swap redundancy keep the 2U chassis running continuously

Dell PowerEdge R730xd 24-bay server

The Dell PowerEdge R730xd is a 2U rack server fitted with two 14-core Intel Xeon E5-2680 v4 processors at 2.4 GHz and 128 GB of DDR4 registered ECC memory. A PERC H730 controller with 1 GB cache manages the 24 hot-swap 2.5-inch drive bays, currently populated by two 800 GB SATA SSDs. Dual 750 W platinum power supplies and iDRAC 8 Enterprise remote management complete the platform.

Suits virtualisation and storage-heavy workloads

This server suits teams running databases, virtual desktop infrastructure or data-warehouse nodes that benefit from high core counts and dense 2.5-inch drive bays. The quad-port network daughter card provides two 1 GbE and two 10 Gb SFP+ links for flexible connectivity. Buyers who need more than two processors or memory beyond 1.5 TB capacity should look at larger platforms.

24-bay 2.5-inch chassis with PERC H730 RAID

The single specification that decides fit is the 24-bay 2.5-inch chassis paired with the PERC H730 controller supporting RAID 0, 1, 5, 6, 10, 50 and 60. This combination determines how many drives you can install and which RAID levels are available for your storage layout.

Highlights

  • Dual 14-core Xeon processors at 2.4 GHz with 3.3 GHz turbo for demanding compute workloads
  • 128 GB DDR4 registered ECC memory across eight 16 GB modules for large virtualisation capacity
  • PERC H730 1 GB controller supports RAID 0, 1, 5, 6, 10, 50 and 60 for flexible data protection
  • Two 800 GB enterprise SATA SSDs deliver fast read performance for database and VDI workloads
  • Dual 750 W platinum power supplies with hot-swap redundancy keep the 2U chassis running continuously

Specifications

BrandDELL
SeriesPowerEdge R730XD
ModelR730xd
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.40 GHz
CPU SocketLGA 2011-3
Number of CPU Cores14-Core Processor
# of Processors Installed2
MAX Processors2
ChipsetIntel C610
Installed Memory Size128GB
Memory TypeDDR4
Max Memory Capacity1.5TB
Number of Memory Slots24
Storage ControllerDell Perc H730 1GB Controller
HDD InterfaceSATA
SSD (Installed)2 x 800GB SATA SSD
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerDell Intel X520/I350 Quad Port 2x 1GbE 2x 10Gb SFP+ Network Daughter Card
LAN Ports4 x Ports
Expansion Slots1 x PCIe 3.0 x16 Slot, Single Riser Included (Riser 3)
Management PortRJ 45
Operating SystemNo
Features24 x 2.5" SATA/SAS Hot-Plug Drive Bays

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How can I confirm the PERC H730 controller is operating correctly after installation?

During POST the controller initialises and displays its firmware version and battery status; the iDRAC8 Enterprise dashboard then shows all 24 drive bays, the two 800GB SSDs and any configured virtual disks with a green health indicator.

Which components are included and which must be sourced separately?

The unit ships with two Xeon E5-2680 v4 processors, eight 16GB DDR4 RDIMMs totalling 128GB, the PERC H730 1GB controller with battery, two 800GB SATA SSDs, the X520/I350 quad-port network daughter card, iDRAC8 Enterprise, two 750W platinum power supplies, bezel and ready rails; additional drives or memory modules are not included.

Should I choose this 128GB configuration or add more memory for virtualisation workloads?

The system has 24 DDR4 slots and supports up to 1.5TB; with eight slots populated by 16GB modules there are 16 free slots, so extra capacity can be added later if VM density demands it.
