Silver 2U rack server with sixteen 2.5-inch drive bays and dual power supplies

DELL

DELL PowerEdge R760 2U Rack Server 2x Xeon Gold 6430 2.1GHz 32C 64GB DDR5 H965i 16x 2.5" 5720 iDRAC9 2x 1400W

SKU CH-KJN9-6DTH7

Dual Xeon Gold 6430 32-core rack server with 64GB DDR5, H965i RAID, sixteen 2.5″ trays and redundant 1400W power

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.1GHz (3.4GHz Turbo)
  • CPU SocketLGA 4677
  • Dual Xeon Gold 6430 CPUs deliver 64 cores at 2.1 GHz base clock
  • 64 GB DDR5-4800 ECC memory scales to 8 TB across 32 slots
  • PERC H965i RAID controller with 8 GB NV cache supports RAID 0/1/5/6/10/50/60
  • Sixteen 2.5" hot-swap drive trays plus quad-port 1 GbE OCP 3.0 networking
  • iDRAC9 Datacenter remote management and dual 1400 W platinum power supplies

DELL PowerEdge R760 2U Server

The DELL PowerEdge R760 is a 2U rack server built for enterprise workloads. It ships with two Intel Xeon Gold 6430 processors and 64GB of DDR5-4800 ECC memory. The system supports virtualization, AI, databases and software-defined storage. Buyers needing a tower form factor or single-socket configuration should look elsewhere.

Dual Xeon Gold 6430 32-Core CPUs

Two Intel Xeon Gold 6430 processors provide 32 total cores running at 2.1GHz with 3.4GHz turbo capability. The LGA 4677 socket platform supports DDR5 memory across 32 DIMM slots with 8TB maximum capacity. This configuration is fixed at the dual-processor limit. Workloads requiring more than two sockets cannot be accommodated by this platform.

Redundant 1400W Platinum Power Supplies

Dual 1400W Platinum-efficiency power supplies deliver redundant hot-swap power for continuous operation. The 2U chassis uses forced-air cooling across sixteen 2.5-inch drive bays and expansion slots. iDRAC9 Datacenter provides out-of-band thermal monitoring and fan-speed management. Environments without rack airflow or redundant power distribution will not meet the cooling and uptime requirements.

Highlights

  • Dual Xeon Gold 6430 CPUs deliver 64 cores at 2.1 GHz base clock
  • 64 GB DDR5-4800 ECC memory scales to 8 TB across 32 slots
  • PERC H965i RAID controller with 8 GB NV cache supports RAID 0/1/5/6/10/50/60
  • Sixteen 2.5" hot-swap drive trays plus quad-port 1 GbE OCP 3.0 networking
  • iDRAC9 Datacenter remote management and dual 1400 W platinum power supplies

Specifications

BrandDELL
SeriesPowerEdge
ModelR760
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.1GHz (3.4GHz Turbo)
CPU SocketLGA 4677
Number of CPU Cores32 Core-Processors
CPU FeaturesGold 6430
# of Processors Installed2
MAX Processors2
Installed Memory Size64GB
Memory TypeDDR5
Max Memory Capacity8TB
Number of Memory Slots32
Hard Drive (Installed)None
Storage ControllerDell Perc H965i Controller
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Ethernet ControllerDell EMC Broadcom 5720 Quad Port 1GbE OCP 3.0 Network Card
Remote ManagementiDRAC9 Datacenter
LAN Ports4 x Ports
Management PortRJ 45
Operating SystemNo

Questions about this item

What does the 2.1 GHz base clock mean when both Xeon Gold 6430 CPUs are under full load?

Each of the two Gold 6430 processors runs at 2.1 GHz base frequency with 32 cores; under sustained full load the server maintains that frequency across all 64 cores, while the 3.4 GHz turbo can engage on fewer cores when thermal headroom allows.

What does the OCP 3.0 slot provide for the installed Broadcom 5720 quad-port 1 GbE card?

The OCP 3.0 mezzanine slot delivers PCIe Gen5 x16 bandwidth to the 5720 adapter, so the four 1 GbE ports operate at line rate without sharing throughput with other expansion cards.

How many 2.5-inch drive trays fit in the front and what drive types do they accept?

Sixteen hot-swap 2.5-inch trays are populated; each tray accepts SAS, SATA or NVMe SSDs and HDDs, all connected to the H965i RAID controller with 8 GB NV cache.
