Silver rack-mount server chassis with sixteen 2.5-inch drive bays, front panel and rails

DELL

DELL PowerEdge T430 16SFF 2x Xeon E5-2699v4 64GB DDR4 rack server

SKU CH-E4SR-PF8MA

A 16-bay 2.5-inch rack server with dual 22-core Xeon E5-2699 v4 CPUs at 2.2 GHz, 64 GB DDR4 ECC memory and a PERC H730 SAS controller

  • TypeRack
  • CPU TypeIntel Xeon
  • CPU Speed2.2GHz
  • # of Processors Installed2
  • MAX Processors2
  • Installed Memory Size64GB
  • Dual Xeon E5-2699 v4 processors provide 22 cores each at 2.2 GHz
  • 64 GB DDR4 ECC registered memory installed with capacity up to 384 GB
  • 16 hot-swap 2.5 inch drive bays supported by PERC H730 SAS controller
  • iDRAC8 Express remote management enables out-of-band server control
  • Dual 1100 W power supplies deliver redundant power for high availability

Dual Xeon E5-2699v4 server for dense compute

The Dell PowerEdge T430 packs two 22-core Xeon E5-2699v4 processors at 2.2GHz and 64GB of DDR4 ECC registered memory into a 16-bay 2.5-inch chassis. It targets virtualisation hosts, database nodes and render farms that need high core counts in a compact rack footprint. Buyers who need more than 384GB of memory or GPU acceleration should look elsewhere.

Dual 1100W supplies with PERC H730 RAID

Redundant 1100W power supplies feed the CPUs, memory and up to sixteen SATA or SAS drives through the PERC H730 controller. iDRAC8 Express provides remote console and sensor monitoring so fan curves and inlet temperatures can be managed without physical access. The integrated 1GbE dual-port 332T adapter handles management and light data traffic.

Grows from 64GB to 384GB DDR4 in the same chassis

The system ships with 64GB installed across the available DIMM slots and supports a maximum of 384GB when fully populated with DDR4 ECC registered modules. Drive bays accept 2.5-inch SATA or SAS media; no drives are included. The jump is worth it when workloads scale beyond a single-socket box but still fit within the 430’s thermal and power envelope.

Highlights

  • Dual Xeon E5-2699 v4 processors provide 22 cores each at 2.2 GHz
  • 64 GB DDR4 ECC registered memory installed with capacity up to 384 GB
  • 16 hot-swap 2.5 inch drive bays supported by PERC H730 SAS controller
  • iDRAC8 Express remote management enables out-of-band server control
  • Dual 1100 W power supplies deliver redundant power for high availability

Specifications

BrandDELL
SeriesPowerEdge
ModelRack Mount
TypeRack
CPU TypeIntel Xeon
CPU Speed2.2GHz
# of Processors Installed2
MAX Processors2
Installed Memory Size64GB
Memory TypeDDR4
Max Memory Capacity384GB
Hard Drive (Installed)8,00
Storage ControllerDell PERC H730 SAS Controller
HDD InterfaceSATA
GPU TypeIntegrated Graphics
Remote ManagementiDRAC8 - Express License
Dimensions36 x 24 x 10 in
Weight40

Questions about this item

How do I install the 2.5-inch drives into the 16-bay chassis and what step is often missed?

Slide each drive into a bay until the latch clicks, then configure the virtual disks in the PERC H730 BIOS before the OS sees them.

Which components will need replacement first during long-term operation?

The two 1100 W power supplies and system fans are the primary field-replaceable units; DDR4 ECC memory modules can also be swapped if errors appear.

What thermal or power limit appears first when both Xeon E5-2699 v4 CPUs run at full load continuously?

The dual 1100 W supplies set the power ceiling; sustained 22-core activity at 2.2 GHz will hit that limit before memory bandwidth saturates.
