Silver 2U rack server front with sixteen 2.5-inch drive bays and bezel

DELL

DELL PowerEdge R760 2U rack server 2x Xeon Platinum 8468 48-core 2.1GHz 256GB DDR5 16-bay

SKU CH-834E-Y90SJ

A 2U rack server with dual 48-core Xeon Platinum 8468 CPUs at 2.1 GHz, 256 GB DDR5 memory, 16 hot-swap 2.5-inch drive bays, H965i RAID controller, quad-port 1 GbE networking.

  • TypeRack
  • Rack Height2U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.1GHz (3.8GHz Turbo)
  • CPU SocketLGA 4677
  • Dual Xeon Platinum 8468 CPUs deliver 96 cores at 2.1 GHz base and 3.8 GHz turbo
  • 256 GB DDR5-4800 ECC memory across 8 modules supports up to 8 TB total capacity
  • PERC H965i RAID controller with 8 GB NV cache enables RAID 0, 1, 5, 6, 10, 50, 60 for NVMe and SAS/SATA drives
  • Sixteen 2.5" hot-swap bays plus OCP 3.0 quad-port 1 GbE and iDRAC9 Datacenter provide flexible storage and remote management
  • Redundant 1400 W platinum power supplies and 2U rack form factor ensure high availability in dense deployments

Enterprise 2U rack server

The Dell PowerEdge R760 is a 2U rack server built for enterprise workloads. Two Intel Xeon Platinum 8468 processors provide 48 cores each at 2.1GHz with 3.8GHz turbo. The system ships with 256GB of DDR5 memory across 32 slots and includes iDRAC9 Datacenter for remote management.

Build integration

Sixteen 2.5-inch hot-swap drive bays accept SAS, SATA and NVMe media through the PERC H965i RAID controller. Dual 1400W hot-swap power supplies and a quad-port 1GbE OCP 3.0 card are installed. PCI Express Gen5 slots remain available for additional accelerators or networking.

Capacity and headroom

Memory scales to 8TB across the 32 DDR5 slots for large virtualization or in-memory databases. The H965i supports RAID 0, 1, 5, 6, 10, 50 and 60 with 8GB NV cache. Buyers needing more than two processors or integrated GPU compute will need a different platform.

Highlights

  • Dual Xeon Platinum 8468 CPUs deliver 96 cores at 2.1 GHz base and 3.8 GHz turbo
  • 256 GB DDR5-4800 ECC memory across 8 modules supports up to 8 TB total capacity
  • PERC H965i RAID controller with 8 GB NV cache enables RAID 0, 1, 5, 6, 10, 50, 60 for NVMe and SAS/SATA drives
  • Sixteen 2.5" hot-swap bays plus OCP 3.0 quad-port 1 GbE and iDRAC9 Datacenter provide flexible storage and remote management
  • Redundant 1400 W platinum power supplies and 2U rack form factor ensure high availability in dense deployments

Specifications

BrandDELL
SeriesPowerEdge
ModelR760
TypeRack
Rack Height2U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.1GHz (3.8GHz Turbo)
CPU SocketLGA 4677
Number of CPU Cores48 Core-Processors
CPU FeaturesPlatinum 8468
# of Processors Installed2
MAX Processors2
Installed Memory Size256GB
Memory TypeDDR5
Max Memory Capacity8TB
Number of Memory Slots32
Hard Drive (Installed)None
Storage ControllerDell Perc H965i Controller
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
Ethernet ControllerDell EMC Broadcom 5720 Quad Port 1GbE OCP 3.0 Network Card
Remote ManagementiDRAC9 Datacenter
LAN Ports4 x Ports
Management PortRJ 45
Operating SystemNo

Questions about this item

How many 2.5-inch drive bays does the R760 provide for sustained storage throughput?

The server includes sixteen 2.5-inch hot-swap bays that accept SAS, SATA, SSD or NVMe media and are served by the PERC H965i controller with 8 GB NV cache.

What is the combined thermal design power of the two Xeon Platinum 8468 CPUs and the 1400 W power supplies under continuous load?

Each Platinum 8468 runs at a 2.1 GHz base with 3.8 GHz turbo across 48 cores, and the dual 1400 W platinum supplies share the load with redundant hot-swap operation.

Which memory modules must already be on hand to reach the 256 GB DDR5-4800 ECC registered configuration?

The system ships with eight 32 GB DDR5-4800 ECC registered DIMMs installed across the 32 available slots.
