Tower server chassis with silver front bezel and eight 3.5-inch drive bays

DELL

DELL PowerEdge T430 E5-2667 2x 3.2GHz 8-Core 16GB DDR4 H730 8-Bay rack server

SKU CH-BN6Q-1W4NH MPN E5-2667

Tower server with dual 3.2 GHz 8-core Xeons, 16 GB DDR4, H730 RAID and eight 3.5″ drive bays

  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed3.20 GHz
  • CPU SocketLGA 2011-3
  • Number of CPU Cores8-Core Processor
  • # of Processors InstalledE5-2667 V4

Installed Memory Size 16GB

HDD None

CPU Model E5-2667 V4

  • Dual Xeon E5-2667 v4 at 3.2 GHz base clock with 3.6 GHz turbo for high single-thread speed
  • 16 GB DDR4 2400 MHz registered ECC memory across 2 modules with room to grow to 384 GB
  • PERC H730 1 GB controller supports RAID 0/1/5/6/10/50/60 and pass-through on 12 Gb/s SAS/SATA
  • Eight 3.5-inch hot-swap drive trays ready for SATA or SAS drives with no drives installed
  • iDRAC 8 Express plus dual 1 GbE ports and dual 750 W platinum power supplies for remote management and redundancy

Tower server for small offices

The Dell PowerEdge T430 is a tower-format server system built around two Intel Xeon E5-2667 v4 processors running at 3.2 GHz with a 3.6 GHz turbo frequency. Each CPU delivers eight cores, providing sixteen threads for multi-threaded workloads. The system ships with 16 GB of DDR4 registered ECC memory and a PERC H730 storage controller supporting RAID levels 0, 1, 5, 6, 10, 50 and 60.

Suits general office workloads.

This configuration fits small offices and remote sites running collaboration, mail, file, print or web serving tasks where a single tower server with redundant power is preferred. Organisations needing more than twelve memory slots, more than eight 3.5-inch drive bays, or integrated networking faster than dual-port 1 GbE should evaluate alternative platforms.

Eight 3.5-inch SAS/SATA bays

The chassis provides eight hot-swap trays for 3.5-inch SAS or SATA hard drives or solid-state drives, but no drives are included. The PERC H730 controller manages the installed drives through the SATA/SAS interface, so storage capacity and performance depend entirely on the drives you add.

Highlights

  • Dual Xeon E5-2667 v4 at 3.2 GHz base clock with 3.6 GHz turbo for high single-thread speed
  • 16 GB DDR4 2400 MHz registered ECC memory across 2 modules with room to grow to 384 GB
  • PERC H730 1 GB controller supports RAID 0/1/5/6/10/50/60 and pass-through on 12 Gb/s SAS/SATA
  • Eight 3.5-inch hot-swap drive trays ready for SATA or SAS drives with no drives installed
  • iDRAC 8 Express plus dual 1 GbE ports and dual 750 W platinum power supplies for remote management and redundancy

Specifications

BrandDELL
SeriesPowerEdge T430
ModelT430
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed3.20 GHz
CPU SocketLGA 2011-3
Number of CPU Cores8-Core Processor
# of Processors InstalledE5-2667 V4
MAX Processors2
ChipsetIntel C610
Installed Memory Size16GB
Memory TypeDDR4
Max Memory Capacity384GB
Number of Memory Slots12
Hard Drive (Installed)None
Storage ControllerDell Perc H730 1GB Controller
HDD InterfaceSATA/SAS
SSD (Installed)No
Raid LevelRAID 0/1/5/6/10/50/60
GPU TypeMatrox G200
Video Memory8 MB
Ethernet ControllerIntegrated Dell Broadcom 5720 Dual Port 1GbE LOM
LAN Ports2 x Ports
Expansion Slots1 x PCIe 3.0 x16 Slot, Single Riser Included (Riser 3)
Management PortRJ 45
Operating SystemNo
Features8 x 3.5" SATA/SAS Hot-Plug Drive Bays

Other versions of this model

5 more in the same range

Same family, different memory, cooler or clock — compare before you commit.

Questions about this item

What interface does the H730 controller use and what speed does it cap at?

The PERC H730 is a 12 Gb/s SAS/SATA controller that supports RAID 0/1/5/6/10/50/60 and pass-through mode.

What physical space and trays does the server provide for drives?

The chassis includes eight 3.5-inch SAS/SATA hot-swap trays and a front bezel; no drives are installed.

How is the H730 controller installed and what step is often missed?

The H730 mini card seats in the dedicated storage slot and its backup battery must be connected for RAID cache protection.
