Silver rack-mount server chassis with sixteen 2.5 inch drive bays front panel

DELL

DELL PowerEdge T430 16SFF rack server 1x Xeon E5-2620 v3 192GB DDR4

SKU CH-4G0Y-3AGC7

A 16-bay 2.5-inch rack server with a 2.4GHz 6-core Xeon, 192GB DDR4 and PERC H730 controller

  • TypeRack
  • CPU TypeIntel Xeon
  • CPU Speed2.4GHz
  • # of Processors Installed1
  • MAX Processors2
  • Installed Memory Size192GB
  • 16 drive bays for storage density
  • 192GB DDR4 ECC memory for large workloads
  • Single Xeon E5-2620 v3 at 2.4GHz with six cores
  • PERC H730 RAID controller for data protection
  • iDRAC8 Express for remote server management

Dell PowerEdge T430 16SFF rack server

The Dell PowerEdge T430 is a 16-bay rack server fitted with one Intel Xeon E5-2620 v3 processor running at 2.4 GHz and 192 GB of DDR4 ECC registered memory. It targets organisations that need dense 2.5-inch SAS storage in a 36 x 24 x 10 inch chassis with remote management via iDRAC8 Express.

SAS interface and PERC H730 controller

The server uses a SAS interface driven by a Dell PERC H730 RAID controller supporting up to 16 drive bays. No drives are installed, so capacity and redundancy depend entirely on the SAS disks you add. Maximum memory capacity is 384 GB across the available slots.

Installation notes and common issues

Two 1100 W power supplies and an integrated dual-port 1 GbE 332T adapter are included, simplifying initial power and network cabling. Rail kits are optional and must be requested separately. Memory upgrades must use DDR4 ECC registered modules only; other DDR generations will not fit.

Highlights

  • 16 drive bays for storage density
  • 192GB DDR4 ECC memory for large workloads
  • Single Xeon E5-2620 v3 at 2.4GHz with six cores
  • PERC H730 RAID controller for data protection
  • iDRAC8 Express for remote server management

Specifications

BrandDELL
SeriesPowerEdge
ModelRack Mount
TypeRack
CPU TypeIntel Xeon
CPU Speed2.4GHz
# of Processors Installed1
MAX Processors2
Installed Memory Size192GB
Memory TypeDDR4
Max Memory Capacity384GB
Hard Drive (Installed)4,80
Storage ControllerDell PERC H730 SAS Controller
HDD InterfaceSAS
GPU TypeIntegrated Graphics
Remote ManagementiDRAC8 - Express License
Dimensions36 x 24 x 10 in
Weight40

Questions about this item

Should I pick the single-CPU or dual-CPU version of the PowerEdge T430?

This unit ships with one Xeon E5-2620 v3 at 2.4 GHz and supports a second processor up to two total.

What does 192 GB of DDR4 ECC registered memory mean for daily workloads?

It provides 192 GB of error-correcting DDR4 RAM, leaving headroom to expand to the 384 GB maximum.

How does the PERC H730 SAS controller limit drive performance?

The H730 manages SAS drives over the controller’s RAID engine; throughput is bound by the controller and drive specs.
