Silver 4U rack server with front bezel, 24 drive bays and four power supplies

DELL

DELL PowerEdge R930 4U rack server 4x Xeon E7-8890 v4 2.2GHz 384GB DDR4 24x 600GB SAS

SKU CH-A5VZ-4Y200

A 4U rack server with four 24-core Xeon processors at 2.2 GHz, 384 GB DDR4, 24-bay SAS storage and quad-port 1/10 GbE networking

  • Rack Height4U
  • CPU TypeIntel Xeon
  • CPU Speed2.20 GHz
  • CPU SocketLGA 2011
  • Number of CPU Cores24-Core Processor
  • # of Processors Installed4
  • 4x Xeon E7-8890 v4 24-core CPUs deliver 96 total cores for heavy workloads
  • 384GB DDR4 2400MHz ECC memory supports large in-memory databases and virtualization
  • 24x 600GB 10K SAS drives on PERC H730P provide high-capacity RAID storage
  • Quad-port X520/I350 card adds 2x 10GbE SFP+ and 2x 1GbE connectivity
  • iDRAC8 Enterprise enables remote lifecycle management and agent-free provisioning

Enterprise four-socket server

The Dell PowerEdge R930 is a 4U rack server equipped with four Intel Xeon E7-8890 v4 processors running at 2.2 GHz with 3.4 GHz turbo. It targets organisations running memory-intensive databases, virtualisation clusters or analytics workloads that demand high core counts and large memory capacity in a single chassis.

Scales to 12 TB DDR4 across 96 slots

The system ships with 384 GB of DDR4 registered ECC memory installed across 48 modules, leaving 48 additional slots for expansion up to 12 TB. Twenty-four 2.5-inch drive bays connect to a PERC H730P controller supporting RAID 0, 1, 5, 6, 10, 50 and 60, while a quad-port network daughter card provides two 1 GbE and two 10 Gb SFP+ links. Four 1100 W platinum power supplies and iDRAC8 Enterprise remote management are included.

Sustained throughput for in-memory workloads

With 96 total cores and a memory subsystem designed for 2400 MHz DDR4, the platform maintains consistent performance during extended OLTP, SAP HANA or SQL Server runs. The H730P controller's 2 GB battery-backed cache absorbs write bursts, and the redundant power supplies keep all processors and memory online without throttling during continuous operation.

Highlights

  • 4x Xeon E7-8890 v4 24-core CPUs deliver 96 total cores for heavy workloads
  • 384GB DDR4 2400MHz ECC memory supports large in-memory databases and virtualization
  • 24x 600GB 10K SAS drives on PERC H730P provide high-capacity RAID storage
  • Quad-port X520/I350 card adds 2x 10GbE SFP+ and 2x 1GbE connectivity
  • iDRAC8 Enterprise enables remote lifecycle management and agent-free provisioning

Specifications

BrandDELL
SeriesPowerEdge R930
Rack Height4U
CPU TypeIntel Xeon
CPU Speed2.20 GHz
CPU SocketLGA 2011
Number of CPU Cores24-Core Processor
# of Processors Installed4
MAX Processors4
ChipsetIntel C602J
Installed Memory Size384GB
Memory TypeDDR4
Max Memory Capacity12TB
Number of Memory Slots96
Storage ControllerDell Perc H730P 2GB Controller
HDD InterfaceSAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8MB
Ethernet ControllerDell Intel X520/I350 Quad Port 2x 1GbE 2x 10Gb SFP+ Network Daughter Card
LAN Ports4 x Ports
Expansion Slots1 x PCIe 3.0 x16 Slot, Single Riser Included (Riser 3)
Management PortRJ 45
Operating SystemNo

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What is the first limit reached under sustained heavy compute load with four 24-core Xeon processors?

The four E7-8890 v4 CPUs top out at 3.4 GHz turbo and cannot exceed 96 total cores or 12 TB memory capacity.

How much heat and noise do four 1100 W platinum PSUs produce when the server runs 24/7?

Four 1100 W 80+ Platinum supplies deliver up to 1100 W each; actual draw depends on workload but the PSUs are rated for continuous operation.

Which network transceivers and cables are needed for the installed X520/I350 daughter card?

The daughter card provides two 1 GbE and two 10 GbE SFP+ ports; compatible SFP+ modules and matching fibre or copper cables must be supplied separately.
