Silver 2U rack server front panel showing eight 3.5-inch drive bays

DELL

DELL PowerEdge R740 8LFF 2x Xeon Platinum 8260L 64GB DDR4 rack server

SKU CH-61F6-RWCMT

Rack server with dual Xeon Platinum 8260L processors, 64 GB DDR4 memory, eight 3.5-inch drive bays and PERC H730P RAID controller

  • TypeRack
  • CPU TypeIntel Xeon
  • CPU Speed2.4GHz
  • # of Processors Installed2
  • MAX Processors2
  • Installed Memory Size64GB
  • Dual Xeon Platinum 8260L CPUs provide 24 cores each for parallel workloads
  • 64 GB DDR4 ECC memory supports large datasets and virtualisation
  • Eight 3.5-inch drive bays with PERC H730P RAID controller enable flexible storage
  • iDRAC9 Enterprise licence gives full remote management and monitoring
  • Dual 750 W power supplies and 10 GbE 562T adapter ensure uptime and throughput

Dual Xeon Platinum 8260L server

The Dell PowerEdge R740 chassis arrives with two Xeon Platinum 8260L processors running at 2.4GHz, each delivering 24 cores and 35.75MB cache. 64GB of DDR4 ECC registered memory is installed across the available slots. The system targets virtualization hosts, database nodes and compute clusters that need high core counts in a 2U rack form factor.

8-bay 3.5 storage headroom

Eight front-accessible 3.5-inch bays connect to the PERC H730P RAID controller over SATA. No drives ship with the unit so capacity starts at zero and scales to the limit of the installed disks. The controller supports hardware RAID levels for redundancy or throughput, but the 10GbE 562T adapter and dual 750W supplies remain the same regardless of drive count.

DDR4 memory ceiling and PCIe constraints

The platform accepts up to 3TB of DDR4 when fully populated, leaving substantial headroom above the factory 64GB. Growth beyond that ceiling requires a newer processor generation not present in this chassis. The integrated graphics and iDRAC9 Enterprise remote management operate within the existing PCIe lane budget, so additional accelerator cards must fit the remaining slots and power envelope.

Highlights

  • Dual Xeon Platinum 8260L CPUs provide 24 cores each for parallel workloads
  • 64 GB DDR4 ECC memory supports large datasets and virtualisation
  • Eight 3.5-inch drive bays with PERC H730P RAID controller enable flexible storage
  • iDRAC9 Enterprise licence gives full remote management and monitoring
  • Dual 750 W power supplies and 10 GbE 562T adapter ensure uptime and throughput

Specifications

BrandDELL
SeriesPowerEdge
ModelRack Mount
TypeRack
CPU TypeIntel Xeon
CPU Speed2.4GHz
# of Processors Installed2
MAX Processors2
Installed Memory Size64GB
Memory TypeDDR4
Max Memory Capacity3TB
Hard Drive (Installed)16,00
Storage ControllerDell PERC H730P Controller
HDD InterfaceSATA
GPU TypeIntegrated Graphics
Remote ManagementiDRAC9 - Enterprise License
Dimensions36 x 24 x 10 in
Weight40

Questions about this item

Will the 2.4 GHz Xeon Platinum 8260L CPUs and PERC H730P controller work with my existing 3.5" SATA drives?

Yes, the 8LFF chassis accepts up to eight 3.5" SATA drives and the PERC H730P controller manages them through the backplane.

How can I verify the dual 24-core Xeon Platinum 8260L processors and 64 GB DDR4 ECC memory are recognised after installation?

Check the iDRAC9 Enterprise interface or BIOS POST screen; both will list two 2.4 GHz CPUs with 35.75 MB cache each and 64 GB DDR4 registered memory.

Does the server ship with drive caddies and rails, or must I order them separately?

The unit includes the PERC H730P controller, dual 750 W power supplies and a 10 GbE 562T adapter; drive caddies and rail kit are not included and must be purchased separately.
