DELL
DELL PowerEdge T630 16SFF 2x Xeon E5-2640 v3 256GB DDR4 No Drive Rack Server
A rack-mount server with sixteen 2.5-inch drive bays, dual Xeon E5-2640 v3 processors at 2.6GHz and 256GB DDR4 memory, ready for custom storage configuration
- TypeRack
- CPU TypeIntel Xeon
- CPU Speed2.6GHz
- # of Processors Installed2
- MAX Processors2
- Installed Memory Size256GB
- Dual Xeon E5-2640 v3 processors deliver 16 cores at 2.6GHz for multi-threaded workloads
- 256GB DDR4 ECC memory supports large datasets and virtualisation density
- 16-bay 2.5" chassis provides flexible SAS storage expansion up to 1.5TB RAM capacity
- PERC H730 RAID controller with 2GB cache accelerates array performance and data protection
- iDRAC8 Enterprise remote management enables out-of-band monitoring and firmware updates
Capacity and compute density
The Dell PowerEdge T630 16SFF is a rack-mount server system equipped with two Intel Xeon E5-2640 v3 processors running at 2.6GHz and 256GB of DDR4 ECC registered memory. Sixteen 2.5-inch drive bays and a PERC H730 SAS controller provide high-density internal storage capacity. Integrated graphics and a 1Gb dual-port Ethernet adapter handle display and network connectivity out of the box.
Organisations needing dense CPU and memory resources
IT departments that run virtualisation clusters, database workloads or memory-intensive applications will benefit from the dual-socket design and 1.5TB maximum memory ceiling. Buyers who require GPU acceleration or more than sixteen drive bays should evaluate other platforms because this model uses integrated graphics and a fixed 16-bay chassis. Remote administration is covered by iDRAC8 Enterprise licensing.
Sixteen 2.5-inch SAS drive bays with PERC H730 RAID
The single specification that determines fit is the sixteen-bay 2.5-inch SAS backplane paired with the PERC H730 controller. It defines how many drives can be installed, which RAID levels are supported and whether existing SAS drives can be reused. No drives are included, so storage capacity and redundancy must be planned around this bay count and controller combination.
Highlights
- Dual Xeon E5-2640 v3 processors deliver 16 cores at 2.6GHz for multi-threaded workloads
- 256GB DDR4 ECC memory supports large datasets and virtualisation density
- 16-bay 2.5" chassis provides flexible SAS storage expansion up to 1.5TB RAM capacity
- PERC H730 RAID controller with 2GB cache accelerates array performance and data protection
- iDRAC8 Enterprise remote management enables out-of-band monitoring and firmware updates
Specifications
| Brand | DELL |
|---|---|
| Series | PowerEdge |
| Model | Rack Mount |
| Type | Rack |
| CPU Type | Intel Xeon |
| CPU Speed | 2.6GHz |
| # of Processors Installed | 2 |
| MAX Processors | 2 |
| Installed Memory Size | 256GB |
| Memory Type | DDR4 |
| Max Memory Capacity | 1.5TB |
| Hard Drive (Installed) | 9,60 |
| Storage Controller | Dell PERC H730 SAS Controller |
| HDD Interface | SAS |
| GPU Type | Integrated Graphics |
| Remote Management | iDRAC8 - Enterprise License |
| Dimensions | 36 x 24 x 10 in |
| Weight | 40 |
Questions about this item
Should I choose the 16-drive-bay chassis or a smaller bay count for this T630?
The server is built with the 16 x 2.5-inch bay chassis, giving you the maximum drive density this model supports.
What does the 2.6 GHz speed mean when both Xeon E5-2640 v3 processors are installed?
Each of the two CPUs runs eight cores at 2.6 GHz base clock, providing 16 total cores and 20 MB cache per processor for multi-threaded workloads.
How does the PERC H730 SAS controller limit the storage interface?
The H730 manages SAS drives through the backplane, capping drive connectivity to SAS protocol and the 16 available 2.5-inch bays.
