Silver 5U rack server chassis, sixteen 2.5-inch drive bays, two power supplies, front bezel absent

DELL

DELL PowerEdge T440 5U rack server 2x Xeon Gold 5120 2.2GHz 14-core 32GB DDR4 HBA330 8x 2.5" trays 2x 750W PSU

SKU CH-V76V-30FF9

A 5U rack server with dual 14-core Xeon Gold 5120 CPUs at 2.2 GHz, 32 GB DDR4, HBA330 controller and eight 2.5-inch drive trays

  • TypeRack
  • Rack Height5U
  • Redundant Hot-swap PowerYes
  • CPU TypeIntel Xeon
  • CPU Speed2.2GHz (3.2GHz Turbo)
  • CPU SocketLGA 3647
  • Dual Xeon Gold 5120 CPUs deliver 14 cores each at 2.2GHz base and 3.2GHz turbo
  • 32GB DDR4-2400 ECC registered memory installed across four slots with 1TB maximum capacity
  • PERC HBA330 controller provides 12Gb/s SAS and SATA connectivity for storage arrays
  • Sixteen 2.5-inch hot-swap drive bays with eight trays included for flexible storage configuration
  • iDRAC 9 Express enables remote management with dual 750W platinum power supplies for redundancy

Server configuration

This new Dell PowerEdge T440 is a 5U rack server equipped with two Intel Xeon Gold 5120 processors, each running at 2.2 GHz with 14 cores and a 3.2 GHz turbo frequency. It includes 32 GB of DDR4 ECC registered memory across four modules and a PERC HBA330 storage controller. The chassis provides eight 2.5-inch drive trays within a sixteen-bay design and dual 750 W redundant power supplies.

Target workloads

The dual 14-core CPUs and expandable memory capacity suit virtualisation hosts, database servers and file storage roles that benefit from high core counts and storage density. Organisations needing GPU-accelerated compute, higher memory bandwidth than DDR4 provides or a smaller rack footprint will not find those capabilities in this platform.

Storage controller interface

The installed PERC HBA330 delivers 12 Gb/s SAS and SATA connectivity to the drive backplane. This specification determines which drive types can be used and whether hardware RAID functions are available without adding a separate controller card.

Highlights

  • Dual Xeon Gold 5120 CPUs deliver 14 cores each at 2.2GHz base and 3.2GHz turbo
  • 32GB DDR4-2400 ECC registered memory installed across four slots with 1TB maximum capacity
  • PERC HBA330 controller provides 12Gb/s SAS and SATA connectivity for storage arrays
  • Sixteen 2.5-inch hot-swap drive bays with eight trays included for flexible storage configuration
  • iDRAC 9 Express enables remote management with dual 750W platinum power supplies for redundancy

Specifications

BrandDELL
SeriesPowerEdge
ModelT440
TypeRack
Rack Height5U
Redundant Hot-swap PowerYes
CPU TypeIntel Xeon
CPU Speed2.2GHz (3.2GHz Turbo)
CPU SocketLGA 3647
Number of CPU Cores14 Core-Processors
CPU FeaturesGold 5120
# of Processors Installed2
MAX Processors2
Installed Memory Size32GB
Memory TypeDDR4
Max Memory Capacity1TB
Number of Memory Slots16
Hard Drive (Installed)None
Storage ControllerDell Perc HBA330 Controller
SSD (Installed)No
Raid LevelNone
Ethernet ControllerIntegrated Dell 2x1GbE Dual Port Ethernet Adapter
Remote ManagementiDRAC9 Express
LAN Ports2 x Ports
Management PortRJ 45
Operating SystemNo

Questions about this item

Do I need to supply my own 2.5" SAS or SATA drives for the 16 hot-swap bays?

Yes, the server ships with 8 drive trays installed and no drives included, so you must provide up to 16 compatible 2.5" SAS or SATA drives yourself.

Will my existing DDR4-2400 ECC registered DIMMs work alongside the four 8 GB modules already installed?

The system has 16 DDR4 slots supporting up to 1 TB; adding matching DDR4-2400 ECC registered modules will work, but mixing speeds or ranks may reduce performance.

How can I verify the HBA330 controller sees every drive after I populate the bays?

During POST the HBA330 BIOS lists each detected SAS or SATA device, and iDRAC 9 Express shows the full drive inventory in its storage overview once the OS loads.
