Silver rack-mount server chassis with sixteen 2.5-inch drive bays visible on front

DELL

DELL PowerEdge T430 16SFF rack server 1x Xeon E5-2640 v3 2.6GHz 128GB DDR4

SKU CH-H2BK-G7YY5

A 16-bay 2.5-inch rack server with one Xeon E5-2640 v3 at 2.6GHz, 128GB DDR4 and a PERC H730 controller

  • TypeRack
  • CPU TypeIntel Xeon
  • CPU Speed2.6GHz
  • # of Processors Installed1
  • MAX Processors2
  • Installed Memory Size128GB
  • 16 drive bays for high storage density
  • 128GB DDR4 ECC memory for reliable multitasking
  • PERC H730 RAID controller for data protection
  • iDRAC8 remote management for simplified administration
  • Dual 1100W power supplies for redundancy

Dell PowerEdge T430 16SFF Server

The Dell PowerEdge T430 is a 2U rack server with a 16-bay 2.5-inch chassis. It ships with one Intel Xeon E5-2640 v3 processor at 2.6GHz and 128GB of DDR4 ECC registered memory. This configuration targets businesses that need dense local storage capacity in a standard rack footprint.

Installation notes

The unit includes two 1100W power supplies and a PERC H730 RAID controller pre-installed. Drive bays accept SAS drives; no drives are fitted so you must supply your own. Rails are available on request. The iDRAC8 Express licence provides basic remote management out of the box.

Memory ceiling

Maximum supported memory is 384GB across the available DIMM slots. The current 128GB load leaves headroom for future expansion if workloads grow. Buyers who need more than 384GB of RAM should consider a different platform.

Highlights

  • 16 drive bays for high storage density
  • 128GB DDR4 ECC memory for reliable multitasking
  • PERC H730 RAID controller for data protection
  • iDRAC8 remote management for simplified administration
  • Dual 1100W power supplies for redundancy

Specifications

BrandDELL
SeriesPowerEdge
ModelRack Mount
TypeRack
CPU TypeIntel Xeon
CPU Speed2.6GHz
# of Processors Installed1
MAX Processors2
Installed Memory Size128GB
Memory TypeDDR4
Max Memory Capacity384GB
Hard Drive (Installed)4,80
Storage ControllerDell PERC H730 SAS Controller
HDD InterfaceSAS
GPU TypeIntegrated Graphics
Remote ManagementiDRAC8 - Express License
Dimensions36 x 24 x 10 in
Weight40

Questions about this item

How can I confirm the PERC H730 RAID controller and both 1100W power supplies are detected after first boot?

During POST watch for the H730 BIOS banner and verify both PSUs show green LEDs; iDRAC8 Express will then report each supply and the controller as healthy in its system inventory.

Which components ship with the T430 and which must I source separately?

The chassis includes one Xeon E5-2640 v3, 128GB DDR4 ECC RDIMMs, PERC H730, dual 1100W PSUs, 2-port 332T NIC, iDRAC8 Express and rails on request; drives are not installed.

Should I select the 16-bay 2.5" chassis or a different capacity for this configuration?

This unit is the 16-bay 2.5" SFF model supporting up to 16 drives; no other bay-count version is offered for this listing.
