Silver 2U rack server, sixteen 2.5-inch drive bays, front bezel, ready rails

DELL

DELL PowerEdge R760 16-Bay 2U Rack Server 2x Xeon 8468 256GB DDR5 H965i 5720 iDRAC9 Datacenter 2x 1400W PSU

SKU CH-JZPJ-JK0T7

A 2U rack server with dual Xeon 8468 48-core processors, 256GB DDR5, H965i RAID, sixteen 2.5-inch bays, 5720 quad-port 1GbE and iDRAC9 Datacenter

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.1GHz (3.8GHz Turbo)
  • CPU SocketLGA 4677
  • Dual Xeon 8468 CPUs deliver 96 total cores for heavy compute
  • 256 GB DDR5-4800 ECC memory supports large-scale virtualization
  • PERC H965i RAID controller handles NVMe, SAS and SATA arrays
  • Broadcom 5720 quad-port 1 GbE OCP 3.0 adapter provides redundant networking
  • Dual 1400 W platinum PSUs with hot-swap keep the server running

Built for Enterprise Scale

The Dell PowerEdge R760 is a 2U rack server equipped with two Intel Xeon Platinum 8468 processors, each delivering 48 cores at 2.1 GHz with a 3.8 GHz turbo frequency. The system ships with 256 GB of DDR5-4800 ECC registered memory across 32 slots, providing a foundation for virtualization, AI inference, and database workloads that demand high core counts and memory bandwidth.

Installation and Common Pitfalls

The chassis includes 16 front-accessible 2.5-inch hot-swap bays and eight drive trays, while the PERC H965i controller with 8 GB NV cache manages RAID 0, 1, 5, 6, 10, 50, and 60 for SAS, SATA, and NVMe media. Installers should verify that the OCP 3.0 quad-port 1 GbE adapter and iDRAC9 Datacenter module are seated correctly, and confirm that both 1400 W platinum power supplies are locked into the redundant hot-swap bays before powering on.

Capacity Headroom and Limits

Memory can scale to 8 TB across the 32 DIMM slots, giving substantial room for in-memory databases or dense virtual machine clusters. Storage capacity is bounded by the 16-bay front panel and the RAID controller’s supported topologies, while compute is fixed at the two-socket maximum with the installed Platinum 8468 CPUs. Workloads requiring more than 96 total cores or more than 16 front drives will need additional nodes.

Highlights

  • Dual Xeon 8468 CPUs deliver 96 total cores for heavy compute
  • 256 GB DDR5-4800 ECC memory supports large-scale virtualization
  • PERC H965i RAID controller handles NVMe, SAS and SATA arrays
  • Broadcom 5720 quad-port 1 GbE OCP 3.0 adapter provides redundant networking
  • Dual 1400 W platinum PSUs with hot-swap keep the server running

Specifications

BrandDELL
SeriesPowerEdge
ModelR760
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.1GHz (3.8GHz Turbo)
CPU SocketLGA 4677
Number of CPU Cores48 Core-Processors
CPU FeaturesPlatinum 8468
# of Processors Installed2
MAX Processors2
Installed Memory Size256GB
Memory TypeDDR5
Max Memory Capacity8TB
Number of Memory Slots32
Hard Drive (Installed)None
Storage ControllerDell Perc H965i Controller
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Ethernet ControllerDell EMC Broadcom 5720 Quad Port 1GbE OCP 3.0 Network Card
Remote ManagementiDRAC9 Datacenter
LAN Ports4 x Ports
Management PortRJ 45
Operating SystemNo

Questions about this item

How do I confirm the dual Xeon 8468 processors are running at 2.1GHz base and 3.8GHz turbo after installation?

Use the iDRAC9 Datacenter interface to view real-time CPU frequency, core utilisation and thermal status for both Platinum 8468 CPUs.

Which components are included and which must be purchased separately for the 16-bay R760?

Included: 2x Xeon 8468, 256GB DDR5-4800 ECC RDIMM, H965i RAID controller with 8GB NV cache, 8x 2.5" drive trays, Broadcom 5720 quad-port 1GbE OCP 3.0 card, iDRAC9 Datacenter, 2x 1400W PSU, Ready Rails and front bezel. Drives are not installed.

Should I choose the 256GB DDR5 configuration or plan for the 8TB maximum across the 32 slots?

The server ships with 8x 32GB DDR5-4800 ECC RDIMMs filling 8 of 32 slots. Add matching modules later to scale toward the 8TB limit as workload demands grow.
