DELL
DELL PowerEdge T430 16SFF 2x Xeon E5-2683 v4 192GB DDR4 rack server
A 16-bay 2.5-inch rack server with dual Xeon E5-2683 v4 processors at 2.1GHz, 192GB DDR4 memory and PERC H730 SAS controller
- TypeRack
- CPU TypeIntel Xeon
- CPU Speed2.1GHz
- # of Processors Installed2
- MAX Processors2
- Installed Memory Size192GB
- Dual Xeon E5-2683 v4 processors deliver 32 total cores for demanding workloads
- 192GB DDR4 ECC memory supports large datasets and virtualization
- 16 x 2.5" drive bays with PERC H730 SAS controller enable flexible storage arrays
- iDRAC8 Express provides remote server management and monitoring
- Dual 1100W power supplies offer redundancy for continuous operation
DELL PowerEdge T430 16SFF 2x Xeon E5-2683 v4
The DELL PowerEdge T430 is a 16-bay 2.5-inch rack server fitted with two Intel Xeon E5-2683 v4 processors running at 2.1GHz and 192GB of DDR4 ECC registered memory. It targets organisations that need dense local storage and dual-socket compute in a 2U form factor for virtualisation, database or file-serving workloads.
PERC H730 controller and iDRAC8 Express
The bundled PERC H730 SAS controller enables hardware RAID across the 16 drive bays using SATA or SAS media, while the iDRAC8 Express licence provides out-of-band remote management for power control, console redirection and firmware updates without an operating system. Two 1100W power supplies and a dual-port 1GbE 332T adapter are also installed.
384GB DDR4 ceiling and 2.5-inch bay constraint
Maximum memory capacity stops at 384GB of DDR4, so further expansion requires replacing existing modules rather than adding to empty slots. The 16 front bays accept only 2.5-inch drives, limiting raw capacity per bay compared with 3.5-inch alternatives, and the integrated graphics offers no discrete GPU option for compute acceleration.
Highlights
- Dual Xeon E5-2683 v4 processors deliver 32 total cores for demanding workloads
- 192GB DDR4 ECC memory supports large datasets and virtualization
- 16 x 2.5" drive bays with PERC H730 SAS controller enable flexible storage arrays
- iDRAC8 Express provides remote server management and monitoring
- Dual 1100W power supplies offer redundancy for continuous operation
Specifications
| Brand | DELL |
|---|---|
| Series | PowerEdge |
| Model | Rack Mount |
| Type | Rack |
| CPU Type | Intel Xeon |
| CPU Speed | 2.1GHz |
| # of Processors Installed | 2 |
| MAX Processors | 2 |
| Installed Memory Size | 192GB |
| Memory Type | DDR4 |
| Max Memory Capacity | 384GB |
| Hard Drive (Installed) | 15,36 |
| Storage Controller | Dell PERC H730 SAS Controller |
| HDD Interface | SATA |
| GPU Type | Integrated Graphics |
| Remote Management | iDRAC8 - Express License |
| Dimensions | 36 x 24 x 10 in |
| Weight | 40 |
Questions about this item
How many DDR4 memory slots remain free for future upgrades?
The system holds 192 GB of DDR4 today and supports up to 384 GB, so half the total capacity is still available for additional modules.
Which component reaches its ceiling first when the 2.1 GHz Xeon E5-2683 v4 CPUs run at full load continuously?
With both processors already installed, the CPU socket limit of 2 is reached, so compute scaling stops at the two 16-core chips.
How loud and hot does the chassis get with dual 1100 W power supplies running 24/7?
Dual 1100 W supplies share the load, keeping each unit cooler and fan speeds lower than a single supply would require.
