Silver 2U rack server with front drive bays and bezel

DELL

DELL PowerEdge R760 2U rack server 2× Xeon Gold 6430 32-core 512GB DDR5 H965i

SKU CH-JE0P-Y1ASH

2U rack server with dual 32-core Xeon Gold 6430 processors at 2.1GHz, 512GB DDR5 memory, PERC H965i RAID controller, quad-port 1GbE networking, iDRAC9 Datacenter management.

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.1GHz (3.4GHz Turbo)
  • CPU SocketLGA 4677
  • Dual Xeon Gold 6430 CPUs deliver 64 total cores for heavy compute
  • 512GB DDR5-4800 ECC memory supports large datasets and virtualization
  • PERC H965i RAID controller with 8GB NV cache accelerates storage performance
  • Sixteen 2.5" hot-swap bays enable flexible SAS, SATA, SSD and NVMe configurations
  • iDRAC9 Datacenter plus quad 1GbE OCP 3.0 simplify remote management and networking

Dual-socket Xeon server for heavy compute

The PowerEdge R760 fits two Xeon Gold 6430 processors, each running at 2.1GHz with a 3.4GHz turbo frequency and 32 cores. Together they provide 64 cores in a 2U chassis that supports 4th and 5th Generation Intel Xeon Scalable processors. The system ships with 512GB of DDR5-4800 ECC registered memory installed across 16 modules, leaving 16 of the 32 total slots free for expansion up to 8TB.

Redundant platinum power and managed airflow

Two hot-swap 1400 watt platinum-efficiency power supplies deliver redundant power for continuous operation. The 2U rack form factor uses managed airflow to cool the dual processors, memory and storage subsystem under sustained load. iDRAC9 Datacenter provides remote thermal monitoring and power management without requiring host OS access.

Sixteen-bay storage and quad 1GbE networking

The front panel holds 16 hot-swap 2.5-inch bays supporting SAS, SATA and NVMe drives; four drive trays are included. A PERC H965i controller with 8GB NV cache manages RAID 0, 1, 5, 6, 10, 50 and 60 across those bays. A Broadcom 5720 OCP 3.0 card adds four 1GbE ports, and Ready Rails with a front bezel are supplied for rack mounting.

Highlights

  • Dual Xeon Gold 6430 CPUs deliver 64 total cores for heavy compute
  • 512GB DDR5-4800 ECC memory supports large datasets and virtualization
  • PERC H965i RAID controller with 8GB NV cache accelerates storage performance
  • Sixteen 2.5" hot-swap bays enable flexible SAS, SATA, SSD and NVMe configurations
  • iDRAC9 Datacenter plus quad 1GbE OCP 3.0 simplify remote management and networking

Specifications

BrandDELL
SeriesPowerEdge
ModelR760
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.1GHz (3.4GHz Turbo)
CPU SocketLGA 4677
Number of CPU Cores32 Core-Processors
CPU FeaturesGold 6430
# of Processors Installed2
MAX Processors2
Installed Memory Size512GB
Memory TypeDDR5
Max Memory Capacity8TB
Number of Memory Slots32
Hard Drive (Installed)None
Storage ControllerDell Perc H965i Controller
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Ethernet ControllerDell EMC Broadcom 5720 Quad Port 1GbE OCP 3.0 Network Card
Remote ManagementiDRAC9 Datacenter
LAN Ports4 x Ports
Management PortRJ 45
Operating SystemNo

Questions about this item

How do I install the server into a standard rack and what is the step most people miss?

Slide the unit onto the included Ready Rails, secure the front mounting ears, then attach the cable-management arm before powering on — skipping the arm blocks airflow.

Which components will need replacement first during long-term operation?

The two 1400 W hot-swap power supplies and the cooling fans are the only field-replaceable wear items; both can be swapped without shutting down.

What thermal or power limit appears first when both Xeon Gold 6430 CPUs run at 3.4 GHz turbo continuously?

The 1400 W platinum power supplies set the ceiling; sustained all-core turbo on both 32-core processors will hit that limit before the chassis cooling does.
