Silver 2U rack server with 24 front 2.5-inch drive bays, bezel and rails

DELL

DELL PowerEdge R730xd 2U rack server 2x Xeon E5-2683 v3 2.0GHz 14-core 256GB DDR4 24x 800GB SSD H730

SKU CH-Z9SA-WAFJV

2U rack server with dual 14-core Xeon processors, 256GB DDR4 memory, 24 hot-swap 800GB SSDs and PERC H730 RAID controller

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.00 GHz
  • CPU SocketLGA 2011-3
  • 28 cores at 2.0 GHz with 3.0 GHz turbo accelerate heavy workloads
  • 256 GB DDR4 2133 MHz ECC memory supports large virtualisation environments
  • PERC H730 1 GB controller enables RAID 0/1/5/6/10/50/60 flexibility
  • 24 x 800 GB enterprise SATA SSDs provide high-density flash storage
  • iDRAC8 Enterprise with X520/I350 quad-port networking simplifies remote management

24-bay 2U rack server for dense storage workloads

This 2U rack server delivers 24 front-accessible 2.5-inch drive bays in a compact chassis. Dual Xeon E5-2683 v3 processors provide 28 total cores at 2.0GHz with 3.0GHz turbo. The 256GB DDR4 ECC memory supports virtualization and database tasks. It is built for organizations that need high local capacity in minimal rack space.

SATA SSD limits and 12Gb/s controller throughput

The 24 installed 800GB drives use the SATA 6Gb/s interface, capping sequential throughput at the SATA link speed. The PERC H730 controller operates on a 12Gb/s SAS/SATA bus, so the drives cannot saturate the controller bandwidth. RAID 0/1/5/6/10/50/60 and pass-through modes are available, but write-heavy workloads will hit the SATA device ceiling before the controller limit.

24x 800GB SATA SSD capacity fixed at purchase

The server ships with 24 populated bays, leaving no empty slots for expansion without removing existing drives. Total raw capacity is fixed at the installed 800GB per drive. Buyers who need more storage must replace drives with larger models or add external enclosures. The 24 DIMM slots and dual-socket maximum are also fully populated, so memory and CPU growth require module or processor replacement.

Highlights

  • 28 cores at 2.0 GHz with 3.0 GHz turbo accelerate heavy workloads
  • 256 GB DDR4 2133 MHz ECC memory supports large virtualisation environments
  • PERC H730 1 GB controller enables RAID 0/1/5/6/10/50/60 flexibility
  • 24 x 800 GB enterprise SATA SSDs provide high-density flash storage
  • iDRAC8 Enterprise with X520/I350 quad-port networking simplifies remote management

Specifications

BrandDELL
SeriesPowerEdge R730XD
ModelR730xd
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.00 GHz
CPU SocketLGA 2011-3
Number of CPU Cores14-Core Processor
# of Processors Installed2
MAX Processors2
ChipsetIntel C610
Installed Memory Size256GB
Memory TypeDDR4
Max Memory Capacity1.5TB
Number of Memory Slots24
Storage ControllerDell Perc H730 1GB Controller
HDD InterfaceSATA
SSD (Installed)24 x 800GB SATA SSD
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerDell Intel X520/I350 Quad Port 2x 1GbE 2x 10Gb SFP+ Network Daughter Card
LAN Ports4 x Ports
Expansion Slots1 x PCIe 3.0 x16 Slot, Single Riser Included (Riser 3)
Management PortRJ 45
Operating SystemNo
Features24 x 2.5" SATA/SAS Hot-Plug Drive Bays

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Should I choose the 24-bay 2.5" configuration or look for a different drive-count version?

This unit is the 24-bay 2.5" model; it ships with 24 x 800GB SATA SSDs already installed, filling every bay.

What does the dual 14-core Xeon setup deliver for virtualisation workloads?

Two E5-2683 v3 CPUs give 28 cores at 2.0 GHz base with 3.0 GHz turbo, supporting heavy VM density on the C610 chipset.

How does the PERC H730 controller limit the 800GB SATA SSDs in practice?

The H730 runs at 12Gb/s SAS/SATA with 1GB cache and battery backup, so the 6Gb/s SSDs operate at their native SATA speed under RAID 0/1/5/6/10/50/60.
