DELL
DELL PowerEdge T630 16SFF 2x Xeon E5-2620 v3 64GB DDR4 No Drive rack server
Rack server with sixteen 2.5-inch bays, dual Xeon E5-2620 v3 processors at 2.4GHz and 64GB DDR4 memory
- TypeRack
- CPU TypeIntel Xeon
- CPU Speed2.4GHz
- # of Processors Installed2
- MAX Processors2
- Installed Memory Size64GB
- Dual Xeon E5-2620 v3 processors deliver multi-threaded performance for virtualisation workloads
- 64GB DDR4 ECC registered memory supports large dataset handling with error correction
- 16 SFF drive bays with PERC H730 SAS controller enable flexible RAID storage arrays
- iDRAC8 Enterprise license provides comprehensive out-of-band remote server management
- Dual 1100W power supplies ensure continuous operation through hardware redundancy
Dell PowerEdge T630 16SFF Server
This Dell PowerEdge T630 is a 2U rack server built for dense storage workloads. It arrives with two Intel Xeon E5-2620 v3 processors running at 2.4GHz and 64GB of DDR4 ECC registered memory. The 16-bay 2.5-inch chassis supports up to sixteen SATA or SAS drives through the integrated PERC H730 RAID controller. Remote administration is handled by iDRAC8 Enterprise.
Suits virtualisation hosts needing many drive bays
The sixteen 2.5-inch bays and 1.5TB maximum memory capacity make this platform a good fit for virtualisation clusters or software-defined storage nodes that demand local capacity. Buyers who need more than two processor sockets or require 3.5-inch drive carriers should evaluate alternative chassis designs. The integrated 1GbE dual-port adapter may limit throughput for high-speed replication tasks.
16-bay 2.5-inch chassis with PERC H730
The defining specification is the sixteen 2.5-inch drive bays paired with the Dell PERC H730 SAS controller, which determines how many drives can be installed and which RAID levels are available. This combination fixes the storage density and performance ceiling for the system. Confirm that your workload fits within the 2.5-inch form factor and the controller feature set before ordering.
Highlights
- Dual Xeon E5-2620 v3 processors deliver multi-threaded performance for virtualisation workloads
- 64GB DDR4 ECC registered memory supports large dataset handling with error correction
- 16 SFF drive bays with PERC H730 SAS controller enable flexible RAID storage arrays
- iDRAC8 Enterprise license provides comprehensive out-of-band remote server management
- Dual 1100W power supplies ensure continuous operation through hardware redundancy
Specifications
| Brand | DELL |
|---|---|
| Series | PowerEdge |
| Model | Rack Mount |
| Type | Rack |
| CPU Type | Intel Xeon |
| CPU Speed | 2.4GHz |
| # of Processors Installed | 2 |
| MAX Processors | 2 |
| Installed Memory Size | 64GB |
| Memory Type | DDR4 |
| Max Memory Capacity | 1.5TB |
| Hard Drive (Installed) | 1.920,00 |
| Storage Controller | Dell PERC H730 SAS Controller |
| HDD Interface | SATA |
| GPU Type | Integrated Graphics |
| Remote Management | iDRAC8 - Enterprise License |
| Dimensions | 36 x 24 x 10 in |
| Weight | 40 |
Questions about this item
What rack depth does the 36-inch deep chassis require?
The chassis measures 36 inches deep so the rack must provide at least that much usable depth.
How are the two Xeon E5-2620 v3 processors installed, and what step is often missed?
Both processors are already installed in the dual-socket motherboard; the step people miss is verifying that firmware is updated to the latest stable version before deployment.
When will the PERC H730 controller battery need replacement?
The PERC H730 uses a RAID battery backup that typically lasts several years; plan to replace it when the iDRAC8 reports a battery health warning.
