Silver 4U rack server front with 24 drive bays and bezel

DELL

Dell PowerEdge R930 24-Bay 4x Xeon E7-8867 v4 768GB DDR4 H330

SKU CH-G1B7-T802C

4U rack server with four 16-core Xeon E7-8867 v4 processors, 768 GB DDR4 memory, PERC H330 controller and 24 hot-plug 2.5" drive bays

  • Rack Height4U
  • CPU TypeIntel Xeon
  • CPU Speed2.40 GHz
  • CPU SocketLGA 2011
  • Number of CPU Cores16-Core Processor
  • # of Processors Installed4
  • Four Xeon E7-8867 v4 CPUs provide 16 cores each at 2.4 GHz with 3.30 GHz turbo
  • 768 GB DDR4 2400 MHz registered ECC memory across 48 DIMM slots
  • PERC H330 12 Gb/s controller supports RAID 0, 1, 5, 10, 50 for 24 hot-plug 2.5" drives
  • Intel X520/I350 daughter card adds two 1 GbE and two 10 Gb SFP+ ports
  • iDRAC8 Enterprise enables remote lifecycle management with four 1100 W 80+ Platinum PSUs

Built for memory-intensive workloads

The Dell PowerEdge R930 is a 4U rack server equipped with four Intel Xeon E7-8867 v4 processors, each running at 2.40 GHz with 16 cores. It ships with 768 GB of DDR4 2400 MHz registered ECC memory across 48 DIMM slots, leaving 48 slots free to reach the 12 TB maximum. This configuration targets databases, virtualization and analytics that demand high core counts and large memory capacity in a single chassis.

Thermals, noise and power draw

Four 1100 W 80+ Platinum power supplies provide redundant power delivery for the fully populated CPU and memory configuration. The 4U form factor allows ample airflow across the processor and memory zones, while the system fans are managed by the integrated iDRAC8 Enterprise controller to balance cooling against acoustic output under varying loads. Power draw scales with the number of active cores and memory modules installed.

What the bundled accessories change

The server includes 24 front-accessible 2.5-inch drive trays with screws, a Dell PERC H330 12 Gb/s SAS/SATA RAID controller supporting RAID 0, 1, 5, 10 and 50, and a quad-port network daughter card with two 1 GbE and two 10 Gb SFP+ connections. Ready Rails and a front bezel are supplied for rack mounting, and iDRAC8 Enterprise enables remote management, lifecycle automation and agent-free provisioning without additional licensing.

Highlights

  • Four Xeon E7-8867 v4 CPUs provide 16 cores each at 2.4 GHz with 3.30 GHz turbo
  • 768 GB DDR4 2400 MHz registered ECC memory across 48 DIMM slots
  • PERC H330 12 Gb/s controller supports RAID 0, 1, 5, 10, 50 for 24 hot-plug 2.5" drives
  • Intel X520/I350 daughter card adds two 1 GbE and two 10 Gb SFP+ ports
  • iDRAC8 Enterprise enables remote lifecycle management with four 1100 W 80+ Platinum PSUs

Specifications

BrandDELL
SeriesPowerEdge R930
Rack Height4U
CPU TypeIntel Xeon
CPU Speed2.40 GHz
CPU SocketLGA 2011
Number of CPU Cores16-Core Processor
# of Processors Installed4
MAX Processors4
ChipsetIntel C602J
Installed Memory Size768GB
Memory TypeDDR4
Max Memory Capacity12TB
Number of Memory Slots96
Storage ControllerDell Perc H330 Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/10/50
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerDell Intel X520/I350 Quad Port 2x 1GbE 2x 10Gb SFP+ Network Daughter Card
LAN Ports4 x Ports
Expansion Slots1 x PCIe 3.0 x16 Slot, Single Riser Included (Riser 3)
Management PortRJ 45
Operating SystemNo

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

How do I install the 48 DDR4 DIMMs across the 96 memory slots for the 4x Xeon E7-8867 v4 processors?

Populate slots in quad-channel sets per CPU, matching identical 16GB modules across all four controllers; the step often missed is leaving gaps for unpopulated channels instead of filling consecutive slots.

When will the PERC H330 controller battery-backed write cache need replacement?

The cache backup module typically lasts 3–5 years; plan replacement when iDRAC8 reports a degraded battery or during scheduled 4U chassis maintenance windows.

At what point do the 4x 1100W Platinum PSUs hit their thermal limit under sustained 96-core load?

With all four CPUs at 2.4GHz base and Turbo disabled, the power draw approaches the 1100W per supply rating; sustained Turbo to 3.30GHz can exceed cooling capacity first.
