Silver 2U rack server front with 24 drive bays and bezel

DELL

DELL PowerEdge R740xd 2U rack server 2x Xeon Gold 6134 3.2GHz 64GB DDR4 24x 800GB SSD

SKU CH-4M49-X9A23

Dual 8-core Xeon Gold 6134 processors, 64GB DDR4 ECC memory, and 24 hot-swap 800GB SATA SSDs behind a PERC H730P RAID controller in a 2U rack chassis

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed3.20 GHz
  • CPU SocketLGA 3647
  • Dual Xeon Gold 6134 CPUs at 3.2 GHz base speed deliver high compute throughput
  • 64 GB DDR4 registered ECC memory supports demanding virtualization workloads
  • 24 enterprise 800 GB SATA SSDs provide dense all-flash storage capacity
  • PERC H730P controller enables RAID 0/1/5/6/10/50/60 for data protection
  • iDRAC9 Enterprise and quad-port 1/10 GbE give remote management and network flexibility

Purpose-built density

The PowerEdge R740xd is a 2U rack server that fits two Xeon Gold 6134 processors and 24 drive bays into a single chassis. It targets software-defined storage clusters, service-provider platforms and virtual desktop infrastructure where capacity and compute must share the same footprint.

SATA throughput ceiling

Twenty-four 800GB SSDs connect through a PERC H730P controller limited to the SATA 6Gb/s interface. The 12Gb/s SAS backplane cannot accelerate SATA media, so sustained sequential throughput tops out at the SATA link rate rather than the controller’s native speed.

Twenty-four bay maximum

The chassis accepts exactly 24 2.5-inch drives and cannot be expanded further. Buyers who need more raw capacity must add another node instead of populating additional slots in this unit.

Highlights

  • Dual Xeon Gold 6134 CPUs at 3.2 GHz base speed deliver high compute throughput
  • 64 GB DDR4 registered ECC memory supports demanding virtualization workloads
  • 24 enterprise 800 GB SATA SSDs provide dense all-flash storage capacity
  • PERC H730P controller enables RAID 0/1/5/6/10/50/60 for data protection
  • iDRAC9 Enterprise and quad-port 1/10 GbE give remote management and network flexibility

Specifications

BrandDELL
SeriesPowerEdge R740xd
ModelR740xd
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed3.20 GHz
CPU SocketLGA 3647
Number of CPU Cores8-Core Processor
# of Processors Installed2
MAX Processors2
ChipsetIntel C620
Installed Memory Size64GB
Memory TypeDDR4
Max Memory Capacity3TB
Number of Memory Slots24
Storage ControllerDell Perc H730P 2GB Controller
HDD InterfaceSATA
SSD (Installed)24 x 800GB SATA SSD
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerDell Intel X520/I350 Quad Port 2x 1GbE 2x 10Gb SFP+ Network Daughter Card
LAN Ports4 x Ports
Expansion SlotsRiser options with up to 8 PCIe Gen 3 slots, maximum of 4 x 16 slots
Management PortRJ 45
Operating SystemNo
Features24 x 2.5" SATA/SAS Hot-Plug Drive Bays

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

Should I choose the 24-bay 2.5-inch version or a different chassis?

This unit is the 24-bay 2.5-inch 2U chassis with 24 installed 800GB SATA SSDs and two Xeon Gold 6134 processors; other bay counts or drive sizes are separate configurations.

What does the 3.2 GHz base clock mean once the server is running?

Each Xeon Gold 6134 runs at 3.2 GHz base and can boost to 3.7 GHz, giving 16 total cores across two sockets for virtualization or storage workloads.

How does the PERC H730P controller limit drive performance?

The H730P provides 12 Gb/s SAS and 6 Gb/s SATA connectivity with RAID 0, 1, 5, 6, 10, 50, 60 and pass-through, capping each SSD at the SATA 6 Gb/s link speed.
